OPERATING INSTRUCTIONS Basic Guide Personal Computer CF-D1N series Model No. Contents Getting Started Introduction ..............Description of Parts ............ First-time Operation ............ Turning On / Turning Off........... Useful Information Handling and Maintenance ........Installing Software ............ Troubleshooting Troubleshooting (Basic)..........Appendix LIMITED USE LICENSE AGREEMENT .... -
Page 2: Introduction 4
Introduction Thank you for purchasing this Panasonic product. For optimum performance and safety, please read these instructions carefully. In these instructions, the names are referred as follows. indicates Windows 10 Operating System. indicates Windows 7 Operating System. n Terms and illustrations in these instructions Conditions that may result in minor or moderate injury. - Page 3 To access the on-screen manuals, follow the steps below. Double-touch [Manual Selector] on the desktop, and select the on-screen manual. 1. Double-touch the [Panasonic PC Settings Utility] on the desktop screen, and then touch [Support] - [Manual] - [Launch Manual Selector].
-
Page 4: Description Of Parts
Description of Parts Front side Bottom and rear side C D E F G A: Tether Hooks I: Bluetooth Antenna The tether hooks are not provided for some models. <Only for model with Bluetooth> B: Tablet Buttons Connect to a network “Bluetooth” è... - Page 5 Right side Left side Parts (F) illustrated below are all optional. To set the wireless switch to ON, slide and align it to the mark. A: DC-IN Jack I: USB3.0 Port B: LAN Port Reference Manual “USB Devices” è Reference Manual “LAN”...
- Page 6 Description of Parts l This computer contains a magnet and magnetic products at the location cir- cled in the illustration at right. Avoid leaving metallic object or magnetic media in contact with this area. n Attaching the stylus to the computer <Only for model with tether> The tether prevents the stylus (included) from falling accidentally.
- Page 7 A Check and identify the supplied accessories. If you do not find the described accessories, contact Panasonic Technical Support. y AC Adaptor ..1 y AC Cord ....1 y Battery Pack .
- Page 8 First-time Operation Inserting the Battery Pack (è page 7) l Do not touch the terminals of the battery pack and the computer. Doing so can make the terminals dirty or damaged, and may cause malfunction of the battery pack and the computer. l Be sure to attach the cover for use.
- Page 9 Restart the computer A Touch (Start) . B T ouch (Power) - [Restart]. l A portion of the Panasonic PC Settings Utility functions will be enabled after the computer restarts. Update the on-screen manual A Connect to the internet. Sign in / Log on to Win- dows as an administrator.
- Page 10 NOTE Panasonic PC Settings Utility You can check the status of the computer, and change the settings. Double-touch [Panasonic PC Settings Utility] on the desktop to start the utility. (è Reference Manual “Panasonic PC Settings Utility”) l PC Information Viewer This computer periodically records the management information of the hard disk, etc.
- Page 11 Turning On / Turning Off Turning On Press and hold the power switch (è page 4) until the power indicator (è page 4) lights. NOTE l Do not press the power switch repeatedly. l The computer will forcibly be turned off if you press and hold the power switch for four seconds or longer. l Once you turn off the computer, wait for ten seconds or more before you turn on the computer again.
-
Page 12: Handling And Maintenance
Handling and Maintenance Operation environment l Place the computer on a flat stable surface not subject to shock, vibration, and danger of dropping. Do not place the computer upright or turn it over. If the computer is exposed to an extremely strong impact, it may become dam- aged. - Page 13 n PC-Diagnostic Utility When you start the PC-Diagnostic Utility without connecting an external keyboard and an external mouse, shut down the computer by pressing and holding the power switch. Then, connect an external keyboard and an external mouse to the computer and restart the PC-Diagnostic Utility. Maintenance To clean the LCD panel Use the soft cloth included with the computer.
-
Page 14: Installing Software
Installing Software Installing software will return the computer to the default condition. When you install the software, the hard disk data will be erased. Back up important data to other media or an external hard disk before installation. CAUTION l Do not delete the Recovery Partition on the hard disk. If it has been deleted, the Recovery Disc could not be cre- ated. - Page 15 Turn on the computer, and touch [Click here for Setup] that appears at the top left corner of the screen while [Panasonic] boot screen is displayed. l If the [Panasonic] boot screen is not displayed, as soon as the computer starts up, press several times until the Setup Utility screen appears.
- Page 16 Turn on the computer, and touch [Click here for Setup] that appears at the top left corner of the screen while [Panasonic] boot screen is displayed. l If the [Panasonic] boot screen is not displayed, as soon as the computer starts up, press several times until the Setup Utility screen appears.
- Page 17 Press several times while [Panasonic] boot screen is displayed. The Setup Utility starts up. l If the password is requested, enter the Supervisor Password. Touch [Exit] and double-touch your DVD drive in [Boot Override]. The computer will restart. Touch [Recovery] and touch [Next].
-
Page 18: Troubleshooting (Basic)
Follow the instructions below when a problem has occurred. There is also an advanced troubleshooting guide in the “Reference Manual”. For a software problem, refer to the software’s instruction manual. If the problem persists, contact Panasonic Technical Support. You can also check the computer’s status in the PC Information Viewer (è Refer- ence Manual “Checking the Computer’s Usage Status”). - Page 19 B Touch [Clock, Language, and Region] - [Date and Time]. l If the problem persists, the internal clock battery may need to be replaced. Contact Panasonic Technical Support. l When the computer is connected to LAN, check the date and time of the server.
- Page 20 Panasonic PC Settings Utility / Dashboard for Panasonic PC. As you increase the brightness, battery consumption increases. You can separately set the brightness for when the AC adaptor is connected and when not connected. The screen is disordered.
- Page 21 n On-screen Document l Install Adobe Reader. A Log on to Windows as an administrator. The document of PDF for- B Press (A2) button. mat is not displayed. Input Keyboard screen appears. C Touch (Start) and input “c:\util\reader\en\pinstall.bat” in [Search programs and files], then press Enter .
-
Page 22: Limited Use License Agreement
DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE. Panasonic Corporation has developed or otherwise obtained the Programs and hereby licenses their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to achieve your intend- ed results, and for the installation, use and results obtained therefrom. - Page 23 “Reference Manual”. At least three (3) years from delivery of this product, Panasonic will give to any third party who contacts us at the contact information provided below, for a charge no more than our cost of physically performing source code distribution, a complete machine-readable copy of the corresponding source code covered under GPL V2.0, LGPL V2.1 or the other licenses with the obligation...
-
Page 24: Specifications
Specifications This page provides the specifications for the basic model. The model number is different according to the unit configu- ration. l To check the model number: Check the bottom of the computer or the box the computer came in at the time of purchase. l To check CPU speed, memory size and the hard disk drive (HDD) size: Run the Setup Utility (è... -
Page 25: Main Specifications
*8*22 , Wireless Switch Utility, Wireless Connection Disable Utility , Calibration Utility, Dash- board for Panasonic PC, Display Rotation Tool, Tablet Button Manager, Software Keyboard, Power Plan Extension Utility Aptio Setup Utility, Hard Disk Data Erase Utility , PC Diagnostic Utility... - Page 26 For information on TPM, Double-touch [Manual Selector] on the desktop, and select “Installation Manual for Trusted Platform Module (TPM)”. Operation has been tested and confirmed using Panasonic SD/SDHC/SDXC Memory Cards with a capacity of up to 64 GB. Operation on other SD equipment is not guaranteed.
