Summary of Contents for AnyDATA EMII-800
- Page 1 EMII-800 User Manual Application Information EMII-800-V1.0 February 15, 2002 AnyDATA.NET Inc. Hanvit Bank B/D 6F Byulyang-dong Kwachon KOREA Tel) 82-2-504-3360 Fax) 82-2-504-3362 EMII-800 V1.0 AnyDATA.NET Proprietary Use Subject to Restrictions...
- Page 2 AnyDATA.NET products and may not be distributed to anyone without permission of AnyDATA.NET Inc. All data and information contained in this document are proprietary and confidential information of AnyDATA.NET Inc. No part of this document may be reproduced, in any form or any means without written permission of AnyDATA.NET Inc.
-
Page 3: Introduction
AnyDATA.NET Inc. assumes no responsibility for any loss or claims by third parties, which may arise through the use of its products. AnyDATA.NET Inc. assumes no responsibility for any damage or loss caused by the deletion or loss of data as a result of malfunctions or repairs. - Page 4 Interface Description EMII-800 Reference Manual Application Information CAUTION Operating Requirements The user can not make any changes or modifications not expressly approved by the party responsible for compliance, otherwise it could void the user's authority to operate the equipment. To satisfy FCC RF exposure compliance requirements for a mobile transmitting device, this device and its antenna should generally maintain a separation distance of 20cm or more from a person–s body.
- Page 5 Interface Description EMII-800 Reference Manual Application Information Contents 1 Introduction 1.1 Purpose 1.2 Organization 1.3 Revision History 2 Overview 2.1 Application Description 2.2 Technical Specifications 2.2.1 General Specification 2.2.2 Receive Specification 2.2.3 Transmit Specification 2.2.4 Standards 2.3 Interface Diagram 2.4 EMII-800 General Features 2.5 Internal Modem Features...
- Page 6 Interface Description EMII-800 Reference Manual Application Information 5 Electrical Specifications 5.1 Absolute Maximum Ratings 5.2 Recommended Operating Conditions 5.3 Power Consumption 5.4 Serial Interface Electrical Specifications 6 Mechanical Dimension 6.1 EMII-800 Outline 7 FCC Notice EMII-800 V1.0 AnyDATA.NET Proprietary Use Subject to Restrictions...
-
Page 7: Purpose
1.2 Organization The interface and operation section is organized into the following subsections: Section 2 º Introduces users to the EMII-800 CDMA Wireless Data Modem basic features and general specifications. Section 3 º Contains EMII-800 Pin description - DC12V Input Port, 8pin Serial Port and Debugging Port. -
Page 8: Overview
153.6kbps. The EMII-800 provides external interface. External interface includes the standard RS-232, Digital Audio, and External On/Off control. The EMII-800 has the capability to power down unused circuits in order to dynamically minimize power consumption. EMII-800 V1.0 AnyDATA.NET Proprietary... -
Page 9: Technical Specifications
Interface Description EMII-800 Reference Manual Application Information 2.2 Technical Specifications 2.2.1 General Specifications PARAMETERS DESCRIPTIONS External Access Code-Division-Multiple-Access (CDMA) CDMA Protocol IS-95A/B/C, IS-98A, IS-126, IS-637A, IS-707A Data Rate 153.6Kbps Transmit/Receive 45MHz Frequency Interval Band Width 1.23MHz Operating Voltage DC 6V ~ 12V... -
Page 10: Receive Specification
Interface Description EMII-800 Reference Manual Application Information 2.2.2 Receive Specifications PARAMETERS DESCRIPTIONS Frequency Range 869.04 ~ 893.97 MHz Below º 104 dBm Sensitivity Single tone (-30dBm @900KHz) : Below º 101dBm Interference Two tone (-43 dBm @900KHz and 1700KHz) : Below º 101dBm Two tone (-32 dBm @900KHz and 1700KHz) : Below º... -
Page 11: Interface Diagram
Interface Description EMII-800 Reference Manual Application Information 2.3 Interface Diagram UART1 RS-232 RF Unit MSM Inter. EARJACK CODEC MSM5100 External PWR LDO(4V) (6~14V) DTSS-800 Application Device EMII-800 Figure 2-1 Interface Block Diagram EMII-800 V1.0 AnyDATA.NET Proprietary Use Subject to Restrictions... -
Page 12: Emii-800 General Features
Interface Description EMII-800 Reference Manual Application Information 2.4 EMII-800 General Features Figure 2-2 EMII-800General Features 2.5 Internal Modem Features Figure 2-3 Internal Modem General Features (DTSS-800) EMII-800 V1.0 AnyDATA.NET Proprietary Use Subject to Restrictions... -
Page 13: Pin Description
Interface Description EMII-800 Reference Manual Application Information 3. PIN Description 3.1 8-Pin Male Modular Jacks(RS232 Standard) Molex RS-232 (85503) Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Pin 7 Pin 8 Figure 3-1 Right Angle Modular Jacks Pin Description (85503,Molex 8P) 3.2 3-Pin Connector (Debugging) -
Page 14: Interface Descriptions
EMII-800 Reference Manual Application Information 4. Interface Descriptions 4.1 Overview This chapter covers information required to design the EMII-800 into a subscriber unit application. In addition, the internal signals that are necessary for complete understanding of the UART interfaces are described below. -
Page 15: Electrical Specifications
Interface Description EMII-800 Reference Manual Application Information 5. Electrical Specifications 5.1 Absolute Maximum Ratings Operating the modem under conditions that exceed those listed in the Absolute Maximum. The Ratings table may result in damage to the modem. Absolute Maximum Ratings may be considered as limiting values, and are considered individually. -
Page 16: Mechanical Dimensions
Interface Description EMII-800 Reference Manual Application Information 6. Mechanical Dimensions 6.1 EMII-800 Outline EMII-800 V1.0 AnyDATA.NET Proprietary Use Subject to Restrictions... -
Page 17: Fcc Notice
Interface Description EMII-800 Reference Manual Application Information 7. FCC Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
