- Page 1 Rhein Tech Laboratories Report #: 2004079 360 Herndon Parkway FCC: Part 15.249 Suite 1400 RSS-210 Herndon, VA 20170 FCC ID: PVTTR800-US http://www.rheintech.com M/N: TR800 APPENDIX J: MANUAL Please see the following pages. Page 58 of 74...
- Page 2 OPERATION & INSTALLATION MANUAL TM70 PUSHBUTTON TRANSMITTERS TM70Bi.v2.1a.doc (06/04) IKUSI reserves the right to modify this information without prior notification.
- Page 3 I N DEX PAGE. 1.- DECLARATION OF CONFORMITY ........................1 2.- SYSTEM DESCRIPTION............................2 3.- SAFETY INSTRUCTIONS............................3 3.1.- WHAT YOU MUST DO .............................3 3.2.- WHAT YOU MUST NOT DO ..........................3 3.2.- NOTES.................................4 4.- INSTALLATION ..............................5 4.1.- THE CB60 BATTERY CHARGER ........................5 4.2.- RECEIVER ................................6 4.3.- STARTING UP..............................8 5.- USING THE SET ..............................10 6.- MAINTENANCE ..............................11...
-
Page 4: Declaration Of Conformity
Tel : (+34) 943 448800 Fax: (+34) 943 448816 O Fabricante Declara que el producto: Telemando IKUSI TM70/1 Declares that the product: Remote Control IKUSI Erklärt, dass das Produkt: Funkfernsteuerung IKUSI TM70/2 Déclare que le produit: Télécommande IKUSI Dichiara che il prodotto: Radiocomando IKUSI... -
Page 5: System Description
2.- SYSTEM DESCRIPTION The TM70/1 and TM70/2 push-button transmitter type, radio remote control systems are designed for the remote control of hoists and cranes, and are particularly suitable for applications when the operator needs to be able to choose the best location from which to carry out an operation. -
Page 6: Safety Instructions
Identify the machine controlled on the label for this purpose on the transmitter. Service the equipment periodically. When carrying out repairs, only use spare parts supplied by IKUSI dealers. 3.2.- WHAT YOU MUST NOT DO Never make any changes to the set, which have been studied and approved by manufacturer. -
Page 7: Notes
3.2.- NOTES Changes or modifications not expressly approved by the manufacturer could void the user's authority to operate the equipment. To comply with FCC RF exposure compliance requirements, this device and its antenna must not be co-located with, or operating in conjunction with, any other antenna or transmitter. -
Page 8: Installation
(keys, coins, etc.). Always keep contacts clean. Never leave batteries in direct sunlight. Only use IKUSI manufactured batteries. When the batteries are exhausted they can be disposed of or recycled safely according to local standards. -
Page 9: Receiver
4.2.- RECEIVER Make sure that the crane is stopped for the entire duration of the assembly process, keep the work area free and wear protective clothing. Park the crane and position stop-ends (if these are not available use appropriate signs) at a suitable distance so that other cranes on the same runway do not hit it. - Page 10 Connect the power supply and the receiver outputs on the corresponding relay board plug-in terminals. Do this following the outputs diagram, which is supplied with the set. This diagram indicates the correspondence between the transmitter commands and the receiver outputs. The STOP relays KSTOP1 and KSTOP2 are in series and must be connected to the main contactor coil circuit.
-
Page 11: Starting Up
OFF in the case of the channels being signal free. Blinks ON when there is a RF signal on the channels DATA: OFF; when there is not another TM70 system active in the area. Blinks ON in the opposite case.. Next, turn transmitter ON to OPERATION mode, as follows: Place a charged battery in the transmitter. - Page 12 On receiving a signal from the transmitter, the following LED’s will light up on the receiver: POWER: ON, indicates that the power supply is correct. HARDOK: ON, indicates that defects have not been detected on the board. SIGNAL: ON, indicates that it is receiving a RF signal at the working frequency. DATA: When ON indicates that the data received has a correct format.
-
Page 13: Using The Set
5.- USING THE SET To ensure correct use of the equipment, follow the instructions below: Make sure the transmitter you are going to use is the right one, identifying the machine on the identification label. In the case of transmitters with LCD display, you are able to edit the machine identification label, refer to ANNEX B. -
Page 14: Maintenance
6.- MAINTENANCE 6.1.- WARRANTY IKUSI guarantees the TM70 remote control sets for a period of up to one year after the date of delivery. This guarantee covers repairs and the replacement of defective pieces at our Technical Service Department. Both the transmitter and receiver will be necessary if any repairs or replacements need to be carried out. -
Page 15: Fault Finding
DATA Is receiving the correct Signal received is not data from a TM70 (1) correct (1): DATA and ID LED’s show a weak flashing when data and ID code are received correctly, but Start command has not yet been received. Once Start button is pushed ON;... -
Page 16: Spares
If the problem is associated with the equipment, please send both the transmitter and the receiver to the your Technical Assistance Service Agent, together with a description of the problem and the status of the LED’s. If the transmitter becomes so damaged that a spare has to be arranged, it can be quickly substituted by following the instructions in ANNEX A. -
Page 17: Annex A - Programming A Spare Transmitter
ANNEX A - PROGRAMMING A SPARE TRANSMITTER. In case of damage to the transmitter, it is quickly possible to restore service, if a spare transmitter is available. To achieve this we have to install into the spare transmitter the exact parameters of that to be replaced. -
Page 18: Annex B.- Programming The Machine Identification In Lcd Transmitters
ANNEX B.- PROGRAMMING THE MACHINE IDENTIFICATION IN LCD TRANSMITTERS. Transmitters with the LCD display option allow the operator to programme a machine identification label of up to 24 text characters. This identification displays on transmitter start- This text must identify the machine with a that is commonly known by the workmen. When first starting the transmitter you can edit/introduce this text as follows;...
