- Page 1 Bittium Tough Mobile Quick start guide...
-
Page 2: Device At-A-Glance
USB 3.0 port and protective cover The ambient light sensor and proximity sensor are located next to the camera on the front of the Tough Mobile. The micro USB 3.0 port is located on the bottom of the Tough Mobile. - Page 3 The Tough Mobile is water and dust resistant (IP67). In order to maintain the water and dust resistance the battery cover, the USB connector cover and the headset cover must be properly closed. Submerging the Tough Mobile in water will degrade touch screen responsiveness and audio quality.
-
Page 4: Box Contents
OFF before removing the battery and inserting SIM card(s). Getting started To start using the Tough Mobile first remove the battery cover and insert SIM card(s). In- sert a micro SD card into a micro SD card slot. SIM card 1 is inserted into SIM card slot 1 and the battery is inserted. - Page 5 Prior to using the Tough Mobile the battery should be fully charged using the charger and USB3.0 cable provided inside of the sales package. The Back Cover of the Tough Mobile is intentionally tight to meet IP67 requirements. Apply enough force via the small notch in the Back Cover to pry the cover open.
- Page 6 Once the Tough Mobile has powered up, fol- low the on-screen instructions to set up the device using the Security Wizard. Security wizard The Tough Mobile is equipped with a Securi- ty Wizard that is launched during the initial power up of the device. The Security Wizard is used to set up a number of different de- vice settings.
-
Page 7: Lock Screen
Lock screen Turning off the display locks the Tough Mo- bile. The Tough Mobile also locks after a period of inactivity. Turn the display off by pressing the power key once. The display can be turned on by pressing the power key or multiuse key. -
Page 8: Home Screen
To return back to the lock screen, push the arrow in the left top corner. Home screen Once the Tough Mobile is successfully booted up and the screen is unlocked, it will display the home screen. Press the APPS symbol in the middle section of the bottom of the screen to open the application grid. - Page 9 Apps Back Recent apps Home Encrypted email The Tough Mobile supports email encryp- tion using OpenPGP. PGP related key man- agement, encryption, decryption and key signing are performed using the OpenKey- Chain application. To set up the email encryption, the security keys must be created or imported for the cipher.
- Page 10 2. Select the encryption algorithm and key strength. More encryption options are available in the advanced settings. 3. A key icon in the status bar indicates the PGP is set up and ready to use. Bittium Tough Mobile Quick start guide...
-
Page 11: Device Encryption
More information about OpenKeyChain can be found at http://www.openkeychain.org/ Device encryption The Tough Mobile supports file system en- cryption for both the device internal flash memory and micro SD card. The internal flash memory is encrypted by default. To enable micro SD card encryption select “Security”... - Page 12 3. Select active SIM card (SIM card 1 or SIM card 2). 4. Launch camera application. 5. Launch a defined application Application permission firewall The Tough Mobile allows the user to restrict access permissions of applications to phone Bittium Tough Mobile Quick start guide...
-
Page 13: Tampering Detection
Change the application permissions from the Security Settings menu. Tampering detection The Tough Mobile is equipped with hard- ware tamper detection. An intrusion, other than opening the back cover, will result in a notification from the Security Wizard. -
Page 14: Important Health And Safety Precautions Information
Aviation application, is prohib- ited and will void your warranty. Bittium Tough Mobile Quick start guide... - Page 15 CAUTION Do not allow children to play with the Tough Mobile since it contains small parts that could become detached and create a choking hazard. NOTE When using your device for pro- longed periods of time, such as when you’re talking on the phone, charging...
-
Page 16: Important Customer Information
Important customer information The Tough Mobile is a wireless device, containing a radio transmitter and receiver which emit radio fre- quency energy during its use. Most modern electron- ic equipment is shielded from RF signals. However, certain electronic equipment may not be shielded against the radio signals from a wireless phone. -
Page 17: Declaration Of Conformity
Turn the Tough Mobile OFF in any facility where posted notices so require. To avoid interfering with blasting operations turn Tough Mobile OFF when in a blasting area or in areas posted: “Turn off two-way radio”. Obey all signs and instructions. -
Page 18: Fcc Notice To Users
FCC radio frequency (RF) Exposure Guidelines in Supplement C to OET65.This trans- mitter must not be co-located or operated in con- junction with any other antenna or transmitter. Bittium Tough Mobile Quick start guide... -
Page 19: Specific Absorption Rate (Sar) Certification Information
If this Product is determined to be defective with- in the 1 year warranty period, Bittium will repair the Product or replace it with a new or refurbished Product, at its option, at no charge to the customer, except as set forth below. - Page 20 Bittium shall not be liable for errors con- tained herein or for damages in connection with the furnishing, performance, or use of this material.
