WARNING: To ensure your safety, please do not attempt to assemble this seesaw without reading this instruction manual
carefully. Failure to comply with this warning may result in injury and/or property damage.
• Prior to assembly, this seesaw includes small parts/accessories that are not suitable for children under 3 years of age as
they may cause a choking hazard.
• This seesaw should be assembled by 2 adults.
• Only use this seesaw on a soft, flat level surface.
• This seesaw has a maximum user weight of 34kg per unit/seat. The total weight on the swing set at any time
must not exceed 68kg.
• Only one child per unit/seat at any time.
• This seesaw is suitable for children 3-9 years of age.
• This seesaw is designed for outdoor domestic use only, it is not intended for commercial use in play centres, nurseries etc.
For parts and service enquiries, please contact Action Spares on 1800 465 070 or e-mail service@actionspares.com.au
Rotating Seesaw
S002029
Instruction Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Action S002029
Summary of Contents for Action S002029
- Page 1 • This seesaw is suitable for children 3-9 years of age. • This seesaw is designed for outdoor domestic use only, it is not intended for commercial use in play centres, nurseries etc. For parts and service enquiries, please contact Action Spares on 1800 465 070 or e-mail service@actionspares.com.au...
- Page 2 Contents Important Safety Information Parts List Assembly Instructions Warranty Information S002029 Action Rotating Seesaw...
-
Page 3: Important Safety Information
15. Do not wear apparel such as hats with straps, helmets, scarves, garments with pull strings or any other item of loose clothing while using the swing set as children can get trapped and may be unable to free themselves causing serious injury. S002029 Action Rotating Seesaw... -
Page 4: Parts List
Allen Key Upper Support Tube M6x25mm Bolt Lower Support Tube M6x70mm Bolt Leg A (lower holes) M6x52mm Bolt Leg B (higher holes) M6x63mm Bolt Handle Bar M6x94mm Bolt Seat Spacer Some parts may be supplied pre-assembled. Note: S002029 Action Rotating Seesaw... -
Page 5: Assembly Instructions
Service Centre to have replacement parts sent out prior to beginning assembly (details can be found in the warranty pages at the end of this manual). Step 1 Attach 1 x Seat (8) to 1 x End Bar (2) using 4 x M6x25mm Bolts (S1). Repeat this for the other side. S002029 Action Rotating Seesaw... - Page 6 The end bars can be set to the desired length by adjusting which 2 holes of the end bar are used Note: to secure these to the centre bar. Each end bar must be secured into place using 2 bolts, failure to comply with this warning Warning: may result in serious injury to the user. S002029 Action Rotating Seesaw...
- Page 7 Bolts (S5). Next attach 2 x Leg Bs (higher holes) (6) to opposite sides of the Lower Support Tube (4) using 2 x M6x94mm Bolts (S5). Finally slide the Upper Support Tube (3) into the Lower Support Tube (4). S002029 Action Rotating Seesaw...
-
Page 8: Warranty Information
2/24 Anderson Road, Smeaton Grange, NSW 2567 – if mailing please include your contact details. A service representative will then assist you in the appropriate action to be taken. For efficient processing of your enquiry please have proof of purchase, the date of purchase and the retailer name you purchased the item from, and the brand on the product. - Page 9 9:00am – 4:30pm Monday to Friday (excluding Public Holidays) 9:00am – 3:00pm Saturday This product is warranted and distributed by: Action Sports of 48B Egerton St, Silverwater NSW, 2128 Phone: (02) 8799 3500 © 2017 Action Sports Equipment Pty Ltd.
