- Page 1 Access to your home by the tone of your phone™ Door & Hardware Federation Raising Standards ® MULTI LAYER INSTALL GUIDE...
- Page 2 Contents. 3. Overview 4. Multi Layer Connections 5. I/O Board Connections 6. Pass Thru & I/O Expansion Board Connections 7. / 8. / 9. / 10. / 11. SMS Programming...
- Page 3 Low Profile. The PCB connects via a supplied ribbon cable back to the I/O PCB (Input/Output) that is housed inside the back box, this is where you will find all the usual Telguard connections. The Multi Layer board features a built in GSM module where the SIM and antenna both connect.
- Page 4 HY-CAN Multi Board...
- Page 5 I/O Board Power Relay (Changeover) • Switching voltage max 60V AC or DC. • Max switching current 2 Amp. Opto Relay (Normally Open) • Switching current max 200mA. • Max switching voltage 60V AC or DC.
- Page 6 Pass Thru Board I/O Expansion Board...
