42" (3) Burner Pro Built-In Grill CGP42-2G-1SR-L-(WH) and CRCD41 Combo 2X Drawer plus Dual Tank/Trash slides.
Caliber Crossflame™ Pro Series Outdoor Grills
Models:
42" 3 BURNER GRILL:
CGP42-2G-1SR-L/N-(WH); (2) grill burners, (1) sear burner,(1) rotisserie burner, Wood Handle
Option(WH)
60" 3 BURNER GRILL with integral Dual Power Pro Side Burners:
CGP60-2G-1SR-2SB-L/N-(WH); (2) grill burners, (1) sear burner,(1) rotisserie burner, (2) Power
Pro Side Burners, Wood Handle Option(WH)
Installation + Use/Care Instructions
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CGP42-2G-1SR-L and is the answer not in the manual?

Questions and answers

Related Manuals for Caliber CGP42-2G-1SR-L

Summary of Contents for Caliber CGP42-2G-1SR-L

  • Page 1 Appliances 42” (3) Burner Pro Built-In Grill CGP42-2G-1SR-L-(WH) and CRCD41 Combo 2X Drawer plus Dual Tank/Trash slides. Caliber Crossflame™ Pro Series Outdoor Grills Models: 42” 3 BURNER GRILL: CGP42-2G-1SR-L/N-(WH); (2) grill burners, (1) sear burner,(1) rotisserie burner, Wood Handle Option(WH) 60”...
  • Page 2 DANGER: AVERTISSEMENT S’IL Y A UNE ODEUR DE GAZ: If you smell gas: 1. Shut off gas to the grill. 1. Coupez l’admission de gaz de l’appariel. 2. Extinguish any open flame. 2. Éteindre toute flamme nue. 3. Open Lid. 3.
  • Page 3 Table of Contents Pages 3-6 Care and Safety Precautions Pages 7-9 Grill Placement and Installation Pages 10-14 Gas Requirements, Pressure Testing and Hookups Pages 15-17 Leak Testing Page 18 Electrical Connections Page 19 Air Shutter Adjustments Pages 20-22 Lighting, Match Lighting Instructions Page 23 Using the Rotisserie Page 24...
  • Page 4 Getting to know your Caliber Grill: (not all features available on all models - CGP60-2G-1SR-2SB model shown below)
  • Page 5 SAFETY PRACTICES TO AVOID PERSONAL INJURY! When properly cared for, your Caliber grill will give safe and reliable service for many years. However, extreme care must be used since the grill produces intense heat and can increase accident potential. When using your grill, basic safety prac-...
  • Page 6 POT HOLDERS » Use only dry pot holders: moist or damp pot holders on hot surfaces may cause burns from steam. Do not use a towel or bulky cloth in place of pot holders. Do not let pot holders touch hot portions of the grill rack. GREASE »...
  • Page 7 WARNING! Spiders and insects can nest in the grill burners , causing gas not to flow through the burner. The gas will flow from the front of the burner into the control panel. This is a very dangerous condition which can cause a fire to occur behind the valve panel, thereby damaging the grill components and making it unsafe to operate.
  • Page 8 » To avoid burns when cooking, use long handled BBQ tools. » Do not move the appliance during its use. » This unit is for outdoor use only! Do not operate in enclosed areas. This could result in carbon monoxide build-up which would result in injury or death.
  • Page 9 GRILL PLACEMENT AND INSTALLATION Clearance to non-combustible construction*: A minimum of 3” clearance from the back of the grill to non-combustible construction is required for the lid to open freely. It is desirable to allow at least 6” rear and side clearance to non- combustible construction above the cooking surface for counter space.
  • Page 10 During heavy use, the grill will produce considerable smoke. therefore, locate the grill in a well-ventilated area. Never locate the grill in a building, garage, breezeway, shed or other such enclosed areas without an approved ventilation system for outdoor use. If installing grill in an island in an open area, without suitable protection from windy conditions, a windbreak MUST be created to ensure proper performance of the grill.
  • Page 11 GRILL PLACEMENT AND INSTALLATION - cont’d The grill is designed for easy placement into built-in masonry enclosures. For non-combustible applications the grill drops into the opening shown below and hangs from its side flanges. A deck is not required to support it from the bottom. A carpenter’s “spirit level”...

  • Page 12: Gas Requirements

    GAS REQUIREMENTS Verify the type of gas supply to be used, either natural or LP, and make sure the marking on the appliance rating plate agrees with that of the supply. The rating plate is located underneath the unit bottom. Never connect an unregulated gas line to the appliance.
  • Page 13 42” GRILL LP GAS HOOK UP (TYPE 1 OR QCC1 REGULATOR): Grills orificed for use with LP gas come equipped with a high capacity hose/regulator assem bly for connection to a standard 20 lb. LP cylinder (Type 1). The LP tank is not included. Connection: 1/2”...
  • Page 14 LP TANK RESTRAINT FOR BUILT-IN INSTALLATION If the grill is to be installed in a Built-in application, then the grill must be installed in accordance with the Built–in instal- lation guidelines. If you intend to operate your Built-in grill on LP gas utilizing a 20 lb Type 1 cylinder, then the Built-in LP tank restraint must be installed prior to initial use of the grill.
  • Page 15 60” GRILL LP GAS HOOK UP (TYPE 1 OR QCC1 REGULATOR): The Caliber 60” Grill orificed for use with LP gas come equipped with a high capacity hose/regulator assembly for connec- tion to a standard 20 lb. LP cylinder (Type 1). The LP tank is not included.
  • Page 16 PRESSURE TESTING AND HOOKUPS CAUTION! Use grill only in NON-COMBUSTIBLE enclosures. DO NOT build grill into a combustible enclosure. PRESSURE TESTING » The appliance and its individual shut off valve must be disconnected from the gas supply piping system during any pressure testing of that system, at test pressures in excess of 1/2 PSIG (3.5 kPa).

  • Page 17: Leak Testing

    LEAK TESTING GENERAL » Although all gas connections to the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed at the installation site due to possible mishandling in shipment, or excessive pressure unknowingly applied to the unit.
  • Page 18 Check all gas supply fittings for leaks before each use: 42” Grill LP Gas: Leak test points Leak test points Leak test point Lp tank 42” Grill Nat. Gas: nG safety shut off vaLve Leak test points Leak test points Leak test point...
  • Page 19 LEAK TESTING - cont’d. 60”GRILLS: 60” Grill Nat. Gas: natuRaL Gas ConfiGuRation Leak test point Leak test point shut off vaLve to natuRaL Gas suppLy Leak test point Main Gas suppLy 60” Grill LP Gas: Leak test point Lp Gas ConfiGuRation Leak test 2 staGe...

  • Page 20: Electrical Connections

    ELECTRICAL CONNECTIONS GENERAL » The Caliber Crossflame Pro Grill is equipped with a 110V electronic ignition system along with 12V panel lighting and interior/exterior lighting. Included with each Pro Grill is an electrical box that is pre-wired and ready for connect- ing to the 2 leads from the grill (110V(#2 in the illustration) and 12V(#1 in the liiustration)).
  • Page 21 AIR SHUTTER ADJUSTMENTS BURNER AIR SHUTTER ADJUSTMENT » Each burner air shutter is tested at the factory prior to shipment; however, variations in the local gas supply may make it necessary to adjust the air shutters. The flames of the burners should be visibly checked. »...

  • Page 22: Lighting Instructions

    LIGHTING INSTRUCTIONS BEFORE TURNING ON THE BURNERS » Ensure that all packaging material has been removed » Ensure that the grill has been leak tested and is properly located » Check that the radiant trays and grill racks are properly seated »...

  • Page 23: To Match Light The Grill

    TO MATCH LIGHT THE GRILL If the burners do not light after several attempts, then the grill burners, rotisserie burner, or side burners(on some mod- els) may be match lit using a long stem match and the provided match holder arm. Attach the match to the lighter arm which is attached to the drip pan handle and light it.

  • Page 24: Using The Grill

    TO MATCH LIGHT THE GRILL(continued) Below: To match Light the Power Pro Top Burner (Single or Dual) Below: To match Light the Grill Sear Burner USING THE GRILL Grilling requires high heat for searing and proper browning. Most foods are cooked at the “medium” setting for the entire cooking time.

  • Page 25: Using The Rotisserie

    USING THE ROTISSERIE TO LIGHT ROTISSERIE (if equipped) Open the lid, push and turn the knob to the “HI” position. You will hear a single snap sound at the burner control knob which is the ignition switch sending a spark to the flame electrode mounted under the stainless steel box to the left of the rotisserie burner.
  • Page 26 USING THE POWER PRO™ TOP BURNERS TO LIGHT THE POWER PRO™ TOP BURNER (if equipped) Note: On most models there is a front and rear burner operated with independent knobs. When lighting these Top Power Burners, make sure that you are using the intended knob for ignition and use of the front or rear burner. Open the grill lid, remove the Power Pro™...

  • Page 27: Care And Maintenance

    CARE AND MAINTENANCE GRILL RACKS It is recommended that the grill racks be cleaned immediately after grilling, AFTER the flame has been turned off. Be sure to wear a barbecue mitt to protect your hands from the heat and steam. Dip a wire brush in tap water and scrub the hot grill racks.
  • Page 28 Any part determined by Caliber to be defective will be repaired or replaced free of charge with the owner paying all other costs including freight and labor.
  • Page 29 AVERTISSEMENT S’IL Y A UNE ODEUR DE GAZ: » Coupez l’admission de gaz de l’appariel. » Éteindre toute flamme nue. » Ouvrir le couvercle. » Si l’odeur persiste, appeler immédiatement votre compagnie de gaz ou votre département des incendies. AVERTISSEMENT »...
  • Page 30 » Empêcher les enfants de manipuler la bouteille ou de jouer avec. » Lorsque la bouteille n’est pas raccordée à l’appareil, en maintenir fermé le robinet. Pour les appareils de cuisson auto- nomes d’exténeur, utiliser une bouteille d’une capacité maximale de 9 kg (20 lb). »...
  • Page 32 Because of continuous product improvement, Caliber reserves the right to modify any product specifications. All material contained herein may not be reproduced without prior written consent of Caliber Appliances. Copyright 2017 CA L IBE RA PP L I A NC ES . CO M...
