Stereo/Mono Output

The Matrix Infinity Mic Blend can be used in mono or stereo output simply by
choosing the appropriate cable. For a blended mono output use a standard ¼"
to ¼" instrument cable. For stereo operation, use a TRS to TRS or a TRS to stereo
"Y" cable and set the Blend control to 100% pickup.
In stereo with Blend set to pickup, the mic signal will be present on the output
jack Ring and the pickup signal on the Tip. The Volume control is stereo and
acts simultaneously for both Tip and Ring, allowing volume adjustments without
altering the external blend.
