- Page 1 GhosT-OLED Series Manual Date Revision No. Author Check Final Check Description 28.09.2016 BVT/TSN/DWN First Draft...
-
Page 2: Table Of Contents
TABLE OF CONTENT Important information Safety instructions Damage prevention Operating conditions Overview GhosT-OLED Series Introduction 2.1.1 GhosT-OLED-I (Installation) 2.1.2 GhosT-OLED-PT (primeTOUCH) GhosT-OLED Setup Versions 2.2.1 GhosT-OLED Table-Stand Version (TV) 2.2.2 GhosT-OLED Straight Version (SV) 2.2.3 GhostT-OLED Straight Offset Version (SOV) - Page 3 Straight Offset Version Certification Note: These installation instructions must always be handed over to the installing person Note: Read these instructions carefully before installing the system Copyright © 2016 LANG AG. All rights reserved. Only a qualified person should install this product...
-
Page 4: Important Information
Do not open the housing of the display otherwise electric shocks may occur. There is no need • for users to open the housing of the display. Please refer to Lang-AG for any service works. Do not expose the screen to water or moisture to prevent electric shocks. -
Page 5: Operating Conditions
1.3 Operating conditions Temperature: 25 +/-10°C • Humidity: 55 +/-20% rH • Operating time: less than 12 hours a day • Display pattern should be changing continuously to avoid any kind of image retention • No sunlight or any other warm light sources directed onto the screen •... -
Page 6: Ghost-Oled-I (Installation)
This version provides a frameless glass surface, thinner than 9 mm. With its frameless but robust design the GhosT-OLED-I version is perfect for exclusive, futuristic installations. The display is available in each of the three installation options whereby the Table-Stand Version is pictured below. -
Page 7: Ghost-Oled Setup Versions
2.2 GhosT-OLED Setup Versions The three different setup versions for GhosT-OLED-I and -PT will be described briefly in the following passage. Please note: All images present the GhosT-OLED-I, but basically the same applies also to GhosT-OLED-PT. 2.2.1 GhosT-OLED Table-Stand Version (TV) For flexible use and fast setup the Table-Stand Version is recommended. -
Page 8: Ghostt-Oled Straight Offset Version (Sov)
2.2.3 GhostT-OLED Straight Offset Version (SOV) The straight-offset version provides all the advantages of the Straight Version with an additional mounting surface for leveled installations. It uses the same mounting points as the Straight Version. Figure 5: GhosT-OLED-I, SOV Option, backside... -
Page 9: Scope Of Delivery
3. Scope of delivery Note: Please check the delivery for completeness and damage immediately after you receive the shipment. Please contact your supplier in case of missing or damaged parts. GhosT-OLED-I delivery scope GhosT-OLED-PT delivery scope Quantity Item Quantity Item... -
Page 10: Pack-/ And Unpack-Instructions
4. Pack-/ and unpack-instructions GhosT-OLED units get shipped in a functional flight case designed for all three installation versions. Caused by the universality the units get inserted upside down. Note: Read the following instructions carefully to prevent injuries to humans or damages to the system and environment. - Page 11 Foam cover 1. The glass surface of the GhosT-OLED-I Glass surface version is protected with an additional User side foam cover. Remove the cover carefully and store it safely. Note: For packing follow the provided steps backwards...
-
Page 12: Straight Version & Straight Offset Version
4.2 Straight Version & Straight Offset Version Description Illustration 1. Make sure that the brakes of the flight case are tightened 2. Open the front cover of the flight case 3. Open the top cover of the flight case Straight Version 1. - Page 13 Foam cover 1. The glass surface of the GhosT-OLED-I Glass surface version is protected with an additional User side foam cover. Remove the cover carefully and store it safely. Note: For packing follow the provided steps backwards.
-
Page 14: Installation Instructions
5. Installation instructions 5.1 Mechanical installation All versions of the GhosT-OLED series are based on the same housing system which makes them easy and fast to setup. Before you start installing the screen, follow the instructions provided in 3 Scope of delivery and 4 Pack-/ and unpack-instructions. Note: Read the following instructions carefully to prevent injuries to humans or damages to the system. -
Page 15: Screw Hole Pattern
5.1.2 Screw hole pattern Version Screw hole pattern in mm [In] GhosT- OLED-I Note: The red marked area cannot be used. GhosT- OLED-PT Note: The red marked area is only available in case of using the Table-Stand Version... -
Page 16: Installation Possibilities
5.2 Installation possibilities 5.2.1 GhosT-OLED Table-Stand Version Set up on leveled surfaces, the GhosT-OLED TV option is able to run without additional mounting, but it’s recommended to mount at least 4 screws to the exhibition furniture to hold the unit in place. It’s also made for angled surfaces or portrait mode applications. - Page 17 5.2.2 GhosT-OLED Straight Version The GhosT-OLED Straight Version can only be mounted correctly by using all of the provided mounting points. Therefore it’s required to work in a team of at least three persons. Two persons are needed to align the display to the screw-hole pattern while the third person can insert the screws into the mounting points.
- Page 18 5.2.3 GhosT-OLED Straight Offset Version The GhosT-OLED Straight Offset Version can only be mounted correctly by using all of the provided mounting points. Therefore it’s required to work in a team of at least three persons. Two persons are needed to align the display to the screw-hole pattern while the third person can insert the screws into the mounting points.
-
Page 19: Connector Panel And Control Possibilities
6. Connector panel and control possibilities All versions share a similar connector panel on the backside of the table foot. Figure 9: GhosT-OLED connector panel 6.1 Power Input, IR-Receiver and optional touch These components are located at the lower right side of the connector panel like shown below:... -
Page 20: Video Input Connectors
Description technical design AC IN connector IEC socket Main Power switch 2 pin rocker switch primeTOUCH USB (optional) USB type A, female External IR-receiver input 3,5 mm jack, female 6.2 Video input connectors The GhosT-OLED provides three different video input connectors. All of them are located at the upper left side of the connector panel like shown below: The native input timing for the GhosT- OLED series is 1920 by 1080 @60p. -
Page 21: Local Control
6.3 Local control The GhosT-OLED series provides a user-friendly keyboard which is located at the upper right side of the connector panel like shown below: Description technical design Menu button Short travel key switch Down button Short travel key switch Decrease button Short travel key switch Increase button... -
Page 22: Remote Control
Description technical design USB connector USB type A, female Note: for service access only RS-232C connector D-sub, 9 pin, female LAN port RJ45, female Status LED G, leaded LED Reset Button Short travel key switch 6.4.1 Remote control All units are shipped including a remote control like described in 3 Scope of delivery. The important functions that are required to set up a GhosT-OLED are explained below. -
Page 23: On-Screen-Display (Osd) Menu Guide
6.4.2 On-Screen-Display (OSD) menu guide... -
Page 24: Web Interface
Note: These menu items are not adjustable Note: This function is only activated when using VGA 6.4.3 Web interface All displays of GhosT-OLED series can be controlled by an easy operable web interface which provides several capturing and controlling options. The picture below shows the welcome screen which allows you to read off ambient parameters and current fan values. -
Page 25: Primetouch Option
7. primeTOUCH option As HID (human interface device) the primeTOUCH is a plug and play capable system. For advanced features like calibrating the touch coordinates to the image or running a diagnose of the system you need to install a special software. It is called “Multi Touch Platform” and it is provided on an USB stick that comes with every GhosT-OLED unit. -
Page 26: Transparency
Note: If you are designing interactive content consider the pixel shift functionality. For example buttons should have an adequate size. 8.2 Transparency Black colored content parts will appear transparent so it’s recommended to provide as much black parts as possible during content design to highlight the panel transparency. Such content will also minimize image retention. -
Page 27: Troubleshooting
- Driver is not installed - Check if driver is installed - Not calibrated correctly - Calibrate device (refer to 7 primeTOUCH option) Please contact support if none of the solutions is working: ghost-oled@lang-ag.com 10. Specifications Item Specification Unit Note... - Page 28 With external IR receiver Local Control Keyboard On back side Physical Specification Dimensions See: 11. Product outlines Weight GhosT-OLED-I GhosT-OLED-PT Electrical Power Consumption 100 - 240 V~ / 2A MAX / 50 - 60 Hz Environmental Conditions Storage Temperature Min: 5 °C...
-
Page 29: Product Outlines
11. Product outlines 11.1 Drawings GhosT-OLED-I 11.1.1 Table-Stand Version Figure 14: GhosT-OLED-I TV Option, front, side, bottom view... -
Page 30: Straight Version
11.1.2 Straight Version Figure 15: GhosT-OLED-I SV Option, front view Figure 16: GhosT-OLED-I SV Option, back, side view... -
Page 31: Straight Offset Version
11.1.3 Straight Offset Version Figure 17: GhosT-OLED-I SOV Option, front view Figure 18: GhosT-OLED-I SOV Option, back, side view... -
Page 32: Drawings Ghost-Oled-Pt
11.2 Drawings GhosT-OLED-PT 11.2.1 Table-Stand Version Figure 19: GhosT-OLED-PT TV Option front, side, bottom view... -
Page 33: Straight Version
11.2.2 Straight Version Figure 20: GhosT-OLED-PT SV Option front view Figure 21: GhosT-OLED-PT SV Option back, side view... -
Page 34: Straight Offset Version
11.2.3 Straight Offset Version Figure 22: GhosT-OLED-PT SOV Option front view Figure 23: GhosT-OLED-PT SOV Option back, side view... -
Page 35: Certification
12. Certification... - Page 36 Made in Germany www.lang-ag.com Schlosserstraße 8 51789 Lindlar Germany 09/16...
