- Page 1 Care@Home™ Motion Detector User Guide ESUGSC008 Version 2.0 September 2017...
- Page 2 Table of Contents Table of Contents Overview ..............................3 Installing the PIR ............................ 4 2.1. Determining the Best Location ....................4 2.1.1 Basic Location Requirements ..................4 2.1.2 Locations to Avoid......................6 2.1.3 Room Recommendations ..................... 8 2.2. Checking if an Optical Limiter is Required ................10 2.3.
-
Page 3: Overview
Overview 1. Overview The Essence Passive Infrared Detector (PIR) is a battery operated, bi-directional, wireless motion detector. DragonflyEye ™ Lens Figure 1: Essence Passive Infrared Detector Care@Home™ Motion Detector User Guide... -
Page 4: Installing The Pir
Installing the PIR 2. Installing the PIR To install the PIR: Ensure you have one 3 V CR123A lithium battery NOTE: To comply with the UL certification standards, use GP International Ltd. batteries. Determine the best location Check if an optical limiter is required ... - Page 5 Installing the PIR A surface that is clean, dry, and smooth At a height of 2 to 2.2 m (6.6 to 7.2 ft.) Within 400 m (1,312 ft.) of the control panel (CP) NOTE: The PIR has a maximum detection range of 12 m (40 ft.), and maximum detection angles of 90°...
-
Page 6: Locations To Avoid
Installing the PIR 2.1.2 Locations to Avoid The mounting location should not be: On a door frame. Where objects obscure the coverage area, even partially. For example, bookcases or cabinets. A location that has moving objects in the coverage area. - Page 7 Installing the PIR Directly in front of an air conditioner or heat source. Directly opposite a door. For example, if the bathroom PIR is installed facing the door, when the resident passes the open bathroom door through the hallway, the PIR sends a bathroom event to the CP reporting incorrectly that the resident is entering the bathroom...
-
Page 8: Room Recommendations
Installing the PIR As a further example, the following figure shows an apartment with a typical installation with multiple PIRs, avoiding overlapping coverage. Figure 2: Motion Detector Installation Example 2.1.3 Room Recommendations To get the best from the PIR, take account of the following recommendations for mounting locations in different room types. - Page 9 Installing the PIR Combined bathroom A combined bathroom is a bathroom that includes a toilet. Because this type of bathroom includes two types of activities – bathroom and restroom - it is important to ensure that both activities are monitored separately.
-
Page 10: Checking If An Optical Limiter Is Required
Installing the PIR Living and dining room Ensure there is no overlap of the PIR coverage areas when the dining room and living room are combined, or are adjacent and open plan. Install the two PIRs back to back, such that their locations enable separation of the living room and the dining room types of activity event The following figure shows a possible solution for installation when a... -
Page 11: Checking If A Pet Immune Lens Is Required
Installing the PIR NOTE: The coverage area radius for a PIR with an optical limiter is 0.25 times the installation height. For example, if the PIR is installed at a height of 2 m, the coverage area radius is 0.5 m 2.3. - Page 12 Installing the PIR 3. Release the PIR mounting base by lifting the tab and pushing it forward. Figure 7: Release the Mounting Base NOTE: Refer to Using Screws on page 29 for information about installing the PIR using screws. 4. Peel off the protective strips from the mounting tape required for the installation location. For installing in a corner For installing on...
- Page 13 Installing the PIR 5. Press the mounting base into place, ensuring it is the right way up. Bottom Figure 9: Put the Mounting Base the Right Way Up 6. Remove the battery cover by sliding it upwards. Figure 10: Open the Battery Cover Care@Home™...
- Page 14 Installing the PIR 7. If the PIR does not require a pet immune lens or an optical limiter, skip ahead to step 16 on page 19. 8. Unscrew the two screws above the battery compartment at the top of the back cover. Figure 11: Unscrew the Screws 9.
- Page 15 Installing the PIR The following figure shows the front panel and the back cover of the PIR. Front Panel Back Cover Figure 13: PIR Front Panel and Back Cover Caution: Be careful not to damage the internal parts of the PIR. 10.
- Page 16 Installing the PIR b. Insert the pet immune lens into the opening for the lens in the PIR front panel. The pet immune lens fits inside the opening of the PIR. Figure 15: Insert the Pet Immune Lens c. Insert the PIR outer lens, on top of the pet immune lens, in the groove surrounding the opening for the lenses, putting the outer lens latch tabs into the matching holes.
- Page 17 Installing the PIR 11. To install the optical limiter: a. Slide the optical limiter into the flat-end slot at the top of the oval opening in the PIR front panel. Figure 17: Insert the Optical Limiter b. Push the limiter until it completely fits into place. Otherwise, the PIR cannot close properly. Figure 18: Optical Limiter installed in PIR 12.
- Page 18 Installing the PIR Figure 19: Align and Insert Tabs in Square Slots 13. Put the back cover onto the front cover, aligning the latch tab with the lock tab of the front panel. Figure 20: Put the Back Cover onto the Front Cover 14.
- Page 19 Installing the PIR 15. Screw in the two screws above the battery compartment at the top of the back cover. Figure 22: Screw in the Screws 16. If the PIR is part of a Care@Home™ kit: a. Move the PIR at least 2 m (~6 ft. 7 in.) from the CP. b.
- Page 20 Installing the PIR 17. If the PIR is not part of a Care@Home™ kit: a. On the CP, press the PAIRING button for five seconds. PAIRING button Figure 24: Press the CP PAIRING Button b. Move the PIR at least 2 m (~6 ft. 7 in.) from the CP. c.
- Page 21 Installing the PIR WARNING! A new battery can cause damage if it is incorrectly installed. e. Ensure that the pairing process is successful. The process can have the following results: The CP beeps and the CP ring blinks blue three times. Success ...
-
Page 22: Conducting A Walk Test
Installing the PIR 2.5. Conducting a Walk Test A Walk Test is a function and signal verification check. The test is used to determine the detection area of the PIR. The Walk Test mode starts automatically after the PIR powers up, such as: ... -
Page 23: Operating The Pir
Operating the PIR 3. Operating the PIR The PIR monitors activity and reports it by sending notifications to the CP. 3.1. Notifications The PIR sends notifications to the CP for the following events: The PIR detects motion The room temperature exceeds the configured temperature threshold ... -
Page 24: Replacing The Battery
Replacing the Battery 4. Replacing the Battery When the battery charge is low, the battery must be replaced. WARNING! A new battery can cause damage if it is incorrectly installed. Be careful to replace the battery only with the same or equivalent to the recommended type. - Page 25 Replacing the Battery 2. Remove the battery cover by sliding it upwards. Figure 28: Remove the Battery Cover 3. Remove the old battery. 4. Shake the PIR gently. The rattling sound is the tamper-prevention mechanism. 5. Insert the new battery, observing the correct polarity. When the battery is installed, the LED lights up red, indicating that the PIR has powered up successfully.
-
Page 26: Specifications
Specifications 5. Specifications The following table lists all the technical aspects and data about the PIR. Table 1: Device Technical Specifications Category Details Essence Part number ES700PIR Power Supply Battery One 3 V CR123A lithium Approved manufacturers GP, Energizer, Duracell... - Page 27 Specifications Category Details Functional Main MCU Advanced false alarm suppression algorithms Advanced gain temperature control Immunity Sealed PCB Multiple detection Minimal wait time between detections: 20 seconds mechanism (PERS: 2.5 minutes) Walk test Automatic after power-up, for 10 minutes Visual indications LED for detection, tampering, and walk test Environmental RFI protection:...
-
Page 28: Using Mounting Tape
Installation Method Alternatives Appendix A Installation Method Alternatives There are two ways to install the PIR mounting base: Using mounting tape Using screws Before choosing the installation method, consider the following: Installation with mounting tape is more common. ... -
Page 29: Using Screws
Installation Method Alternatives Using Screws You can use screws to install the PIR: Flat on a wall At an angle facing to the right or the left In a corner Required Equipment Before beginning, prepare the following equipment: ... - Page 30 Installation Method Alternatives Screw Holes The following figures show the screw holes to use for each type of installation. The corner support holes are blocked by the mounting tape. You can drill through the tape. Figure 29: Holes for Figure 30: Holes for Installing Installing on a Flat Wall in a Corner Figure 31: Holes for...
- Page 31 Essence, or their respective owners. Nothing contained herein shall be construed as conferring by implication, estoppels, or otherwise any license or right, either express or implied, under any patent or trademark of Essence or any third party. No use of any trademark may be made without the prior written authorization of Essence.
