AIR CONDITIONER
INDOOR UNIT
Compact Cassette Type
INSTALLATION MANUAL
AMP Air Conditioning
INSTALLATION MANUAL
For authorized service personnel only.
INSTALLATIONSANLEITUNG
Nur für autorisiertes Personal.
MANUEL D'INSTALLATION
Pour le personnel agréé uniquement.
MANUAL DE INSTALACIÓN
Solo para personal autorizado.
MANUALE D'INSTALLAZIONE
Ad uso esclusivo del personale autorizzato.
ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ
Για εξουσιοδοτημένο προσωπικό σέρβις.
MANUAL DE INSTALAÇÃO
Apenas para técnicos autorizados.
РУКОВОДСТВО ПО УСТАНОВКЕ
Для уполномоченного персонала.
KURULUM KILAVUZU
Yetkili servis personeli içindir.
PART NO. 9379124010-05
www.ampair.co.uk | sales@ampair.co.uk
Advertisement
Table of Contents
Related Manuals for Ampair AUYG14LVLB
Summary of Contents for Ampair AUYG14LVLB
-
Page 1: Air Conditioner
Ad uso esclusivo del personale autorizzato. ΕΓΧΕΙΡΙΔΙΟ ΕΓΚΑΤΑΣΤΑΣΗΣ Για εξουσιοδοτημένο προσωπικό σέρβις. MANUAL DE INSTALAÇÃO Apenas para técnicos autorizados. РУКОВОДСТВО ПО УСТАНОВКЕ Для уполномоченного персонала. KURULUM KILAVUZU Yetkili servis personeli içindir. PART NO. 9379124010-05 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... - Page 2 This unit is part of a set constituting an air conditioner. It must not be installed alone or with non-authorized by the manufacturer. Always use a separate power supply line protected by a circuit breaker opera-ting on all wires with a distance between contact of 3mm for this unit. En-1 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
-
Page 3: Cassette Grille Accessories
Select installation locations that can properly support the weight of the indoor unit. Install the units securely so that they do not topple or fall. Wire clamper For electrical wiring (*1) This part is not furnished for AUT* series En-2 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 4: Installation Dimension
Perform fi nal tightening by tightening the double nut fi rmly. Be sure to install the body horizontally and adjust the height below the body and the ceiling surface properly. (4 directions) (3 directions) Unit : mm En-3 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... - Page 5 Note) Check for drainage Pour about 1 liter of water from the position (see 9. TEST RUN/CHECKING DRAINAGE). Check for any abnormalities such as strange noises and whether the drain pump functions normally En-4 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
-
Page 6: Pipe Installation
(See the table below for the (4) Protect the pipes by pinching them or with tape to prevent dust, dirt, or water from fl are nut tightening torques. entering the pipes. En-5 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 7: Installing Heat Insulation
Improp- erly connected or secured wires can cause serious accidents such as overheating the terminals, electric shock, or fi re. En-6 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 8: Wiring System Diagram
Control line Power line Power line Indoor unit Wired remote controller cable Wired remote controller Indoor unit White Black Remote controller cable *Earth (Ground) the remote controller if it has a earth ground) line. En-7 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 9: Connection Cable Preparation
Be sure to align the battery polarities ( ) correctly. ＋ − (1) Remove the control box cover and install each connection wire. (3) Close the battery compartment lid. Screw Control box cover En-8 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 10: Installing The Remote Controller Holder
Use only the supplied screws to install the cassette grille. Cassette grille. 7.1. Remove the intake grille Indoor unit Ceiling Sealant (1) Slide the 2 grille hooks. Cassette grille No gap between ceiling and cassette grille around entire perimeter Grille hook En-9 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 11: Attach The Intake Grille
MODE button and proceed to STEP 2.) (2) Press the TIMER MODE button and check that the indoor unit can receive signals at the displayed signal code. En-10 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 12: Selecting The Remote Controller Signal Code
Setting description Function number Setting value (3) Press the SET TEMP. (▲) (▼) button to change the signal code between . Match the code on the display to the air conditioner signal code. En-11 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 13: Special Installation Methods
: Power supply cable Primary/Secondary setting : Remote controller cable : Bus wire (Function number 51) : Transmission cable, Power supply cable : Power supply cable : Remote controller cable : Bus wire En-12 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... - Page 14 Assign the same number to all of the indoor units connected to an outdoor unit. DIP SW 1-No. 2 (The unit is factory-set to “00”) Primary unit Refrigerant circuit address Function Number Setting Value Secondary unit ∼ En-13 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
-
Page 15: Test Run
If the signal code is changed, explain to the customer how it changed (the system munication error returns to signal code A when the batteries in the remote controller unit are replaced). *(4) is applicable to using wireless remote controller. En-14 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk... -
Page 16: Error Codes
Compressor temp. sensor error ● ● ◊ Outdoor unit Heat Ex. liquid temp. ● ● ◊ EX. Self-diagnosis sensor error Outdoor temp. sensor error ● ● ◊ Suction Gas temp. sensor error ● ● ◊ En-15 AMP Air Conditioning www.ampair.co.uk | sales@ampair.co.uk...
