- Page 1 MT HDD/SSD Duplicator MT Platform Series User Guide V 5.1 MT800H/1600H/2600H/600G/1600G/2100G/2600G...
- Page 2 Content Index Content Index ➃ How to Compare HDDs Disclaimer of Warranties ⌘ Confirm Duplication Notice & Remindeer Accuracy Important Notice Safety Precautions ➄ How to Erase HDDs ⌘ Data Sanitization ➀ Overview -Settings of Erase Methods ⌘ Product Overview 1 Quick Erase ⌘...
-
Page 3: Important Notice
Warranties & Notice Disclaimer of Warranties MT series duplicators are made specifically for data backup with legal authorities from copyright owners. Any unauthorized action of copyright is strictly prohibited, and the manufacturer disclaims all warranties or representations of illegal actions by users. The manufacturer also disclaims any liability for any loss or damage due to not being able to perform its undertakings or provide any of the services attributable to any events or circumstances beyond our control. -
Page 4: Before You Start
Before You Start ⌘ Preparation Tips before You Start • Make sure to use stable power supply. • Please use at clean & dry environment. • Please keep the environment well ventilated. • When the duplicator operates, it is normal for the machine to heat up. -
Page 5: Product Overview
Overview ➀ ⌘ Product Overview The MT series have ultra high speed duplication, and each SATA port is independent. MT series support up to 25 targets duplication, it has the same performance of speed is far beyond PC-based duplicators. There are small to large duplication targets and different duplication speeds for option. MT series obtain full line products to meet specific requirements. -
Page 6: Product Features
Features ⌘ Product Features Log Report Management Ultra High Speed Exclusive Logs management records all tasks and details for better production Ultra high transmission speed for each control. port operating individually. • Besides PC-Monitoring, LV07H can browse Log Report from duplicator Quick Copy Mode through PC. -
Page 7: Hardware Overview
Open Platform Appearance Design ⌘ Hardware Overview ● Front View Source port Optional Target Port Indication Power supply Power switch USB port to PC USB port Operation buttons Optional Alarm ● Back View Power supply Power switch USB port to PC... -
Page 8: Led Status
Appearance ● LED Status Green Yellow Indication LED on each slot Yellow: Powering Green: Pass Red: Fail ● LCD Configuration Number of Function target HDD Total size Forward Confirm/OK Port # of the slowest Backward Cancel/Back copying HDD Time elapsed and Copied processed size copy progress... -
Page 9: Interface Adapter
Appearance ● Interface Adapter (Please contact the original manufacturer of the duplicators ） 1.8”to 3.5”IDE CF to SATA IDE to SATA Micro SATA to SATA CFast to SATA mSATA to SATA eSATA adapter... -
Page 10: Mt-G & Mt-H Series
➁ Function Table ⌘ MT-G & MT-H Series Function Items/Description Copy data from source HDD to targets. 1. Copy (There are four copy modes for selection at function "6.2 Copy Area") 2. Compare Comparison between the source and targets to make sure copy accuracy. 3. - Page 11 Function Table ➁ 6.3 Skip Error Set to ignore error of source HDD while copying. (Set number from 0~65535 or unlimited) 6.4 Minimum Speed Set to check HDDs’ minimum speed as 10, 20, 30~300MB/Sec or don’t check. 6.5 Check Source Minimum Speed Set to check source minimum speed or don’t check.
- Page 12 ➁ Function Table Clear HPA Setting 6.7.7 Clear HPA at Delete HPA during erase tasks. Keep HPA Setting ERASE Do not delete HPA during erase tasks. 6.7.8 Transfer Rate Advanced Select the proper transfer rate UDMA2~7. UDMA7 is the fastest. 6.
-
Page 13: Start To Copy
How to Copy HDDs ➂ ⌘ Start to Copy Step 1: Prepare Source & Target HDDs Prepare a source HDD and target HDDs. （★ It’s strongly recommended the source and target are the same capacity.) Source Port Target HDD Source HDD •... - Page 14 ➂ How to Copy HDDs 功能 總容量 Step 3: Enter Function "1.Copy" 複製 x1 2047M 0:12 50% （2）1024M Use ▲▼ keys to select "1.Copy", and then press "OK". Duplication will start to proceed. 最慢速口 已拷貝容量 已拷貝時間 Note When all the target HDD ports are plugged, the machine will start duplicating automatically. If not all ports are plugged, the number of working targets shows on LCD.
-
Page 15: Set Up Before Copy Compare
Copy Setting ⌘ Set up before Copy/Compare Please pay attention to the following settings before copy: 1 Set Copy Area of Source HDD 2 Set Tolerance of Bad Track 3 Auto Skip Lower-Speed HDD 4 Auto Skip Lower-Speed Source 1 Set Copy Area of Source HDD Appropriate copy area can greatly reduce operation time and have better efficiency. -
Page 16: ➋ All Partitions
➂ How to Copy HDDs Source Duplication Target Partition 1(150G) Data 30G Partition 1(200G) Data 90G 500GB 500GB [Copy Area] ALL Partitions Only 120G data area will be copied, it takes 12mintues. ➋ ALL Partitions Copy all of the partitions area bit-by-bit no matter there is data exist or not. The capacity of target HDDs have to be bigger than the partition required capacity. -
Page 17: ➍ Percentage (%)
[Copy Area] Copy Setting Percentage(%) ➍ Percentage (%) Copy the selected percentage range of source HDD Source Duplication Target 25％ 25％ 32％ 32％ 500GB 500GB Only copy the selected area, other area or data will not be copied. ● Copy area selection Example: There are two partitions in one 500G HDD. -
Page 18: Auto Skip Lower-Speed Hdds
➂ How to Copy HDDs 3 Auto Skip Lower-Speed HDDs Enter function 6.3 to setup tolerance speed of target HDDs. Set to check HDDs’ lowest tolerance speed. Users can choose “Don’t care” or set the speed value among 20/40/60~300MB/second. The system will skip any HDD which cannot reach the minimum speed. -
Page 19: Hpa Setting
Copy Setting ※ Troubleshooting When Duplication Fails Check if too many bad tracks on HDDs can cause duplication failures. Check the setting of function "6.2 Skip Error" ● Make sure all data cables are properly and firmly connected. ● Make sure the capacity of source HDD is smaller than target. ●... - Page 20 ➂ How to Copy HDDs 1 Copy HPA Area Enter fundtion "6. Setup"-->"7. Advanced Setup"-->"6.Copy HPA Area" This setting enables to setup whether to keep hidden area of the source during copy tasks. The users can select one from the function "6.7.6 Copy HPA area". The factory default setting is "No".
- Page 21 Copy Setting 2 Clear HPA at ERASE Enter fundtion "6. Setup"-->"7. Advanced Setup"-->" 7.Clear HPA at ERASE " This function will affect the HPA setting of HDDs during Erase. The default setting is "Clear HPA Setting". This setting enables to setup whether to erase hidden area of the targets during erasing tasks. The users can select from "Clear HPA Setting", or "Keep HPA Setting".
- Page 22 ➃ How to Compare HDDs ⌘ Confirm Duplication Accuracy Step 1: Prepare Source and Targets Prepare source HDD and target HDDs to compare after duplication finished. Target HDD Source HDD Step 2: Place Source and Targets Place source HDD to source port, target HDDs to other ports.
- Page 23 How to Erase HDDs ➄ ⌘ Data Sanitization • It will erase the data in HDD, please make sure you have backup all important data Caution before using this function. • To cancel operation of any erasing mode, press <ESC/X> key and hold continuously for 3 seconds to exit any erasing tasks.
- Page 24 ➄ How to Erase HDDs 1 Quick Erase (System and Files Area) The function will ONLY erase the index of the HDD. It is the quickest way to erase HDD. 2 Full Erase (Whole HDD Area) The function will erase the whole sectors on the target HDD.
- Page 25 How to Erase HDDs ➄ DoD EraseComp Method: **The erasing time of DoD Erase mode is 3 times longer than Full Erase mode, Note **The erasing duration of DoD Erase mode is 3 times longer than full erase mode. and the time of DoD EraseComp is 4 times longer than Full Erase mode. **The duration of DoD EraseComp is 4 times longer than full erase mode.
- Page 26 ➅ How to Update System ⌘ Two Methods for BIOS Update 1 Update by USB [ 系統韌體更新 ] 2.格式化硬盤 Step 1: Create Update USB Connect one USB drive to PC. Download latest firmware and save it to the USB drive. drive port Make sure the partition format of USB drive if Note...
- Page 27 How to Use PC-Monitoring ➆ Real-time PC-Monitoring Real-time PC-Monitoring is a convenient tool to monitor real-time status for advanced series, that real-time tasks skip lower speed HDDs in writing process to keep its best performance. ● Online Status By connecting to PC, all status can be viewed clearly, including copy process. ●...
- Page 28 ➆ How to Use PC-Monitoring Step 2: After launching PC-Link software, the install device driver of PL-2303 USB-to-Serial is initiated. Choose tab <PC Driver> and press <Install Driver> to continue. When the Wizard screen pop up, click <Next> to start installation. Step 3: Please wait during installation processing.
- Page 29 How to Use PC-Monitoring ➆ Step 4: Click <Finish> to complete installation. § Start to Launch PC-Monitoring Step 1: Please confirm that monitoring software LVO7H and the driver PL- 2303 have been installed well. Step 2: Prepare USB cable to connect between computer and the duplicator.
- Page 30 ➆ How to Use PC-Monitoring Step 5: When the following screen shown, the duplicator is linked to the computer successfully, ready to use real-time monitoring function. Step 6: If the status is not shown normal online status, please check step 1~3 again.
- Page 31 How to Use PC-Monitoring ➆ Step 3: After duplication, the program will show average speed of each HDD. ⌘ Browse Log Report through PC Besides PC-Monitoring, LV07H can browse Log Report of duplicator through PC. Step 1: After finishing all the task of duplicator, press "ESC"...
- Page 32 ➆ How to Use PC-Monitoring Log Report How to Use Log Report Log Report is a very important management tool to assist users in monitoring, recording and managing the whole duplication process and the result. Besides PC-Monitoring, LV07H can browse Log Report from duplicator through PC. Specific models of duplicators can provide exporting log through USB port.
- Page 33 How to Use PC-Monitoring ➆ ➌ Select Date Range After entering <Open Report>, select the date range for log report generation to check records of the duplicator. ➍ Generate Report After selecting the date range, clicking the tab <Generate Report> for log report generation, log report would shows.
- Page 34 ➆ How to Use PC-Monitoring ➏ Save Log to the Specific Location Specify a location and a name to save log. ➐ Complete to Output Log Reports After successful creating and saving the log, the report has been output to the location. Export Log by USB Drive The USB port of duplicator is able to perform firmware update and also for exporting Log Report.
- Page 35 How to Use PC-Monitoring ➆ ➏ Screen of Text Logs [ 記錄 ＃1-＃6 ] 4.進階功能 Advanced Function ➊ Function 7.4.1-Clear ALL Logs After user entering password, the log report saved in duplicator can be wiped out. ➋ Function 7.4.2-Setup Password Users can reset password to protect log records.
- Page 36 ➇ FAQ ⌘ System FAQ Category Question Answer: Reasons, Solutions (1) When the capacity of source HDD is larger than target HDDs. For example, copy 500GB source HDD to 250GB target HDDs. Error LCD shows (2) When the capacity of source and target are the same message "HDD Too Small"...
- Page 37 FAQ ➇ ⌘ PC-Monitoring FAQ PC-Monitor Question Answer Make sure USB cable is connected securely between Why my duplicator cannot PC and duplicator. It is recommended to attach USB execute PC-Monitoring? cable first and then open LV07H program. PC-Monitoring consumes large amount of resources Real-time from PC.
- Page 38 Stand-alone operation Operation Type Real-time PC monitoring, log report management Log Model Support log function, MT800H/1600H/2600H/1600G/2100G/2600G Display Backlight monochrome LCD display Status LED LED(Red/Green/Yellow) on each slot: Yellow(powering), Green(pass), Red(fail) 4 push keys ( ▲ / UP, ▼ / Down, OK/ Confirm, ESC/ Exit) Keys Quick Copy (System &...
