- Page 1 PX376 HD Multimedia Player USER MANUAL...
- Page 2 11. Technical data..................Declaration of conformity................Manufacturer reserves the right to make modifications in order to improve device operation. tel.: (12) 626 46 92 PXM Marek Żupnik spółka komandytowa fax: (12) 626 46 94 Podłęże 654 E-mail: info@pxm.pl 32-003 Podłęże ver.
-
Page 3: General Description
1. GENERAL DESCRIPTION PX376 is a multimedia player controlled by DMX protocol. The player allows you to play the video files in Full HD, audio files and images. In case of the loss of DMX signal, it can operate independently according to the pre-programmed settings. The device is equipped with DMX input and output, 4 USB ports, HDMI and Micro USB interfaces. -
Page 4: Player Construction
3. PLAYER CONSTRUCTION Device style: Micro USB analogue output power input HDMI output FRONT: 4 USB ports 10/10TX Ethernet port SECOND SIDE: P U S H DMX IN DMX OUT... -
Page 5: Supported File Formats
1. Open an installation file, click [Next] to go to the PX376 setup wizard. The installation file is attached to the driver on a CD, or it is available for download from the website: http://pxm.pl 2. Select the folder in which you want to install the software. Confirm your selection by clicking [Next]. -
Page 6: Structure Of The Application Window
6. STRUCTURE OF THE APPLICATION WINDOW The application window is divided into three panels: - created configuration list - configuration editing panel - list of devices detected in the network configuration editing panel created configuration list list of devices detected in the network 6.1. - Page 7 6.2. Configuration editing panel Configuration comprises device parameters and a list of multimedia files uploaded into the device. The device will be visible on the network under the name assigned to it in the [Device name] field. The PX376 is controlled by 4 consecutive DMX channels. The first of the channels is identified in the [DMX address] field.
- Page 8 [Playlist] – in which you must load all the files to be played by the player and set them in the right order buttons to modify the content of the playlist 6.3. List of devices The list displays all devices that have been browsed through in the network. DMX address change field device rename...
- Page 9 operation mode selection (Play, Stop, Pause) track number selector knob playback mode selection volume adjustment knob Network configuration: if the function is selected, address will be automatically assigned from a DHCP server, if not – a static address will be used IP address, network mask and gateway address - static network parameters of the player...
-
Page 10: Operation Of The Player
To upload the configuration to the device: þ 1. Check the checkbox for an appropriate device on the list, 2. Select the configuration that you want to upload to the device from the configuration selection list [New configuration]. If the same configuration is uploaded to several devices, you can change the name and the DMX address for each device individually. - Page 11 The device is controlled by 4 DMX channels: channel 1: command command value on the channel 0 - 63 stop 64 - 127 pause 128 - 255 play channel 2: track selection track value on the channel 0 - 3 4 - 6 253 - 255 channel 3: playback mode...
-
Page 12: No Signal
7.2. No signal In the absence of DMX signal, the device operates in accordance with the parameters set in the configuration file. That applies to DMX control only. Available commands in the absence of DMX signal: [Play] – playing the highlighted track (from 1 to 85) in a selected mode (track, loop track, playlist, loop playlist, shuffle) with a set volume (0-100%);... - Page 13 4. Create a playlist using: [Add media] – adding a file to the Playlist [Add empty] – adding an empty item to the list If the selected DMX command is to be unassigned to any track, at this point you should add an empty item on the list.
-
Page 14: Connection Scheme
9. CONNECTION SCHEME a) Diagram of connecting the device to a projector with using an HDMI cable DMX controller, e.g. PX333 DMX- DMX+ to further components DMX IN DMX OUT PENDRIVE HDMI Ethernet PROJECTOR HDMI 230 V 5 V DC power supply unit included with the device... - Page 15 b) Diagram of connecting devices to the projector with using the included cable, analog audio- video DMX controller, e.g. PX333 DMX- DMX+ to further components DMX IN DMX OUT PENDRIVE analog Audio R PROJECTOR Video Audio L 230 V 5 V DC power supply unit included with the device...
-
Page 16: Dimensions
10. DIMENSIONS 11. TECHNICAL SPECIFICATION Type: PX376 - control: DMX-512 protocol, UDP - optical isolation of DMX line: - supported file formats: mkv, avi, mpeg, mp4, ogg, wmv, mpg, mp3, jpg, jpeg, png - number of supported files: - image quality: Full HD (1920x1080p) - power supply: 5V DC (power supply unit included) -
Page 17: Declaration Of Conformity
12 626 46 94 30-701 Kraków DECLARATION OF CONFORMITY according to guide lines 2004/108/WE and 2006/95/WE Name of producer: PXM Marek Żupnik sp. k. Manufacturer’s address: ul. Przemysłowa 12 30-701 Kraków We declare that our product: Product name:...
