Please dispose of packaging for the product in a responsible
manner. It is suitable for recycling. Help to protect the
environment, take the packaging to the local amenity tip and
place into the appropriate recycling bin.
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: 01509500400
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
Ref: 271115
20
5 Ton & 10 Ton
Long Floor Jack
03642 & 03647
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
Advertisement
Table of Contents
Related Manuals for SIP 03642
Summary of Contents for SIP 03642
- Page 1 FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: 03642 & 03647 TEL: 01509500400 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com...
- Page 2 As the manufacturer's authorised representative within the EC declare that the 5 Ton Long Floor Jack - SIP Part Number 03642 10 Ton Long Floor Jack - SIP Part Number 03647 Conforms to the requirements of the following directive/s, as indicated.
- Page 3 Safety Symbols Used Throughout This Manual Safety Instructions Guarantee Technical Specifications Getting to Know Your Floor Jack Operating Instructions Maintenance Troubleshooting Exploded Drawing - 03642 Parts List - 03642 Exploded Drawing - 03647 Parts List - 03647 Declaration of Conformity...
-
Page 4: Safety Symbols Used Throughout This Manual
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL NOTES Danger / Caution: Indicates risk of personal injury and/or the possibility of damage. Note: Supplementary information. SAFETY INSTRUCTIONS IMPORTANT: Please read the following instructions carefully, failure to do so could lead to serious personal injury and / or damage to the Floor Jack. - Page 5 SAFETY INSTRUCTIONS….cont WARNING! Only operate on a level and stable surface and never use on soft ground Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. where the Floor Jack is likely to “sink” whilst in operation.
-
Page 6: Guarantee
GUARANTEE This SIP Floor Jack is covered by a 12 month parts and labour warranty covering failure due to manufacturers defects. This does not cover failure due to misuse or operating the Floor Jack outside the scope of this manual - any claims deemed to be outside the scope of the warranty may be subject to charges Including, but not limited to parts, labour and carriage costs. -
Page 7: Technical Specifications
PARTS LIST - 03642 TECHNICAL SPECIFICATIONS Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. 1-1. Frame HY01-00510 1-19. Shaft HY01-00528 1-2. Front wheel HY01-00511 1-20. Washer HY01-00529 1-3. Washer HY01-00512 1-21. HY01-00530 1-4. Snap ring HY01-00513 1-22. -
Page 8: Operating Instructions
/ agent (contact distributor or SIP for a list of authorised service centres). It is recommended that an annual inspection be done by a qualified per-son/s. - Page 9 TROUBLESHOOTING OPERATING INSTRUCTIONS….cont Note: Follow the vehicle manufacturer’s recommended guidelines for lift- ing. Engage the emergency brake and chock each un-lifted wheel in both directions to prevent inadvertent vehicle movement. 1. Push the handle into the handle base, use the bolt, washer and nut in the handle Symptom Possible Causes Corrective Action...
-
Page 10: Maintenance
Recommended Oil - ISO 15. be bled. To bleed air from the hydraulic system, follow the instructions below. Oil Capacity - 03642 480ml (approx.) 03647 - 1050 ml (approx.). 1. Remove the oil fill bung. 2. Insert the handle into the handle base.
