Ecolink Siren+Chime User Manual

SIREN+CHIME (Z-WAVE PLUS

PRODUCT OVERVIEW

The Ecolink Siren+Chime is a Z-Wave Plus
automation network for the purpose of sounding a siren or chime when told to do so by a controlling device. It can
be used to sound its siren when a house has been broken into; to chime when a monitored door or window is
opened; and to give audible user feedback on the state of the security system with entry-delay and exit-delay
tones.

Plug and Play for Z-Wave Plus enabled Alarm Systems

Chime (Programmable) to alert when zones are opened

120 dB Siren

Can be plugged into any AC outlet and screwed into faceplate for solid installation

PRODUCT SPECIFICATIONS


For indoor use only

Operating Frequency 908.42 MHz

Operating range: Up to 100 feet (30.5 meters) line of sight

Operating temperature: 0˚C to 49˚C, 32˚F to 120˚F (ambient temperature)

HOW DO I USE THIS?

The Siren+Chime can be enabled through "scenes" to make noise under certain conditions defined in your scene.
A scene on some gateways can be called an "automation," or a "Smart App."
However, not every Z-Wave Plus
via their user interface. You should check with the manufacturer of your particular Z-Wave Plus
if they support our device explicitly. If they do not explicitly support our device, it may still work with limited
functionality. In fully supported controllers, the Siren+Chime device would show up as such, and all or most
functionality will be enabled within the user interface, otherwise this device may appear as a generic electric
outlet and be controlled as if it were a lamp. An incomplete list of compatible Z-Wave Plus
found on our website at www.discoverecolink.com.
If your Z-Wave Plus controller only allows the Siren+Chime to be controlled as if it was single electric outlet,
TM
you can choose whether your Siren+Chime is just a siren or just a chime via the jumper labeled "J5" on the back of
the device. With the jumper placed, the device will enable its chime functionality, and with the jumper removed
(default) the siren functionality is enabled.
© 2016 Ecolink Intelligent Technology Inc.
enabled device intended to integrate into a Z-Wave Plus
TM
controller allows our devices to appear for the user to properly use and control
TM
)
TM
home
TM
controller to see
TM
gateways may be
TM
PN SC-ZWAVE5-ECO R1.01
