8
8
6
6
4
4
12 10
12 10
2
2
0
0
MANLEY
MANLEY
LABORATORIES INC.
LABORATORIES INC.
REDUCTION dB
REDUCTION dB
IN
IN
BYPASS
BYPASS
BALANCE
BALANCE
ADJUST
ADJUST
A
H
A
IN / BYPASS
B.
COMP. / LIMIT
C.
RECOVERY
D.
THRESHOLD
E.
OUTPUT ATTENUATE
F.
ATTACK
G.
DUAL INPUT
I.
LINK
I.
POWER ON/OFF
H.
GR METER
FRONT PANEL
MANLEY
MANLEY
STEREO VARIABLE MU® LIMITER COMPRESSOR
STEREO VARIABLE MU® LIMITER COMPRESSOR
RECOVERY
RECOVERY
OUTPUT
OUTPUT
FAST
FAST
SLOW
SLOW
THRESHOLD
THRESHOLD
ATTACK
ATTACK
LIMIT
LIMIT
COMPRESS
COMPRESS
MIN
MIN
MAX
MAX
SLOW
SLOW
FAST
FAST
METER
METER
B
C D
E F
Switched in bypass mode, (down position) all effects of the limiting circuitry are
bypassed and will not affect the audio signal. In the bypass mode , the audio
signal passes from the input directly to the output.
Selects compression ( 1.5:1) or limiting (4:1) function. Compression is soft -knee,
Limit is a sharper knee. At greater than 12dB of limiting the ratio increases (up to
20:1 maximum)
Recovery times can be selected between
a.
VERY SLOW
b.
SLOW
c.
MEDIUM
d.
FAST
e.
VERY FAST
Continuously variable gain reduction threshold control.
Determines the necessary amplitude for compression or limiting to take effect.
Most extreme effect is at the MIN (fully counter clockwise) position. The lower
the threshold, the more that gets limited.
Continuously variable attenuation of output signal leaving the amplifier circuitry.
Full attenuation occurs at the full counterclockwise position.
This control is active only in IN mode.
Continuously variable sensitivity of transient detection. Determines the necessary
length of transient to initiate gain reduction. Fast =25mS, Med =50mS, Slow
=70mS.
Fully counter clockwise at the slowest setting will prevent most percussive
signals from causing limiting or compression.
Continuously variable attenuation of input signal entering the amplifier limiting
circuitry
Full attenuation occurs at the fully counterclockwise position.
This control is active only in IN mode.
When switched to "SEP" left side is independent from the right side. When
switched to "LINK"
both channels are reduced in gain by the same number of dB. This insures that
the stereo image is unchanged. The METERs remain independent to help set
THRESHOLDs.
Power is supplied to the unit when switched UP. Meters will illuminate
Measures in decibels amount of reduction
DUAL INPUT
DUAL INPUT
OUTPUT
OUTPUT
RECOVERY
RECOVERY
FAST
FAST
ATTACK
ATTACK
THRESHOLD
THRESHOLD
SEP
SEP
LINK
LINK
FAST
FAST
SLOW
SLOW
MAX
MAX
POWER
POWER
G H I
E F
C D
8 seconds
4 seconds
.6 seconds
.4 second
.2 second
6
8
8
6
6
4
4
10
10
12
12
MANLEY
MANLEY
SLOW
SLOW
LABORATORIES INC.
LABORATORIES INC.
REDUCTION dB
REDUCTION dB
LIMIT
LIMIT
COMPRESS
COMPRESS
MIN
MIN
METER
METER
ADJUST
ADJUST
BALANCE
BALANCE
B
H
2
2
0
0
IN
IN
BYPASS
BYPASS
A
