4.3.2 T
IMECODE DISPLAY SETTINGS
The Connect timecode display with sequence tool [1] option allows the time code display to start
simultanously with sequence. The delay time [2] defines a time lag after which the display starts.
4.3.3 LED HEAD
LIGHT
1
4
6
7
9
measured at a different position (see image below).
Follow these steps for adjusting the illuminance:
1. Enter a lux value into field [2]:
Image Engineering
Software Documentation
1
2
SETTINGS AND
2 3
5
8
10
11
lightSTUDIO
( STUDIO-M)
LIGHT
C
ONTROL
With the LED lightHEAD more functionality and
flexibility is available in comparison to the Standard
lightHEAD. The iQ-LED technology allows to generate
individual illuminants with predefined illumination
values and to switch between the different illuminants
very rapidly.
Calibration:
Before using the LED lightHEAD, it needs to be
calibrated. The procedure described below must be
undertaken in a dark surrounding without any stray light
entering the light box. Also ensure that the aperture of
the built-in spectrometer in the bottom plate is not
covered. Both steps, illuminance adjustment and
spectral calibration, should always be performed
combined and in the same order.
1) The Illuminance adjustment is necessary in order
to regulate the deviation of the illuminance
measurement of the spectrometer, whose aperture is
placed in the bottom plate of the light box. The
maximum achievable lux value as noted in the
acceptance protocol of your lightSTUDIO however is
9
