2-Way Touch Screen Remote
Paging Alarm & Engine Starting System
OPERATION INSTRUCTIONS
CONGRATULATIONS on your choice of the 2-Way Touch Screen Remote Paging Alarm &
Remote Engine Starting System by Crimestopper Security Products Inc. The FS-90 operates
at 915MHz and features an animated color LCD Touch Screen remote control. It includes
voice confirmation of all Alarm and Remote Start functions in both English and Spanish. The
remote uses a rechargeable Lithium Ion battery and includes both a car and AC charging
adaptor. The system includes Carjack and Panic protection. You can operate 4 vehicles with
a Pin Code. There are 7 zones of protection with trigger history of date and time of violation.
The remote control includes a Parking Meter, Alarm Clock, and vehicle temperature and
battery voltage checks. Remote Start features include, Daily Starting and built in Turbo Timer.
A special protective cover is included to protect the Touch Screen remote. There is a built in
Photo Cell to sense bright sun light. This changes the icons to black and white for easier
viewing.
CONTACT INFORMATION:
TECHNICAL SUPPORT (800)-998-6880
Monday - Friday 8:00am - 4:30pm Pacific
Website: www.crimestopper.com
CRIMESTOPPER SECURITY PRODUCTS INC.
1770 S. TAPO STREET
SIMI VALLEY, CA. 93063
REV.
04.2010
FS-90
INTRODUCTION
This device complies with FCC Rules part 15. Operation is
subject to the following two conditions: 1) This device may not
cause interference, and (2) this device must accept any
interference that may be received, including interference that
may cause undesired operation.
responsible for any radio or TV interference caused by
unauthorized modification to this equipment. Such modification
could void the user's authority to operate the equipment.
1
The manufacturer is not

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-90 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fortress Automotive Security FS-90

Summary of Contents for Fortress Automotive Security FS-90

  • Page 1 INTRODUCTION CONGRATULATIONS on your choice of the 2-Way Touch Screen Remote Paging Alarm & Remote Engine Starting System by Crimestopper Security Products Inc. The FS-90 operates at 915MHz and features an animated color LCD Touch Screen remote control. It includes voice confirmation of all Alarm and Remote Start functions in both English and Spanish.
  • Page 2 TABLE OF CONTENTS Operation Cautions & Warnings………………..…………..…..………………….…………..2 The Remote Controls………………..…………..……………………………………………..3-4 Menu Flow Chart………………..…………..……………………………………..………………5 Alternate Sub Menus………………………………………………………………………………. 6 Operating Instructions - Alarm………………..…………..………………………………..7-11 Car Selection / Car Name / Car Logo………………..…………..…………………………...11 Auxiliary Channels………………..…………..…………………………………………………12 Vehicle Status / Voltage / Temperature Check………………..…………..………....12 Time Display / Alarm Clock Settings…………………….………………..………………….12 Setting the Clock…………………………………………….………………..…………………13 Pin Code………...…………………………………………….………………..…………………13 Backlight / Vibration / Sound Settings………...……………………..…………………...13-14...

  • Page 3: The Remote Controls

    THE REMOTE CONTROLS 1-WAY - SIDEKICK REMOTE: The 1-Way sidekick remote adds flexibility to your system. You can have the convenience of operating your system without needing to carry the larger pager remote. The Sidekick remote has less range and offers all of the same operation features except for page-back confirmation.
  • Page 4 This screen changes to black and white in bright sun light. ARM / LOCK DISARM / UNLOCK TRUNK START DOWN MENU UP MENU • Press Up or Down Arrow Icon to Display Alternate Menus • The Touch Screen remote can operate up to 4 vehicles •...

  • Page 5: Menu Flow Chart

    Menu Flow Chart • Pressing side button once activates main menu screen. • Pressing UP Arrow once goes to CAR selection screen. • Pressing DN Arrow once goes to SILENT ARM / DISARM screen. • Continnue pressing UP or DN Arrow to scroll thru all menus.

  • Page 6: Alternate Sub Menus

    • Alternate Sub Menus Icon turns the Power OFF. All memory functions will be lost. You will have to reset the Date and Clock after turning remote back on. The Touch Screen Remote will not receive signals from vehicle until the side button is pressed. Battery life will be about 3 months in this mode.
  • Page 7 Arming / Locking: Press the Lock Icon on the front screen or the side Lock button on the remote control. The System will arm and confirm with one siren and horn chirp, one park lights flash, and the LED will begin to flash slowly. Power locks will lock (if equipped). The starter disable circuit will turn on.
  • Page 8 Silent Arming: To Arm without chirps, press the Silent Arm Icon. The 2-Way LCD Pager will confirm with “System Armed”. Silent Disarming: To Disarm without chirps, press the Silent Disarm Icon. The 2-Way LCD Pager will confirm with “System Disarmed”. Silent Mode: To Arm the alarm with silent monitoring of vehicle, press the Silent Mode Icon.
  • Page 9 Emergency Override (Disarm without Remote) If you have lost the transmitter or it stops working for any reason and the Alarm is armed, you will have to disarm the system manually. Open the door with the key [alarm will sound], turn the ignition on, and press the Valet / Override button for about 5 seconds.
  • Page 10 Pre-Warning Shock Protection: The Pre-Warning (Warn-A-Way) feature will activate when a low-level Light Shock or vibration is detected by the system’s shock sensor. The alarm will chirp the siren 6 times to help deter any further tampering with the vehicle. You will receive a paging signal that will display an icon of a hammer hitting the vehicle.
  • Page 11 Trunk / Hatch Pop - Remote Channel 1 (Option # 10 and 16) This feature is designed to interface with existing Factory power trunk or power hatch release systems and may require additional parts and/or labor charges. To activate, press and hold the Trunk Icon for 3 seconds.
  • Page 12 Remote Channels 2, 3, 4, 5, and 6 (Optional, Requires special programming) These outputs are programmable for a variety of functions. The default settings are for standard features like dome light, horn honk and remote starting. These outputs are programmable for momentary, latched, or timed.

  • Page 13: Setting The Clock

    Setting the Clock Time and Date: To change the date and time, press the Time Set Icon. The display will show DATE SET screen. Enter the month, day and year and press the Enter Icon to save selection. The TIME SET screen shows next. Enter the correct time and press the Enter Icon to save selection.

  • Page 14: Count Down Timer

    Light Delay Time: This adjusts the amount of time the display stays illuminated. You can increase or decrease the time in 1 second increments. The display will show the number of seconds in the top right corner of screen. Press ENTER Key Icon to save selection. Vibration and Melody: To change the sounds, voice, vibration or power off remote, press the MELODY Icon.
  • Page 15 Panic Mode: To sound the alarm in an emergency situation or to draw attention to your vehicle, press and hold the Lock Icon until the siren / horn sounds. The alarm will sound for 30 seconds. Press the Lock or Unlock Icon to reset panic mode. Carjack Protection: 2 Modes of Operation (Option #27) Carjack Mode is designed to protect you in a Hold-Up situation.
  • Page 16 Remote Engine Starting: Press and hold the Remote Start Icon until the remote control beeps a 2 time. 1) Parking lights flash twice and the system will chirp 3 times for audible confirmation. The 2-Way LCD Pager will give voice confirmation “Engine ON”. 2) After the Ignition and Accessory circuits turn for a few seconds, the Starter Motor engages.
  • Page 17 Remote Start Diagnostics: If the system doesn’t remote start, the Status LED flashes an error code to identify the problem area. • SOLID LED = Valet Service Mode. The system is in Valet Mode. To exit Valet Mode, turn the Ignition on, press and hold Valet Button for about 5 seconds until LED goes out.

  • Page 18: Turbo Timer Mode

    Turbo Timer: (Option# 23) The optional Turbo Timer mode allows the Remote Starter to keep a Turbo or Turbo Diesel vehicle running for 1 to 6 minutes (selectively) after you remove the key and exit the vehicle. This is handy for turbo cool-down without the need for expensive turbo timers.
  • Page 19 Touch-Screen LOCATE/FIND Function description: There is a Locate and Find Function for the 2-Way remote controls. This is used to help find a lost remote control. It will activate a beeping function for 30 seconds to locate the lost remote. You can use the Sidekick 1-Way remote to find a 2-Way remote, or use a 2-Way to find another 2-Way remote.
  • Page 20 SIDEKICK 1-Way Transmitter LOCATE Code-Learning: Press the Touch Screen transmitter code-learning button. Within 30 seconds, press Sidekick 1-Way transmitter buttons together at the same time. If learning successful, the Touch-Screen Transmitter will display “OK” on the top-right side of the screen along with a confirm melody. LOCATE FUNCTION: Using the 2-Way remote, select the transmitter you want to...

  • Page 21: Optional Garage Door Opener

    1. A single button garage door opener. Press the same button to open or close the garage door. The FS-90 can control 2 of these garage doors. 2. A separate button for opening and closing the garage door. The FS-90 can control one of these garage doors.
