22 Ton Pneumatic Floor Jack
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
03643
Advertisement
Table of Contents
Related Manuals for SIP 03643
Summary of Contents for SIP 03643
- Page 1 It is suitable for recycling. Help to protect the environment, take the packaging to the local amenity tip and place into the appropriate recycling bin. FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: 03643 TEL: 01509500400 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com...
- Page 2 LE12 9NH England As the manufacturer's authorised representative within the EC declare that the 22 Ton Pneumatic Floor Jack - SIP Part Number 03643 Conforms to the requirements of the following directive/s, as indicated. 2006/42/EC Machinery Directive And The Relevant Harmonised Standard/s, including EN 1494+A1:2008 Signed: …………………………………...
-
Page 3: Table Of Contents
NOTES CONTENTS Page No. Description Safety Symbols Used Throughout This Manual Safety Instructions Guarantee Technical Specifications Getting to Know Your Floor Jack Assembly Instructions Operating Instructions Maintenance Troubleshooting Exploded Drawing Parts List Declaration of Conformity... -
Page 4: Safety Symbols Used Throughout This Manual
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL NOTES Danger / Caution: Indicates risk of personal injury and/or the possibility of damage. Note: Supplementary information. SAFETY INSTRUCTIONS IMPORTANT: Please read the following instructions carefully, failure to do so could lead to serious personal injury and / or damage to the Floor Jack. - Page 5 SAFETY INSTRUCTIONS….cont WARNING! Only operate on a level and stable surface and never use on soft ground Ref. No. Description SIP Part No. Ref. No. Description SIP Part No. where the Floor Jack is likely to “sink” whilst in operation.
-
Page 6: Guarantee
GUARANTEE This SIP Floor Jack is covered by a 12 month parts and labour warranty covering failure due to manufacturers defects. This does not cover failure due to misuse or operating the Floor Jack outside the scope of this manual - any claims deemed to be outside the scope of the warranty may be subject to charges Including, but not limited to parts, labour and carriage costs. -
Page 7: Technical Specifications
TROUBLESHOOTING TECHNICAL SPECIFICATIONS Lifting Capacity 22 Ton 110 x 50 mm Ø Minimum Height 230 mm 50 x 50 mm Ø Adaptor sizes Ram Stroke 120 mm 20 mm x 50 mm Ø Symptom Possible Causes Corrective Action Screw Extension 115 mm 20 mm x 70 mm Ø... -
Page 8: Assembly Instructions
ASSEMBLY INSTRUCTIONS MAINTENANCE….cont FITTING THE HANDLE LUBRICATION Fit the bottom half of the handle into the handle socket ensuring that the han- A periodic coating of light lubricating oil to pivot points, axles and hinges will help to dle lock / release control is also fitted into its bracket (Fig. 1). prevent rust and assure that wheels, castors and pump assemblies move freely. - Page 9 MAINTENANCE….cont ASSEMBLY INSTRUCTIONS….cont 4. Return the jack to an upright position. Slide the upper handle over the lower handle and secure in place with the han- 5. Fill with hydraulic oil until the oil reaches the bottom of the oil fill hole. dle screw (Fig 3).
-
Page 10: Operating Instructions
/ agent (contact distributor or SIP for list of authorised service centres). It is recommended that an annual inspection be done by a qualified person/s.
Need help?
Do you have a question about the 03643 and is the answer not in the manual?
