4.3 SUMMARY OF LED COMBINATIONS AND THEIR MEANING

Use the table below to determine the condition of the panel.
LEDs LIT LED CONDITION
POWER CONSTANT GREEN
GEN FLT CONSTANT YELLOW
ONLY
GEN FLT & CONSTANT YELLOW
SUPPLY FLT FLASHING YELLOW
GEN FLT & CONSTANT YELLOW
EARTH FLT FLASHING YELLOW
GEN FLT & CONSTANT YELLOW
ZONAL FLT FLASHING YELLOW
GEN FLT & CONSTANT YELLOW
ZONAL FLT FLASHING YELLOW
GEN S/C FLASHING YELLOW
GEN FLT & CONSTANT YELLOW
SND FLT FLASHING YELLOW
GEN FLT & CONSTANT YELLOW
SND FLT FLASHING YELLOW
GEN S/C FLASHING YELLOW
GEN FLT & CONSTANT YELLOW
SYSTEM FLT CONSTANT YELLOW
GEN FIRE CONSTANT RED
ONLY
GEN FIRE & CONSTANT RED
ZONE FIRE CONSTANT RED
GEN FIRE & CONSTANT RED
ZONE FIRE & CONSTANT RED
GEN DISABLE CONSTANT YELLOW
& DEL CONSTANT YELLOW
GEN DISABLE FLASHING YELLOW
(FAST – 4 HZ)
GEN DISABLE FLASHING YELLOW
(SLOW – 0.5 HZ)
GEN DISABLE FLASHING YELLOW
ZONE DISABLE (SLOW – 0.5 HZ)
GEN DISABLE CONSTANT YELLOW
ZONE DISABLE CONSTANT YELLOW
GEN DISABLE CONSTANT YELLOW
DEL CONSTANT YELLOW
GEN TEST FLASHING YELLOW
ZONE DISABLE FLASHING YELLOW
(VERY SLOW – 0.25 HZ)

4.4 CHECKING THE PANELS INDICATION LEDS

Turn the key switch to "Controls Enabled" position then press the LED test button (Button 4). All the LEDs on the
front panel will light, and the panel's internal buzzer will also sound.
Approved Document No: GLT.MAN-102
Issue: 1.3 Authorised: GH
PANEL STATUS
The panel is supplied with power, and has no faults / fires (System Normal)
Problem with keyswitch connections
There is a problem with either the mains supply or the battery backup
There is a wiring problem. One of the cables is touching the earth screen.
There is an open circuit fault in the wiring of the zone indicated.
There is a short circuit fault in the wiring of the zone indicated.
There is an open circuit fault in the wiring of one or both of the sounder
circuits
There is a short circuit fault in the wiring of one or both of the sounder
circuits
A processor fault has occurred. To reset, turn keyswitch on then back off. If
problem persists, consult your dealer.
A manual evacuation has occurred.
The sounders will be active.
A fire has occurred in the zone indicated.
The sounders will be active.
A fire has occurred in the zone indicated.
The sounders have a delay set, and will become active after the
programmed delay. To override the display, press delay override.
The panel is ready for selecting disable or test mode
The panel is in SELECT DISABLEMENT MODE
The user is scrolling through zones to select which one to disable/or user
has just enabled the zone.
The indicated zone is disabled.
The Sounders are delayed by the amount set on the rotary switch.
The indicated zone is in Test Mode.
Date: 9/6/2004
PAGE 6
