- Page 1 www.domotica-shop.nl INTERCOM SMART VIDEO DOORBELL Installation & Configuration Guide...
-
Page 2: Important Safety Information
www.domotica-shop.nl Important safety information Read this manual before attempting to install the device! Failure to observe recommendations included in this manual may be dangerous or cause a violation of the law. The manufacturer, Fibar Group S.A. will not be held responsible for any loss or damage resulting from not following the instructions of operating manual. The manufacturer is not responsible for any accidents related to theft, damage or breaching of the wiring, performed by an unauthorized person. - Page 3 www.domotica-shop.nl CONTENTS Description and features Installation Package contents Required equipment Choosing location Choosing and routing wires Mounting the installation box Mounting the in-wall part Connecting wires Mounting the on-wall part SD Card Configuration Requirements First login Creating home Configuration of the first device Connecting to the network User configuration Adding more devices...
-
Page 4: Description And Features
Description and features Description FIBARO Intercom can show you everyone who has arrived at your doorstep with a 180-degree high-definition view and night vision. This modern-looking, high-gloss device can be placed near the front door or gate to look after your safety. -
Page 5: Installation
www.domotica-shop.nl Installation Package contents On-wall part In-wall part Installation box Tightening tool Hex key 0.9mm Mounting screws M2 x 8mm 2.2mm x 12mm DIN 913 hex INSTALLATION - PACKAGE CONTENTS... -
Page 6: Required Equipment
www.domotica-shop.nl Required equipment Needle-Nose Pliers or Tweezers Wire stripper PH0 and PH1 Phillips Screwdrivers Professional equipment for mounting the installation box depending on the type of construction material INSTALLATION - REQUIRED EQUIPMENT... -
Page 7: Choosing Location
www.domotica-shop.nl Choosing location Recommended height of installation: 160 cm Do not install the device in direct sunlight! If this happens, try to shade the device to avoid overheating and to keep the sun off the lens and reduce flare. Long-term operating in direct sunlight may cause overheating of the device, its malfunctioning, and a significant temperature rise of a housing above the limit of safe operation for the user. -
Page 8: Choosing And Routing Wires
www.domotica-shop.nl Choosing and routing wires The device may be powered in two ways: 1) Power supply 12V DC (+/- 10%) 1A LPS (not included) 2) PoE (Power over Ethernet) PSE 48V Both powering modes work in parallel and may be connected at the same time with no effect on the device operation. The device may be connected to network in two different ways: 1) Ethernet - wired connection (recommended) 2) Wi-Fi - wireless connection... - Page 9 www.domotica-shop.nl When routing wires take into consideration: • The installation wires of the unit must be lead separately from the mains power wires to prevent the transmission interference and overvoltage on the control lines. • Wires inside the installation boxes should be as short as possible to prevent curling the wires and allow for easy assembling of the in-wall part.
-
Page 10: Mounting The Installation Box
www.domotica-shop.nl Mounting the installation box Before installation pay attention to: • Installation box must be mounted using the materials which will not cause the tension that could deform the shape of a box after the installation (e.g. by expanding). • Mounting in the drywall requires using screws with hooks (not included). -
Page 11: Mounting The In-Wall Part
Mounting the in-wall part To install the in-wall part: 1) Use a screwdriver to unscrew the small screw that secures the masking cap labelled with FIBARO logo. 2) Drag the wires through the hole located on the right of the in- wall part. -
Page 12: Connecting Wires
www.domotica-shop.nl Connecting wires To connect the wires: 1) Make sure that no wires are powered. 2) Remove the outer insulation to expose about 5 cm of the insulated inner wires, taking care not to damage them. 3) Separate and straighten the inner wires if twisted. 4) Cut the inner wires to 4 cm in length. - Page 13 www.domotica-shop.nl Connecting ethernet/POE cable: Connecting 12V DC power supply: ETH1-ETH8 inputs are related to specified numbers of wires in RJ-45 Inputs for connecting an external 12V DC power supply. Please connector according to the T-568B standard as shown below. double-check correct polarity of power supply. 12V GND o O g B b G br BR CAUTION...
- Page 14 www.domotica-shop.nl Connecting relays: Configurable relay outputs 30V/1A. Outputs are not designed for long-term supplying of external devices. Contacts are not connect- ed to the ground and can be connected with any polarity. R1 R1 R2 R2 Connecting tamper switch to external system: Anti-sabotage input, used for connecting to the external alarm system.
-
Page 15: Mounting The On-Wall Part
www.domotica-shop.nl Mounting the on-wall part To mount the on-wall part: 1) Install the masking cap and tighten it with a screw. 2) At this moment you can install a SD card (see “SD Card” on page 16 for more information). 3) Insert the on-wall part (metal flat plate should be on the left) and align it without using excessive force. - Page 16 SD Card The device allows for installing the microSD Card for local storage of recordings. FIBARO Intercom supports up to 128 GB microSDHC and microSDXC cards, Class 10 is recommended. 128 GB As for recording time, please refer to below chart.
-
Page 17: Configuration
• FIBARO ID account (which you can set up during the configuration process). Make sure that during the configuration of FIBARO Intercom your smartphone is connected to the same network as your device. During the setup stand close to the device. -
Page 18: First Login
First login Having a valid FIBARO ID account is necessary to use your device. Such account may be created through the same app that is designed to operate the Intercom. Look below and follow one of the procedures. Without existing FIBARO ID account: 1) Launch a downloaded FIBARO Intercom app. -
Page 19: Creating Home
www.domotica-shop.nl Creating home In this step, it is possible to create a new home or login to existing one. Configuration takes place through BLE (Bluetooth Low Energy) protocol. Make sure that Bluetooth is enabled on your smartphone. Create new home: 1) Create a home and name it. -
Page 20: Connecting To The Network
www.domotica-shop.nl Connecting to the network After selecting your Intercom from the list, you can establish a network connection. You can do this in three ways: via Wi-Fi or LAN (automatically or manually). Wi-Fi connection Make sure that the range of Wi-Fi signal is good enough. If the Intercom is located far from Wi-Fi router, it is strongly recommended to use Wi-Fi signal expanders nearby the Intercom. -
Page 21: User Configuration
4) Set your password for local access. Local password is obligatory when you use device in network without Internet access, stream camera image and you want to integrate it with FIBARO Home Center. Configuration summary The following information will be displayed as a summary of the configuration process: •... -
Page 22: Adding More Devices
All devices assigned to one Home should operate in the same network and must be connected in the same way (Wi-Fi or LAN). User roles There are three user roles available in FIBARO Intercom interface: 1) Administrator - can configure home, add and change settings of devices and add or invite users. The administrator can fully utilize the system (calling, opening the gate, history of actions). -
Page 23: Inviting Users
On invited user’s behalf: 1) Install FIBARO Intercom App and log in to the FIBARO ID account (the same that the invitation was sent to). 2) After logging in you can see a Home list and the one that user is invited to will be marked. -
Page 24: Resetting To Factory Settings
www.domotica-shop.nl Resetting to factory settings There are two ways of performing the reset of the device: through the mobile app or directly using the device. After completion, the Intercom will be restored to factory settings. Please notice that all stored recordings will also be removed! To reset the device through mobile app: 1) Open the app. -
Page 25: Device Operation
Device operation FIBARO Intercom allows to use rotating ring for entering PIN Codes set during the configuration process. Correctly entered PIN code may result in authenticating the user and opening the gate. Anyone who does not have a PIN code may use the button on the front to make a call. -
Page 26: Use Cases
www.domotica-shop.nl Use cases • Opening the gate with electromagnetic lock through the app 12V GND N1 GND N2 TMP TMP R1 R1 R2 R2 12/24V • Opening the gate through the wall switch at your home or near the exit 12V GND N1 GND N2 TMP TMP R1 R1 R2 R2... - Page 27 www.domotica-shop.nl • One switch for opening the wicket, another one for opening the gate 12V GND N1 GND N2 TMP TMP R1 R1 R2 R2 12/24V + - 230VAC 12/24V USE CASES...
-
Page 28: Specifications
www.domotica-shop.nl Specifications Power supply: 12V DC and/or 48V PoE DC supply parameters: 12V +/- 10%, 1A LPS PoE parameters (PSE): 36-57V, 350mA (802.3af, Class 0) Power consumption: up to 5W Conductor cross-section: 0.14 ... 0.34 mm² (AWG 26 ... AWG 22) Communication protocols: Ethernet 10/100BASE-TX, Wi-Fi a/b/g/n 2.4/5GHz, Bluetooth®... -
Page 29: Regulations
Declaration of conformity Hereby, Fibar Group S.A. declares that FIBARO Intercom is in compliance with the essential requirements and other relevant provisions of Di- rective 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: www.manuals.fibaro.com WEEE Directive Compliance Device labelled with this symbol should not be disposed with other household wastes. -
Page 30: Warranty Terms And Conditions
NIP 7811858097, REGON: 301595664, share capital PLN 1,182,100 than a material or manufacturing defect of the Device paid in full, other contact information is available at: www.fibaro. - the guarantee document is not valid or there is no proof of pur- com (hereinafter “the Manufacturer”) guarantees that the device... - Page 32 Industrieweg 18-14 3846BD Harderwijk Support: 0341 266615 www.domotica.support © 2017 Fibar Group S.A. All rights reserved Made in Poland www.fibaro.com 105446710101...
