Page 1
Help to protect the environment, take the packaging to the local amenity tip and place into the appropriate recycling bin. FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: 03688 TEL: 01509500400 EMAIL: sales@sip-group.com or technical@sip-group.com Please read and fully understand the instructions in this manual www.sip-group.com...
Page 2
LE12 9NH England As the manufacturer's authorised representative within the EC declare that the 3.25 Ton Heavy Duty Floor Jack - SIP Part No. 03688 Conforms to the requirements of the following directive/s, as indicated. 2006/42/EC Machinery Directive And The Relevant Harmonised Standard/s, including EN 1494+A1:2008 Signed: …………………………………...
Page 3
PARTS LIST CONTENTS Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. Piston adaptor HY01-00340 Lock washer HY01-00363 Roller pin HY01-00341 Screw HY01-00364 Page No. Description Spring HY01-00342 Screw HY01-00365 Safety Symbols Used Throughout This Manual HY01-00343...
Page 4
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL EXPLODED DRAWING Danger / Caution: Indicates risk of personal injury and/or the possibility of damage. Note: Supplementary information. SAFETY INSTRUCTIONS Important: Please read the following instructions carefully, failure to do so could lead to serious personal injury and / or damage to the trolley jack.
Page 5
TROUBLESHOOTING SAFETY INSTRUCTIONS….cont WARNING! Only operate on a level and stable surface and never use on soft ground where the jack is likely to “sink” whilst in operation. NEVER STAND ON THE JACK: The jack is not designed for this purpose. DO NOT dismantle or tamper with the jack, as this may be dangerous and will invali- date the warranty.
Page 6
500mm higher than the rear of the jack. This SIP hydraulic jack is covered by a 24 month parts and labour warranty covering Caution: Due to the weight of the jack, at least 2 persons are required to failure due to manufacturers defects.
Page 7
MAINTENANCE TECHNICAL SPECIFICATIONS ADDING OIL Ensure that the jack is placed on a level surface. Lower the saddle to its lowest position (turn the handle anti-clockwise). Loosen (do not remove) the 4 cap head bolts that hold the service cover on and remove the cover.
Page 8
GETTING TO KNOW YOUR JACK OPERATING INSTRUCTIONS….cont Note: Follow the vehicle manufacturer’s recommended guidelines for lift- ing. Engage the emergency brake and chock each un-lifted wheel in both directions to prevent inadvertent vehicle movement. Rubber Pad Push the top handle into the lower handle, use the handle screw to secure both Handle parts together.
