  • Page 1 ROBOLINHO 3000 © Robot lawnmower Operating Instructions 474 481_b I 10/2012...
  • Page 2 Akku-Rasenmäher Robolinho 3000 © ..............................43 © 2 0 12 A L - K O KO BER G ROUP Kötz , Germa n y T h i s doc ument ation or excerpt s t h e re f r o m m a y n o t b e r e p r o d u c e d or d i s c lose d to third par ties wi t h o u t t h e e x p r e s s p e r m i s s i o n o f t h e A L - K O KO BER G ROUP.
  • Page 3 Original operating instructions Original operating instructions Contents About this handbook....................45 14.1 Explanation of symbols....................45 14.2 Disposal........................... 45 Scope of delivery......................46 15.1 Unpacking the machine....................46 Product description...................... 47 16.1 Product description......................47 16.2 Designated use....................... 47 16.3 Possible misuse......................47 16.4 Base station........................48 16.5...
  • Page 4 Original operating instructions 21.2 Starting programming......................63 21.3 Selecting the menu......................64 21.4 Program menu.........................64 21.5 Setting menu........................66 21.6 Information menu......................69 21.7 Program information......................69 21.8 Faults..........................70 Mowing........................... 71 Safety instructions......................51 22.2 Setting the cutting height....................71 22.3 Starting the Robolinho....................

  • Page 5: About This Handbook

    Via a return station identifi ed with the CCR mark. Do not dispose of the battery unless it is discharged. The user is obliged to return the battery. It can be returned to an AL-KO dealer, technician or service partner free of charge.

  • Page 6: Scope Of Delivery

    Unpacking the machine Carefully unpack the Robolinho© 3000 and its components and check everything for damage in trans- port. If there is any transport damage, immediately notify your AL-KO dealer, technician or service part- ner in accordance with the warranty conditions.

  • Page 7: Product Description

    Product description Product description The Robolinho 3000 is a fully automatic, batteryoperated lawnmower which moves freely within a defi ned © mowing area. The mowing area is defined by a boundary cable that is connected to the base station. In order for its battery to be recharged, the Robolinho 3000 moves along the boundary cable into the base ©...

  • Page 8: Base Station

    Boundary cable The boundary cable is secured with lawn pegs. If the supplied boundary cable is not large enough for your lawn, you can obtain an extension cable from your AL-KO dealer, technician or service partner. CAUTION! Damage to the boundary cable! Do not scarify the lawn in the area on either side of where the boundary cable is laid.

  • Page 9: Control Panel

    Product description 16.7 Control panel 1 HOME key 6 START/PAUSE key 2 LCD display 7 Multifunction key right 3 STOP key 8 Multifunction key left 4 Up arrow key 9 ON/OFF key 5 Down arrow key 10 Menu key Function of the keys The [HOME key] cancels the current mowing Press the [START/PAUSE key] to start the procedure.

  • Page 10: Sensors

    Original operating instructions 16.8 Sensors Security sensor If the Robolinho 3000 is lifted up by its carry handle during operation, a safety sensor stops the blade within © 2 seconds and switches off travel mode. Rain sensor The Robolinho 3000 is equipped with a rain sensor that interrupts the mowing procedure in case of rain, ©...

  • Page 11: Safety Instructions

    The equipment should be used only if in good order and condition Device and base station regularly for damage. Have damaged parts and batteries replaced or repaired by an AL-KO dealer, technician or service partner. Keep body and clothing away from cutting parts.

  • Page 12: Assembly

    Original operating instructions Assembly 18.1 Assembling the base station 1. Insert the base plate (3) with its front edge in the direction of arrow 1 into the plate of the base station (2), and fold upwards in the direction of arrow 2. 2.

  • Page 13: Laying The Boundary Cable

    Assembly 3. To avoid damage when mowing, make sure that the boundary cable is in direct contact with the ground at all points when you are laying it. 4. If there are places where the boundary cable is not in direct contact with the ground, secure these with an additional lawn peg.
  • Page 14 Original operating instructions 18.3.3 Route cable properly min. 15 cm min. 15 cm min. 30 cm When laying the boundary cable in walkways, it is necessary to maintain the minimum distances from obstacles and the minimum passage width, otherwise the Robolinho 3000 will not be able to operate ©...
  • Page 15 Assembly 18.3.4 Laying the cable around obstacles When laying the cable around obstacles, maintain the distances shown in the illustration. min. 30 cm min. 30 cm 0 cm min. 30 cm If there is a distance of 0 cm between the cables, it When the distance is at least 30 cm, the is possible for the cable to be driven over.

  • Page 16: Electrical Installation

    Original operating instructions Electrical Installation 19.1 Connecting the boundary cable to the base station 1. Remove the insulation from the boundary cable (2) after laying the cable and connect to the spring ter- minals (1). 19.2 Connecting the low-voltage cables to the transformer 1.

  • Page 17: Opening The Base Station

    Electrical Installation 19.3 Opening the base station The cover only has to be opened for the purpose of checking the LED displays. 1. To check the connection, open the cover (2) on the rear of the base station (1). 2. Unscrew the fastening screws (3) and remove the cover from the base station. 19.4 Checking the connection The LEDs must light up when the cables are connected.

  • Page 18: Startup

    Original operating instructions Startup 20.1 Preparations Before starting to operate the Robolinho 3000, © place it in its starting position in the defined mowing area. Comply with the specifi ed dimensions. ca. 1 m min. 1 m 20.2 Transport General CAUTION! Injuries due to the cutting blades! Make sure the cutting blade plate is pointing away from your body.

  • Page 19: Switching On

    Startup Transporting within the mowing area 1. Stop the Robolinho 3000 using [STOP key] (2). © 2. Switch off Robolinho 3000 at [ON/OFF key] © (1). 20.3 Switching on Status display Brill Model Roboline™ R30 Software # xxxxxx Serial-number xxxxxx 1.
  • Page 20 Original operating instructions 1. Use the corresponding [arrow keys] (1) or (2) to select the corresponding digits and confi rm each one with the [multifunction key] (4). 2. Enter the next 3 required digits in the same way. 3. Confi rm the last entry with [multifunction key] (3). Following this, the LCD display shows the [Change PIN] dialog box.
  • Page 21 Startup 20.3.7 Calibration For calibration, set up the Robolinho 3000 accordingly, see Preparations, page © CAUTION! The drive starts when the [START key] ispressed. Do not reach into rotating parts. ! Warning ! Drive starts Charge 1. The automatic calibration procedure starts when the [START key] is pressed. The [Drive starting] warning flashes on the LCD display.

  • Page 22: Checking The Cable Laying

    Original operating instructions 20.4 Checking the cable laying 1. Place the Robolinho 3000 about 1 metre in © front of the boundary cable. 2. Press the [HOME key], the Robolinho 3000 © moves along the boundary cable back towards the base station. 3.

  • Page 23: Programming

    Programming Programming 21.1 Overview of main menu The main menu of the Robolinho 3000 is divided up into the following submenus: © Program menu Setting menu Information menu Main menu Main menu Programs Information Settings Back Confirm Back Confirm Program menu Setting menu Information menu Programs...

  • Page 24: Selecting The Menu

    Original operating instructions 1. Switch on the Robolinho 3000 by pressing the [ON/OFF key]. © 2. Enter PIN code, Enter PIN code, page The PIN code may also be the factory code if no different code was entered during calibration. After the PIN code has been entered, the [Next mowing] information appears, or the current mowing duration.
  • Page 25 Menu item All days Menu item Day of week Mowing window deactivated The Robolinho 3000 mows on the right along the boun- Edge mowing dary cable. After mowing the edges, the Robolinho 3000 continues mowing the marked-out area. Normal mowing...

  • Page 26: Setting Menu

    Original operating instructions 1. Use the [up arrow key] or the [down arrow key] to select the [Programs] menu item until the star sym- bol appears to the left of the menu item. 2. Confirm with the [multifunction key right]. 21.4.4 Calling up entry points Entry points Programs...
  • Page 27 Programming 1. Use the [up arrow key] or the [down arrow key] to select the [Programs] menu item. 2. Call up the [Enter time] menu. 3. Confirm with the [multifunction key right]. 4. Select the required time with the [arrow keys] and confirm with the [multifunction key right]. 5.
  • Page 28 Original operating instructions 4. Use the corresponding [arrow keys] to select the required language and confirm with the [multifunction key right]. After confirming, the LCD display shows [Enter registration PIN]. 5. Press the [menu key] twice to confirm all entries and return to the main menu. The corresponding language only needs to be selected here during the initial start-up.

  • Page 29: Information Menu

    1. Use the [up arrow key] or the [down arrow key] to select the [Pr ogr ams ] menu item. 2. Confirm with the [multifunction key right]. 21.6.2 Call up hardware / software information Information Hardware Software Hardware AL-KO automatic lawnmower 3000 Version Software Manufacture Back Confirm Back...

  • Page 30: Faults

    Original operating instructions 21.8 Faults Display: Fault Date, time and fault code with fault message. Robolinho 3000 ©...

  • Page 31: Mowing

    The PIN code can be changed by the owner. The PUK code can be secured by registering on our website: http://robolinho.al-ko.com If the PIN code is entered incorrectly three times, it will be necessary to enter a PUK code. If the wrong PUK code is entered, the Roboline™ R30 will have to be sent in for it to be unlocked.

  • Page 32: Starting The Robolinho

    Original operating instructions 22.3 Starting the Robolinho 1. Switch on the Robolinho© 3000 by pressing the [ON/OFF key]. 2. Enter PIN code, Enter PIN code, page After the PIN code has been entered, the [Next mowing] information appears. The Robolinho 3000 ©...

  • Page 33: Maintenance And Care

    Maintenance and care Maintenance and care CAUTION! Injuries due to the cutting blades! Always switch off the Robolinho 3000 at the [ON/OFF key] before starting maintenance and © repair work. Disconnect the transformer of the base station from the mains. Always wear working gloves when carrying out maintenance and care jobs on the blade system! CAUTION! Damage to the electrical/electronic system byincorrect cleaning!

  • Page 34: Checking The Base Station

    If the contacts do not spring back into the ADVICE initial system, have them checked by an AL-KO dealer, technician or service part- ner, and renewed if necessary. 23.5 Check the rollers can move freely 1. Once a week, thoroughly clean the area around the rollers (1) with a hand brush or cloth.

  • Page 35: Renewing The Transformer Fuse

    If the operating time of the battery is reduced in spite of it being fully charged, have the battery replaced by a new genuine battery. This task should be carried out by an AL-KO dealer, technician or service partner.

  • Page 36: Exhaustively Discharged Battery

    If the battery charge level has dropped below the threshold set by the manufacturer as a result of ageing or excessively long storage, this means it cannot be recharged any longer. Have the battery and the monitoring electronic control unit checked by an AL-KO dealer, technician or service partner, and renew it if necessary. 23.11 Storage Before putting the robotic mower into storage for the winter, please make sure it is fully charged.

  • Page 37: Troubleshooting

    AL-KO service partner. Battery exhausted. Battery service life exceeded. Have battery renewed by an AL-KO ser- vice partner. Charging electronics faulty. Have charging electronics renewed by an AL-KO service partner.
  • Page 38 Original operating instructions Error message Possible cause Solution Cover has been deflected upwards Remove foreign body. CN002: Lift sensor by lifting or by a foreign body. CN005: Bumper deflected Automatic lawnmower has encoun- tered an obstacle and cannot free itself (collision close to base sta- tion).
  • Page 39 AL-KO service partner. Battery exhausted. Battery service life exceeded. Have battery renewed by an AL-KO ser- vice partner. Charging electronics faulty. Have charging electronics renewed by an AL-KO service partner. Automatic lawnmower does not Put automatic lawnmower into touch charging contacts.

  • Page 40: Examples Of Fault Messages

    © displays malfunctions and the status on the LCD display of the Robolinho 3000. © If this display reappears, do not continue operation. Have the Robolinho 3000 checked by your AL-KO © dealer, technician or service partner. Robolinho 3000 ©...

  • Page 41: Technical Data

    Technical data Technical data Robolinho© 3000 data Length in mm Width in mm Height in mm Weight in kg approx. 8 Mowing system electrical with 2 cutting blades Motor cutting blades rpm 3200 - 3600 Cutting height in mm 30 - 60 Cutting height adjustment 5-stage in mm 6 mm per stage Cutting width in mm...

  • Page 42: Appendix

    We hereby declare that this product in the form in which it is marketed by us complies with requirements of the harmonized EC directives, EC safety standards and the product-specific standards. Product Manufacturer Authorised representative Robot lawnmower AL-KO Kober GmbH Anton Eberle Type Hauptstraße 51 Ichenhauser Str. 14 Robolinho 3000 A-8742 Obdach D-89359 Kötz...

  • Page 43: Robolinho

    Notice Notice 474 481_b...
  • Page 44 Robolinho 3000 © ETK Robolinho 3000 Art.Nr. 119 356 470752 474752 (2) 505075 (2) 47089102 47410085 (2) 474118 454186 (2) 470987 518482 700147 47099001 505075 (4) 470871 474011 470892 474010 474009 119460 705960 (2) 454176 (2) 470932 (2) 705957 (2)
  • Page 45 ETK Robolinho 3000 ETK Robolinho 3000 Art.Nr. 119 356 510759 (2) 47401285 518483 (4) 47093785 474407 470921 47093801 474118 47408201 47484301 (2) 453959 (6) 474743 (2) 474416 47087801 470881 (2) 47093585 47087913 47408185 45450401 (2) 474068 (150m) 543554 (3) 47456913...
  • Page 46 Robolinho 3000 © Notice Robolinho 3000 ©...
  • Page 47 Notice 474 481_b...
  • Page 48 (+380) 44 / 4 92 33 96 (+380) 44 /4 92 33 97 AL-K O Geraet e Gmb H l Head Quarter I Ichenhauser Str. 14 I 89357 Koetz I Deuschland Telefon: (+49) 82 21/ 2 03- 0 I Telefax: (+49) 8221/203-138 I www.al-ko-com...
