AnyDATA ADU-310 User Manual

Anydata usb modem user manual
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ADU-310 USB Modem
(User Manual)
SW-ADU-310-UG-V2.8E(Skylink)
July 26. 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ADU-310 and is the answer not in the manual?

Questions and answers

Related Manuals for AnyDATA ADU-310

Summary of Contents for AnyDATA ADU-310

  • Page 1 ADU-310 USB Modem (User Manual) SW-ADU-310-UG-V2.8E(Skylink) July 26. 2007...
  • Page 2 ADU-310 USB Modem (User Manual) AnyDATA CDMA Module Series Reference Design Specification Copyright © 2000~2007 AnyDATA Corp. All Rights Reserved. Any part of this document may not be distributed, communicated, reproduced or transmitted in any form or by any means, electronic or mechanical or otherwise, for any purpose, without the permission of AnyDATA Corp.

  • Page 3: Table Of Contents

    ADU-310 USB Modem (User Manual) Contents 1. ADU-310 Features............................4 2. LED Indicators ............................5 2.1 POWER ...............................5 2.2 IDLE / BUSY............................5 3. Program Installation..........................6 3.1 Introduction ............................6 3.2 Minimum System Requirement......................6 3.2.1 PC Hardware..........................6 3.2.2 Operating System .........................6 3.3 USB Driver Installation (Windows XP/2000)..................7 3.4 USB Driver Installation (Windows Vista)....................13...

  • Page 4: Adu-310 Features

    ADU-310 USB Modem (User Manual) 1. ADU-310 Features Ear Jack RUIM AnyTime AnyPlace AnyWireless Data Solutions 4/41...

  • Page 5: Led Indicators

    ADU-310 USB Modem (User Manual) 2. LED Indicators 2.1 POWER Mode Descriptions Modem power on state Modem power off state 2.2 IDLE / BUSY Mode Descriptions GREEN Success to network acquisition (Idle state) BLUE Data(Voice) call is connected BLUE BLINK...

  • Page 6: Program Installation

    ADU-310 USB Modem (User Manual) 3. Program Installation 3.1 Introduction This section describes step-by-step method to install ANYDATA.NET USB MODEM and Easy Wireless Net Software. 3.2 Minimum System Requirement 3.2.1 PC Hardware Recommend to use PC/Notebook at speed of 300 MHz or higher.

  • Page 7: Usb Driver Installation (Windows Xp/2000)

    1) Connect the modem and PC’s USB port with supplied USB cable. The manual d river installation shall be required twice. 2) Installing “AnyDATA USB Modem Driver” window will appear. Select “Install from a list or specific location (Advanced )”.
  • Page 8 ADU-310 USB Modem (User Manual) 7) Click the “ Continue Anyway” button. 8) A window that searches “AnyDATA CDMA USB Modem” will appear. AnyTime AnyPlace AnyWireless Data Solutions 8/41...
  • Page 9 ADU-310 USB Modem (User Manual) 9) Process of installing “AnyDATA CDMA USB Modem”. 10) If the installation of “AnyDATA CDMA USB Modem” has been completed, following window will appear. AnyTime AnyPlace AnyWireless Data Solutions 9/41...
  • Page 10 ADU-310 USB Modem (User Manual) 11) Next, it will install “AnyDATA CDMA USB Serial Device”. 12) Select “Install from a list or specific location (Advanced)”. 13) Press button to proceed. 14) Select the proper path from the CD window will appear.
  • Page 11 ADU-310 USB Modem (User Manual) 17) Window that searches “AnyDATA CDMA USB Serial Device” will appear. 18) If the installation has done properly, this window will appear. This will complete the driver installation. AnyTime AnyPlace AnyWireless Data Solutions 11/41...
  • Page 12 “Device Manager”. See the followings to the location of “Device Manager” [Start Control Panel System Hardware Tab Devise Manager] As shown in below with red boxed that shows “AnyDATA CDMA USB Modem” and “AnyDATA CDMA USB Serial Device”, the driver has been successfully installed. AnyTime AnyPlace AnyWireless Data Solutions 12/41...

  • Page 13: Usb Driver Installation (Windows Vista)

    ADU-310 USB Modem (User Manual) 3.4 USB Driver Installation (Windows Vista) The same will apply to Windows Vista 64bit. The manual driver installation shall be required twice. hen shown in below. “User Account Control” is shown. AnyTime AnyPlace AnyWireless Data Solutions...
  • Page 14 ADU-310 USB Modem (User Manual) AnyTime AnyPlace AnyWireless Data Solutions 14/41...
  • Page 15 ADU-310 USB Modem (User Manual) AnyTime AnyPlace AnyWireless Data Solutions 15/41...
  • Page 16 ADU-310 USB Modem (User Manual) “User Account Control” is shown. AnyTime AnyPlace AnyWireless Data Solutions 16/41...
  • Page 17 ADU-310 USB Modem (User Manual) AnyTime AnyPlace AnyWireless Data Solutions 17/41...
  • Page 18 ADU-310 USB Modem (User Manual) AnyTime AnyPlace AnyWireless Data Solutions 18/41...
  • Page 19 “Device Manager”. See the followings to the location of “Device Manager” [Start Control Panel System and Maintenance Devise Manager] As shown in below with red boxed that shows “AnyDATA CDMA USB Modem” and “AnyDATA CDMA USB Serial Device”, the driver has been successfully installed. AnyTime AnyPlace AnyWireless Data Solutions 19/41...

  • Page 20: Check Installed Driver

    ADU-310 USB Modem (User Manual) 3.5 Check Installed Driver 1) Start [Control Panel] 2) Select [System] icon and execute. 3) Select “Device Manager” from Hardware Tab. AnyTime AnyPlace AnyWireless Data Solutions 20/41...
  • Page 21 ADU-310 USB Modem (User Manual) 4) “AnyDATA CDMA USB Modem” will be [Modems] part. 5) “AnyDATA CDMA USB Serial Device” will be [Ports (COM & LPT)] part. AnyTime AnyPlace AnyWireless Data Solutions 21/41...

  • Page 22: Easy Wireless Net Installation

    ADU-310 USB Modem (User Manual) 4. Easy Wireless Net Installation 1) Double click “Setup.exe” from the supplied CD. 2) Select the desire language as shown below. 3) Press button to proceed. By pressing button, the installation of Easy Wireless Net Program will stop.
  • Page 23 6) Next window is related to License Agreement. Please read carefully. 7) Press “I Agree” button to advance to the next step. 8) Next window displays asking proper path for installing the program. Default path is “C:\Program Files\AnyDATA\Easy Wireless Net” AnyTime AnyPlace AnyWireless Data Solutions 23/41...
  • Page 24 ADU-310 USB Modem (User Manual) 9) Press button to install the program. 10) When program has been successfully installed, following window will display. AnyTime AnyPlace AnyWireless Data Solutions 24/41...
  • Page 25 ADU-310 USB Modem (User Manual) 11) Press button for ending the program installation. This is install the Easy Wireless Net Program. <Remark> If modem is not connected to PC/Notebook and device driver is not installed, then the program will not...

  • Page 26: Using Easy Wireless Net

    ADU-310 USB Modem (User Manual) 5. Using Easy Wireless Net 5.1 Run and Exit 1) To run Easy Wireless Net, double click [Easy Wireless Net] icon on the Desktop 2) To exit from Easy Wireless Net, Press button on the program 5.2 DRC infomation View...

  • Page 27: Descriptions For Each Button

    ADU-310 USB Modem (User Manual) 5.3 Descriptions for each button Display Function Connecting to the Internet Disconnecting to the Internet Setup Menu Voice call menu SMS menu Phonebook Menu Sending message Make a voice call Disconnect a voice call Erasing one character on the screen...

  • Page 28: Descriptions For Each Icon

    ADU-310 USB Modem (User Manual) 5.4 Descriptions for each icon Display Function RSSI Signal Strength Indicator Calling Possible Calling not Possible New message arrived. Voice Mail arrived. Voice Mail and New Message arrived. Rx Diversity Mode. Supports Hybrid mode Only 1X mode available...

  • Page 29: Setting Menu

    ADU-310 USB Modem (User Manual) 5.5 Setting Menu There are 4 sub-menus for setting. To change the value check wanted item box and press button to take effect. 1) [About]: Version information AnyTime AnyPlace AnyWireless Data Solutions 29/41...
  • Page 30 ADU-310 USB Modem (User Manual) 2) [Basic]: Configurations for internet connection - All values for internet connection are set automatically. - From Data Call Account, there are two accounts, called Computer Account and RUIM Account. You may select one of them and change Auth Mode upon the selected Account type.
  • Page 31 ADU-310 USB Modem (User Manual) 3) [RUIM] 4) [Advance]: Operating network (1xRTT or 1xEVDO) - This is very important parameter, It is strongly recommended that remain default value AnyTime AnyPlace AnyWireless Data Solutions 31/41...
  • Page 32 ADU-310 USB Modem (User Manual) 5) [User]: Display options - Always Top: The program window will be displayed on the top level - Battery Warning Sound : Low battery warning sound - From International call, there are two modes, called manual mode and AUTOMATIC mode.

  • Page 33: Connecting And Disconnecting To The Internet

    ADU-310 USB Modem (User Manual) 5.6 Connecting and Disconnecting to the Internet 1) Press button for internet connection, it will display the connection status If succeed in connection icon will be appeared, if fail to connect icon will be appeared.

  • Page 34: Voice Call Menu

    ADU-310 USB Modem (User Manual) 6.7 Voice Call Menu Dial calling number and Press button to make a voice call. To disconnect the voice call, press button. When pressing button, One digit will be erased. AnyTime AnyPlace AnyWireless Data Solutions...

  • Page 35: Sms Menu

    ADU-310 USB Modem (User Manual) 5.8 SMS Menu In the SMS menu, there are 3 sub-menus (Write Message, Outbox, Inbox) - Write Message: Edit and send new message - Outbox: Sent message box - Inbox: received message box AnyTime AnyPlace AnyWireless Data Solutions...
  • Page 36 ADU-310 USB Modem (User Manual) 1) Write Message - Edit the message in the window and press button to move to the number editing screen. - Input number(s) for sending SMS, number(s) can be inputted from Phonebook records. Press button to move to send the message screen...
  • Page 37 ADU-310 USB Modem (User Manual) 2) Outbox - In this menu, All sent messages are shown. - To erase the message, select the message and press button. - To see the message, select the message and press button. - To send the message to a new number, press button.
  • Page 38 ADU-310 USB Modem (User Manual) 3) Inbox - In this menu, All received messages are shown. - To erase the message, select the message and press button. - To see the message, select the message and press button. - To send the message to a new number, press button.

  • Page 39: Phonebook Menu

    ADU-310 USB Modem (User Manual) 5.9 Phonebook Menu Store phone numbers and name into RUIM. Making calls and sending messages to stored numbers are possible. Maximum number of Phonebook is depend on RUIM capacity. 1) Store new number - Edit the number and name on this screen, and press right button to save.

  • Page 40: Troubleshooting

    ADU-310 USB Modem (User Manual) 6. Troubleshooting Q: I cannot connect to the Internet? A: Please check User name, Password and Service number on the [Setting] menu. For correct User name, Password and Service number, please contact service provider for more information.
  • Page 41 ADU-310 USB Modem (User Manual) Q: How many people can I send SMS messages at once? A: It is possible to send maximum of 5 people at once. Q: During the running of the program, following message appears and the program halts.
