Vitae 5Kw & 8Kw Landscape
Please hand these instructions to the stove user when the installation is complete. Leave the stove ready for
operation and instruct the user in the correct use of the appliance and operation of controls.
Important: – This product must be installed by a suitably qualified installer.
PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY!
For safety reasons it is essential that your stove is correctly installed and operated. Heat Design
cannot accept responsibility for any fault or consequential problems arising through incorrect
installation or operation.
Wood Burner
Cassette Stove
Installation and Operating
Instructions
Please fix label with serial number of stove
before putting manual into stove
30 – 60 Hawthorn Road
Western Industrial Estate
www.heatdesign.ie
V1
Heat Design
Naas Road
Dublin 12
Advertisement
Table of Contents
Related Manuals for Heat Design Vitae 5Kw
Summary of Contents for Heat Design Vitae 5Kw
- Page 1 Dublin 12 www.heatdesign.ie PLEASE READ ALL THESE INSTRUCTIONS CAREFULLY! For safety reasons it is essential that your stove is correctly installed and operated. Heat Design cannot accept responsibility for any fault or consequential problems arising through incorrect installation or operation.
- Page 2 6.9 Maintenance 6.10 Seasonal Use 7. Safety Notes for your Guidance 8. Frequently Asked Questions 9. Spare Parts List & Codes: Vitae 5Kw Landscape 10. Spare Parts List & Codes: Vitae 8Kw Landscape Vitae 5Kw & 8Kw Landscape V1 – 7-6-17...
-
Page 3: List Of Components
2.3 Now proceed to install the stove according to these instructions and current installation standards or HETAS advice. The internal parts of the stove can be re-assembled as the reverse of the previous removal instructions. Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... -
Page 4: Stove Commissioning Checklist
Name: ………………………………………………………………………….. Address: ………………………………………………………………………… …………………………………………………………………………………… Telephone Number: ……………………………………………………………... Complete upon stove installation Date of Installation: …………………………………………………… Model Number: (Vitae 5Kw / 8Kw Landscape …………………... Serial Number: ………………………………………………………… Fitter/Plumber Name: ………………………………………………………………….. Address: ………………………………………………………………... Telephone Number: ……………………………………………………. Commissioning Checklist – Installer to complete and sign-off... -
Page 5: Installation Instructions
Handling Adequate facilities must be available for unloading and site handling. Heat Design Cassette Stoves are very heavily built so always ask for assistance when lifting and siting the stoves. Fire Cement Some types of fire cement are caustic and should not be allowed to come into contact with the skin. -
Page 6: Installation Information
Please consult HETAS recommended fitting methods if in doubt. It is essential that all connections between the stove and chimney-flue are sealed and made airtight with sealing rope, clamping rings and/or fire cement or heat resisting cement where required. Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... -
Page 7: Fitting The Stove
Note the height of the flue collar of the stove and cut the flexi flue to length accordingly and fit a flexi- Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... - Page 8 For the glass frame the outer casing should sit proud of the opening by 10mm, Ref fig 6. In the case of the flat frame the outer casing should finish flush with the opening. Vitae 5Kw & 8Kw Landscape V1 – 7-6-17...
- Page 9 Advise the user on what to do should smoke or fumes be emitted into the room from the stove – see Safety Notes section. The user should be warned that they MUST use a suitable fireguard in the presence of children, aged and/or infirm persons. Vitae 5Kw & 8Kw Landscape V1 – 7-6-17...
- Page 10 Vitae 5Kw & 8Kw Landscape V1 – 7-6-17...
-
Page 11: Technical Data
Flue Outlet Size (Inch) Fuel Consumption (kg/hr) 1.33 380mm 580mm Max Log Length: Weight 90kg 105kg Recommended Fuel Kiln / Seasoned wood with moisture content of less than 20% *Average reading at nominal output Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... -
Page 12: Operating Instructions
Lining boards are not covered by warranty, as they are a wearing consumable part. Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... -
Page 13: Fuels
Note: To eliminate unwanted smoke emission, after loading new logs on to the fire, open the air wash control up fully for 1-2 minutes to boost the fire and get flames issuing from the top of the fuel as soon as Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... -
Page 14: Shutting Down
Any unauthorised modifications of this appliance will render the guarantee null and void and could be potentially dangerous. Replacement parts should only be sourced from Heat Design approved dealers CO ALARMS Building Regulations require that whenever a new or replacement fixed solid fuel or wood/biomass... - Page 15 If the wall is becoming hot, move the furniture away. Ensure that the Fire Brigade can gain access to your roof space in order to check this area for signs of fire spread. Vitae 5Kw & 8Kw Landscape V1 – 7-6-17...
-
Page 16: Frequently Asked Questions
"red" your stove is over firing and your draught control should be adjusted to restrict airflow to stove. Over firing can cause permanent damage to the appliance, which is not covered by warranty. Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... -
Page 17: Spare Parts List & Codes: Vitae 5Kw Landscape
Collar Y1HDL26E Door Latch roller Y1VTCD61A Four sided trim for cassette – metal only Ashpan Y1HDCD28B Y1VTL05D67A Stove Tool Y1VTCD24B Four Sided Flat Trim (4mm Thick) Y1VTL05D85A Door Y1VTL05D32A Angled Brick Y1VTL05D86A Vitae 5Kw & 8Kw Landscape V1 – 7-6-17... -
Page 18: Spare Parts List & Codes: Vitae 8Kw Landscape
Four Sided Flat Trim (4mm Thick) Y1VTL08D85A Door Y1VTL08D32A Angled Brick Y1VTL08D86A Heat Design, 30 – 60 Hawthorn Road, Western Industrial Estate, Naas Road, Dublin 12 T: 01 408 9192 F: 01 408 9193 Vitae 5Kw & 8Kw Landscape V1 – 7-6-17...
