- Page 1 DWR-2468/DB-2420 2.4GHz Digital True Diversity Wireless System Operation manual ISO 9001 REGISTERED INTERNATIONAL 14001 ISO 14001 REGISTERED INTERNATIONAL OHSAS 18001 OHSAS 18001 GREEN PRODUCT...
- Page 2 Wireless Microphone System Operating Manual Thank you for choosing the Fitness Audio D-Series digital wireless microphone system! Our products are built to last and designed for user friendly operation with quality performance. Each system consists of: 1. Receiver 4. Switching Power Adapter 2.
- Page 3 Wireless Microphone System Operating Manual Audio Output Connection There are two audio outputs on the back of the receiver, Mic-level balanced and Line-level unbalanced. Use audio cable for the connection between the receiver and the amplifier/mixer. Unbalanced Audio Connection: If the amplifier/mixer has a 6.3mm φ phone jack, connect a ...
- Page 4 Wireless Microphone System Operating Manual Receiver Operation CHANNEL SCANNING For an interference-free operation, selecting a cleaner channel by scanning might be necessary. Before scanning, the transmitter must be switched ‘OFF’. 1. Press-release ▲(UP) or ▼(DOWN) button 2. Press and hold SET button until SER000 until the LCD displays and below...
- Page 5 Wireless Microphone System Operating Manual CHANNEL SYNCHRONIZING of the Receiver and Transmitter 1. Press and hold the transmitter’s 2. Press and hold the receiver’s SYNC button synchronizing button until LINK flashes on until the frequency icon appears. After FREQ the LCD. successful channel synchronizing, this icon will disappear automatically.
- Page 6 Wireless Microphone System Operating Manual DB-2420 Digital Belt-pack Transmitter 1. LCD 2. Cover release button 3. Channel synchronizing button 4. Menu button 5. Setting button 6. High-impedance gain control (GT) 7. Low-impedance gain control (MT) 8. Battery compartment 9. Power button 10.
- Page 7 Wireless Microphone System Operating Manual Battery Type Setting Alkaline or Rechargeable can be used with our transmitter. Our optional Battery Charger HC-24 can be used for both types of transmitters. 1. Press-release MENU button until the 2. Press and hold SET button until NIMH CHANNEL-BATTERY TYPE page appears.
- Page 8 Wireless Microphone System Operating Manual 1. Press-release MENU button until the 2. Press and hold SET button until the RF CHANNEL-RF POWER page appears. power figure flashes to denote readiness for setting. CH:006 CH:006 ► ► MENU MENU RF08 RF08 3.
- Page 9 Wireless Microphone System Operating Manual Optional DH-2420 Digital Handmic 1. Cartridge 4. LCD 8. Color cap 2. Battery power LED 5. Menu button 9. Battery compartment 3. 3-step power switch 6. Setting button 10. Charging contacts (ON-MUTE-OFF) 7. Channel synchronizing button 3-STEP power switch Power status MUTE...
- Page 10 Wireless Microphone System Operating Manual Battery Type Setting Alkaline or Rechargeable can be used with our transmitter. Our optional Battery Charger HC-24 can be used for both types of transmitters. 1. Press-release MENU button until the 2. Press and hold SET button until NIMH CHANNEL-BATTERY TYPE page appears.
- Page 11 Wireless Microphone System Operating Manual RF power setting Important: Lower output power will reduce the RF transmission distance and higher output power will extend the possible RF transmission distance. However, higher output power places slightly more load on the battery and will reduce operating duration faster than lower output power.
- Page 12 The Fitness Audio DWR-2468 Receiver, DB-2420 and DH-2420 Transmitters are covered by a minimum 12 month parts and labor warranty against manufacturer’s defects from the date of purchase by the first owner. Warranty Information (Please retain for your records) This product was purchased by: (Your Business) ............................
