Summary of Contents for Fortress Automotive Security FS-99
- Page 1 FS-99 2-Way Touch Screen Remote Paging Alarm & Engine Starting System OPERATION INSTRUCTIONS...
- Page 2 FCC Regulations: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause interference and 2) This device must accept any interference, including interference that may cause undesired operation of the device.
- Page 3 Remote function table Remote command Buttons Conditions Disarm Lock Ignition on Unlock Ignition on Silent Arm Silent Disarm Car Finder Arm state Anti-Hijack Ignition on Panic Ignition off hold 2 sec Shock by pass Activate Channel 1 See function program (Trunk Release) hold 2 sec Activate Channel 2...
- Page 4 Outside view: MAIN PAGE: Press KEY to display Page 0: press anywhere in touch area to display PAGE ONE black& white pages Press KEY hold 2 sec to display Press the button for KEY it will become the main page press again it will become clock, and there are four colors for the clock, just touch these color point, the clock will change the color too.
- Page 5 Other PAGES: Button define is same as PAGE ONE,such as : P10K3 is CH5 button in p10 When transmitter received the car alarming will play trigger movies and sound voice: The move will be stopped,if the key pressed Cancel count down: set count down =00:00 Cancel alert time: set alert time =00:00...
- Page 6 Buttons Explain Buttons Explain Set count down start time Disarm Compass Infrared remote control Trunk Remote engine start LOCATE/FIND Silent arm key Status Check Silent disarm key Get vehicle battery volt Activate Channel 3 Get the outside temperature Activate Channel 4 car jack key Activate Channel 5 Remote valet...
- Page 7 can enter the setting page, to change the following settings power save: ON/OFF date Melody: ON/OFF time mode24H/12H Key beep: ON/OFF language set time Shock: ON/OFF back light power OFF N/Y compass reset N/Y light delay alert time Pin code switch ON/OFF alert switch ON/OFF Pin code change ℃/℉...
- Page 8 Touch-Screen Locate/Find function description Locate/Find page: Press the button to enter the Locate/Find page Select the transmitter: Press button to select different transmitter which you want to Locate/Find/Learning/Name register Register the name for your selected transmitter: Press the name button to register each Locate/Find transmitter name For example: Select TAG1 to name the 1st transmitter.
- Page 9 If learning successful, the Touch-screen transmitter will display “OK” on the top-right side of the screen also a confirm melody. Locate a. Press button to select different transmitter which you want to Locate. Then press the button to Locate Activate this function can locate where the missing key is. If there is a successful returned signal receiving from the lost transmitter, will display OK on the top-right side of the handset.
- Page 10 1. Arm Press button once, system will chirp once, parking lights flash once, lock the doors, starter disabled, window close output 30 sec. (if CH4 programmed), status LED start to flash slowly, Will chirp 4 times and parking lights flash 4 times if door or hood or trunk isn’t closed well while arming, and will not detect the door (hood, trunk) open until there are full closed well.
- Page 11 7. Arm without ZONE 1. Arm bypass sensor 1 Press button , once to set arming, siren chirp, parking lights flash once, Sensor 1 will be bypassed. Sensor 2 is normal 2. Arm bypass sensor2 Press button , once to set arming, siren chirp, parking lights flash once, Sensor 2 will be bypassed.
- Page 12 7. Two-Stage unlock Press button will unlock driver’s door only. Hold button for 2 seconds or press button twice (see program feature 10), will unlock the passenger’s doors (activate “2 stage Unlock Output”). If programmed. 8. Lock Press button will lock the doors. 9.
- Page 13 14. Channel 3 (Dome Light) Press and release button to activate channel 3, remote Output pulse time of channel 3 is programmable function (program feature 12). 15. Channel 4 (HORN -0/P) Press and release button to activate channel 4, remote Output pulse time of channel 4 is programmable function (program feature 13).
- Page 14 20. Valet mode At valet mode system can be remote door lock / unlock, activate channels. No any protect function. Enter and exit Valet mode procedure: - Turn on ignition in disarm mode - Press override button 5 seconds - Parking lights flash and siren chirps 2 times Enter valet mode led still on.
- Page 15 24. Learn tachometer (RPM) - turn on ignition - press override button 6 times, - wait 2s, parking lights flash and siren chirps 6 times - press override button 1 times, - siren chirps one time Start the vehicle with the key. while the engine is running, the parking will flash. if don’t, please check tachometer wire connection.
- Page 16 26. Learning codes of remote transmitter There are only four transmitters may be learned in system’s memory. Codes of learned remote transmitters will be erased each time the learning mode is activated. To activate leaning codes mode: - turn on ignition - press override button 4 times - wait 2 seconds, parking lights flash and siren chirps 4 times - press button...
- Page 17 28. Programming functions 1. Turn Key to the ON position 2. Press program / valet button 5 times. After a few seconds the unit will flash the Parking lights and siren chirps 5 times 3. Push the valet program button [again] the number of times that corresponds to the option number desired (1-20X).
- Page 18 wire) Channel 6 Ignition Run Latch On/Off Output (Ground when Latch On/Off Momentary hold with Ign Reset (Blue/black wire) Running) Disarm with Trunk Pop 30 Sec. Park Lights w/Disarm Pink Wire Selection Diesel *(-) Start *15 Sec. Delay (+) Glow Plug (-) Glow Plug or Gasoline Activation*...
