- Page 1 Vercise Charging Handbook 92093582-01 Content: 92093655 REV B CAUTION: Federal law restricts this device to sale, distribution and use by or on the order of a physician.
-
Page 2: Additional Information
Trademarks All trademarks are the property of their respective holders. Guarantees Boston Scientific Corporation reserves the right to modify, without prior notice, information relating to its products in order to improve their reliability or operating capacity. Additional Information Refer to the Vercise DBS System Patient Manual, for additional instructions and information about your DBS system. - Page 3 Charging Your Stimulator ......................8 Using the Charging Collar ......................8 Using the Adhesive Patch .......................10 Properly Aligning the Charger ....................11 Tips for Properly Aligning the Charger ..................12 Cleaning Instructions .......................14 Technical Support ...........................15 Vercise DBS Charging Handbook 92093582-01 Page iii of iv...
- Page 4 Vercise DBS Charging Handbook This page intentionally left blank Vercise DBS Charging Handbook 92093582-01 Page iv of iv...
-
Page 5: Introduction
Introduction Introduction The Boston Scientific DBS System is used for deep brain stimulation (DBS), a reversible therapy where structures in the brain are stimulated with small electrical pulses. The Boston Scientific DBS System includes a rechargeable stimulator that will require periodic recharging. -
Page 6: Using The Charging System
Failure to recharge may lead to loss of stimulation. After stimulation stops, communication with the Stimulator will also cease until a sufficient level of charge has been attained. Refer either to your Vercise DBS Patient Manual or your Remote Control Handbook for more information. - Page 7 Stimulator will lose its ability to recover its full capacity. As a result, over time, the Stimulator may require shorter intervals between charges. The Stimulator will need replacement when stimulation can no longer be maintained with routine charging. Vercise DBS Charging Handbook 92093582-01 Page 3 of 15...
-
Page 8: Getting Set Up
DBS Charging Handbook Getting Set Up Check that you have received all the components below, which are included in your DB-64125-US Vercise Charging System. If any item is missing, please call the Boston Scientific Customer Service department for a replacement. -
Page 9: Charging The Charger
2. Plug the Power Supply into a standard AC wall outlet. 3. Connect the Power Supply to the Base Station. 4. Place the Charger in the Base Station with the power button facing up. Vercise DBS Charging Handbook 92093582-01 Page 5 of 15... - Page 10 Vercise DBS Charging Handbook The Charger is ready to fully charge your Stimulator when the indicator light is green. If the light is yellow, the Charger can only partially charge the Stimulator. It may be used, but it may not be able to return your Stimulator to a full charge (and you may need to charge sooner than usual).
-
Page 11: Understanding The Charger Sound Alerts
Beep shown in the section Properly Aligning the Charger. The Charger has fully charged the Repeated Double Stimulator battery. Turn off the Charger Beep and return it to the Base Station. Vercise DBS Charging Handbook 92093582-01 Page 7 of 15... -
Page 12: Charging Your Stimulator
Vercise DBS Charging Handbook Charging Your Stimulator When charging, you must use the Charger with either the Charging Collar or an Adhesive Patch to hold the Charger over the Stimulator. The Adhesive Patches are made of non-reactive and natural Latex-free material suitable for most sensitive skin types. - Page 13 Charging Collar using the straps. Occasionally checking that the Charger is aligned over the Stimulator during your charging session is recommended. Note: The Charging Collar can be placed under or over clothing. You should not wear tight fitting or heavy clothing over the Charger while charging to allow air flow around the Charger. Note: Do not use the Charging Collar when it is wet or damp. Vercise DBS Charging Handbook 92093582-01 Page 9 of 15...
-
Page 14: Using The Adhesive Patch
Vercise DBS Charging Handbook Using the Adhesive Patch When the indicator light is green, remove the Charger from the Base Station. (The indicator light will go off, regardless of the ready status of the Charger.) Apply the Adhesive Patch to the backside of the Charger by peeling the clear liner from the patch and applying the white side with the blue stripe to the rear of the Charger, as shown. -
Page 15: Properly Aligning The Charger
Note: If the Adhesive Patch is accidentally located in the wrong place, or if the Charging Collar moves out of alignment, the Charger will start beeping again. Use a new Adhesive Patch or readjust the Charging Collar to place the Charger back into the fully aligned position. Vercise DBS Charging Handbook 92093582-01 Page 11 of 15... -
Page 16: Tips For Properly Aligning The Charger
Vercise DBS Charging Handbook Note: Moving around while charging is acceptable, but be aware that the Charger must stay centered over the Stimulator for proper charging. Excessive movement may cause the Charger and Stimulator to become misaligned. When the Charger emits a distinct double beep, press the power button to turn off the Charger and check the Stimulator’s battery with the Remote Control. - Page 17 12 Slowly move the Charger down, towards the Stimulator. 13 Stop moving the Charger when it stops beeping. 14 Make a mark on your skin at the bottom edge of the Charger, as shown. Vercise DBS Charging Handbook 92093582-01 Page 13 of 15...
-
Page 18: Cleaning Instructions
Vercise DBS Charging Handbook 15 Place the Charger below the Stimulator. 16 Slowly move the Charger up, towards the Stimulator. 17 Stop moving the Charger when it stops beeping. 18 Make a mark on your skin at the top edge of the Charger, as shown. -
Page 19: Technical Support
Technical Support There are no user serviceable parts. If you have a specific question or issue, please contact your healthcare professional. If you need to contact Boston Scientific for any other reason, please call (833) DBS-INFO or (833) 327-4636. Vercise... - Page 20 EU Authorized Representative Australian Sponsor Address Legal Manufacturer Boston Scientific Neuromodulation Corporation Boston Scientific (Australia) Pty Ltd Boston Scientific Limited 25155 Rye Canyon Loop PO Box 332 Ballybrit Business Park Valencia, CA 91355 USA BOTANY Galway, Ireland (866) 789-5899 in US and Canada...
