GPS-721
GPS Receiver and 1 DO, 1 PPS Output
Module

Quick Start Guide

1.

Introduction

This manual introduces the user to the methods used to implement the GPS-721
module into their applications in a quick and easy way, and will only provide
basic instructions. For more detailed information, please refer to the GPS-721
user manual located on the ICP DAS CD-ROM, or download it from the ICP DAS
web site:
https://www.icpdas-usa.com/gps_721.html

2. Package Checklist

GPS-721 GPS Receiver
- QuickStart (Aug/2017)
ICP DAS USA, Inc. |
www.icpdas-usa.com
| 1-310-517-9888 | 24309 Narbonne Ave. Suite 200. Lomita, CA 90717
1
