TABLE OF CONTENTS
1. SPECIFICATIONS .................................................................................................................................................................................................................
2. EXPLODED VIEW ................................................................................................................................................................................................................
3. ACCESSORIES & BRACKETS .............................................................................................................................................................................................
4. I/O PORTS .............................................................................................................................................................................................................................
5. CONNECTIONS ...................................................................................................................................................................................................................
6. PANEL REMOVAL ................................................................................................................................................................................................................
7. MOTHERBOARD INSTALLATION ...................................................................................................................................................................................
8. POWER SUPPLY INSTALLATION ....................................................................................................................................................................................
9. FILTERS REMOVAL .............................................................................................................................................................................................................
10. FANS COMPATIBILITY .......................................................................................................................................................................................................
11. RADIATOR BRACKET INSTALLATION ...........................................................................................................................................................................
12. HARD DRIVE CAGE ............................................................................................................................................................................................................
13. DROP-N-LOCK SSD BRACKET ........................................................................................................................................................................................
14. MULTIFUNCTIONAL MID PLATE ...................................................................................................................................................................................
15. WATERCOOLING INSTALLATION ....................................................................................................................................................................................
16. UPGRADE OPTIONS ...........................................................................................................................................................................................................
17. SERVICES AND SUPPORT ................................................................................................................................................................................................
4
1. SPECIFICATIONS
CASE SPECIFICATIONS
5
Dimension 230 mm x 375 mm x 395 mm (W x H x D)
6
Form Factor Mini ITX Tower
8 Material(s) Steel Plates, Plastics, Steel chassis
Motherboard support Mini ITX
9
Front I/O 2x USB 3.0, Mic, Headphone, RGB switch
Side window Yes, Tempered glass
10
11
13
EXPANSION & DRIVE BAYS
14
Expansion slots 2
15
Internal 3.5" 2 (1x extra upgrade slot)
16
Internal 2.5" 1 (1x extra upgrade slot)
17
COOLING
120 mm
19
Front 2x
20
Top 2x
21
Rear 1x
(1included)
22
LIQUID COOLING 120 mm radiator
24
Front Up to 240
25
Top Up to 240
Rear 120
PH-F140 Premium Fan (1x included)
Speed (rpm)
Max Airflow
Static Pressure
Acoustical Noise
CLEARANCE
Graphic card
CPU cooler
Cable Management
Motherboard - Radiator
Warranty
140 mm 200mm
2x 1x
2x -
1x -
140 mm radiator
Up to 280
140
500-1600 ±250 rpm
68.1 CFM
1.62 mm H2O
17-25.3 dB (A)
330 mm (13 in)
200 mm (7.9 in)
28 mm (1.1 in)
120 mm form factor: 70 mm (2.76 in)
140 mm form factor: 50 (1.97 in)
5 Years
5
