Alcatel-Lucent VitalQIP AMS 1200 Quick Start Manual

VitalQIP AMS 1200
Thank you for choosing the VitalQIP
preloaded with the Appliance Management Software. Upon successful configuration, the AMS
will host the centralized Appliance Management functionality for AMM/ESM appliances. This guide is
intended to help you configure the AMS
Refer to the table below as you ensure that the contents of the box are accounted for.

Box contents

1200
Your AMS ships with the following items:
Item
AMS 1200 appliance
Quick Start Guide
Slide Rail Kit
Power cables
DB9-to-RJ45 Serial Connector
Figure 1. VitalQIP AMS 1200 front view
Figure 2. VitalQIP AMS 1200 rear view

Appliance setup instructions

1. Attach the appliance to an appropriate rack using the supplied rack mount hardware (optional).
2. Connect a network cable to the Ethernet port labelled
3. Connect a monitor, a keyboard, and a mouse to the appropriate ports on the appliance. You may
also use the virtual console of the Lights Out capability (see below for configuration). These devices
can be removed after the initial setup.
4. Connect the supplied power supply cables to the back of the appliance and to a power source (110v
or 240v). The appliance automatically powers up after the power source is connected. If the power
®
1200
®
AMS appliance. The AMS
1200
appliance.
1200
appliance comes
Quantity
1
1
1
2
1
Gb1
on the back of the appliance.
1200
