Outdoor Temperature/Humidity Display
2
1
6
1. Outdoor signal strength indicator
2. Outdoor indicator
3. Outdoor humidity
4. Hi / Lo Alert and Alarm
5. Outdoor temperature
6. Low battery indicator for sensor
12+ Hour Forecast Display
1. Weather forecast indicator
2. Weather forecast icon

Barometer Display

1. Barometer indicator
2. Histogram
3. Absolute/Relative indicator
4. Barometer units (hPa / inHg / mmHg)
5. Barometer reading
6. Hourly records indicator

Rainfall Display

1. Rainfall indicator
2. Time range record indicator
3. Day records indicator
4. Histogram
5. Hi Alert and Alarm
6. Current rainfall rate
7. Rainfall unit (in / mm)
6
3 4 5
1
2
1
2
1
2
3
4
WTH600-en-US_v1.0 8/17
