Summary of Contents for Greencut GS9200
- Page 2 Product Manual - Chainsaws Index Index ................................1 General Safety ............................. 2 Chainsaw Safety............................3 Parts Diagram .............................. 6 Assembly ..............................9 Before use ..............................10 Starting the Engine ............................. 11 Stopping the Engine ........................... 12 Maintenance ............................... 13 Transporting & Storage..........................15 Troubleshooting ............................
-
Page 3: General Safety
Product Manual - Chainsaws General Safety It is important you read and using the machine. Always keep the machine shut off the engine before refuelling. Do not fuel a hot engine – fuel may spill and cause a fire. understand the instruction away from naked flame or sparks. -
Page 4: Chainsaw Safety
Product Manual - Chainsaws Chainsaw Safety WARNING! Before attempting to do anything with the CHAINSAW KICKBACK chainsaw READ THE MANUAL. WARNING! Chainsaws have the potential to inflict injuries CRITICAL! Other than the obvious risk of physical contact with and/or create hazardous situations. The major causes of a moving chain, the single most dangerous aspect of the saw is 'kickback'. - Page 5 Product Manual - Chainsaws 10814082100...
- Page 6 Product Manual - Chainsaws 10814082100...
- Page 8 Product Manual - Chainsaws 10814082100...
-
Page 10: Assembly
Product Manual - Chainsaws Assembly WARNING! The chainsaw has very sharp edges. Use thick protective gloves for safety. Open the box and install the guide bar and the chainsaw on the power unit as follows: 1. Pull the chainbrake handle toward the rear of the saw (or pull in the direction that would be toward the rear of the saw if the chainbrake was installed onto the saw). -
Page 11: Parts Diagram
Product Manual - Chainsaws Adjusting the chain using the chain tensioner WARNING! Always use protective, non-cut gloves when touching the cutting chain. DANGER! Always disconnect the “spark plug lead” before touching the cutting chain. IMPORTANT! After running a new chain for 5min the tension must be re-checked. An old chain must be checked every 15min of use. -
Page 13: Stopping The Engine
Product Manual - Chainsaws If the Engine Fails To Start Repeat the appropriate starting procedure (warm or cold engine). If the engine fails to start after frequent attempts, the engine may be flooded (too much fuel in engine) If you suspect your engine is flooded go to next section “Starting a flooded engine”... -
Page 14: Maintenance
Product Manual - Chainsaws Return idle and mixture screws to factory setting 1. Turn the Idle screw clockwise until it just begins to tighten (do not tighten it) 2. Turn the Idle screw counter clockwise by 5 turns. 3. Turn the Mixture screw clockwise until it just begins to tighten (do not tighten it) 4. - Page 15 Product Manual - Chainsaws 10814082100...
-
Page 16: Transporting & Storage
Product Manual - Chainsaws Transporting & Storage CAUTION! Fuel stored in the carburettor for extended periods can cause hard starting, and could also lead to increased service and maintenance costs. IMPORTANT! Use only clean, fresh non-ethanol 95+ unleaded with 2-Stroke oil mix. IMPORTANT! If the machine will not be used for 30 days or longer, use the following procedures to prepare it for storage. -
Page 17: Troubleshooting
Product Manual - Chainsaws Troubleshooting Engine does not start A) Faulty recoil starter. Does the engine If ‘no’ B) Fluid in the crankcase. crank? C) Internal damage. If ‘yes’ A) Loose spark plug. Good compression? If ‘no’ If ‘no’ Tighten and re-test. B) Excess wear on cylinder, piston, rings. - Page 18 Product Manual - Chainsaws Low Power Operator is over Cut at slower rate. working the unit. Take the machine Is the engine Carburettor to an authorised overheating? mixture is too lean. service center. Fan, fan cover, Clean or replace as cylinder fins dirty or necessary.
