■ Detaching the control head
from the transceiver
1. Disconnect the speaker cable [J803] from the
transceiver's main unit.
2. Disconnect the flat cable from the transceiver's control
head.
3. Detach the control head from the main unit.
Flat
cable
Control head
[J803]
Main unit
■ Attachment
D Opening the separation kit
NOTE: The separation kit is supplied with the front panel
and rear panel attached. First you need to open the
separation kit in order to attach the control head to the
separation kit's rear panel.
Hold the tabs on the separation kit's front panel, and then
pull out in the directions of the arrows.
Front panel
1
ATTACHMENT
Rear panel
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
3
