Cordless Pole Chainsaw / Hedge
Trimmer
User Manual
[Revision 3.0 April 2017]
READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY
DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by
this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Baumr-AG PLTCLSBMRACT2
Summary of Contents for Baumr-AG PLTCLSBMRACT2
- Page 1 Cordless Pole Chainsaw / Hedge Trimmer User Manual [Revision 3.0 April 2017] READ THIS MANUAL CAREFULLY BEFORE USE – FAILURE TO DO SO MAY RESULT IN INJURY, PROPERTY DAMAGE AND MAY VOID WARRANTY. • KEEP THIS MANUAL FOR FUTURE REFERENCE. • Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description and packaging.
-
Page 2: Table Of Contents
Cordless Pole Chainsaw / Hedge Trimmer Table of Contents Safety ..............................3 Chainsaw............................. 8 Parts Identification............................8 Set-Up ................................ 9 Charging the Battery .......................... 11 Operation ..............................11 Saw Chain Tension Adjustment ......................11 Cutting ............................... 13 Maintenance ............................13 Cleaning ............................ -
Page 3: Safety
Cordless Pole Chainsaw / Hedge Trimmer Safety • WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. • Save all warnings and instructions for future reference. The term "power tool"... - Page 4 Cordless Pole Chainsaw / Hedge Trimmer − Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in moving parts. − If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 5 Cordless Pole Chainsaw / Hedge Trimmer • Never attempt to open the battery. • When the battery pack is not in use, keep it away from metal objects that can make a connection between its terminals. Shorting the battery terminals together may cause burns or a fire. •...
- Page 6 Cordless Pole Chainsaw / Hedge Trimmer • Do not probe the charger. • Intended for indoor use only. • The battery needs to be charged before first use and whenever it fails to produce sufficient power on jobs that were easily done before. •...
- Page 7 Cordless Pole Chainsaw / Hedge Trimmer • Never stand on a ladder or other type of unstable support while using the tool. • Always use both hands to operate tool. Keep a firm, steady pressure while cutting but do not try to force the tool. •...
-
Page 8: Chainsaw
Cordless Pole Chainsaw / Hedge Trimmer Chainsaw Parts Identification Part Name Part Name Saw chain Grip area Guide bar Buckle Scabbard Strap Trigger safety button Power head Handle Top tube Trigger Locking knob Battery Under tube Battery release button E&OE ©2017 Bäumr-AG... -
Page 9: Set-Up
Cordless Pole Chainsaw / Hedge Trimmer Set-Up IMPORTANT! The chainsaw may come with plastic spacers over or around the bar studs - the spacer is for shipping purposes only and must be removed before mounting the chain bar. After removing the chain brake cover, remove any spacers, then mount the chain bar as described. - Page 10 Cordless Pole Chainsaw / Hedge Trimmer 4. Secure the strap buckle with a screw (see figure below): 5. Fill the chain saw oil tank with engine oil (IMPORTANT: Tighten the cap securely after filling). 6. To insert the battery pack, find the slots in the underside of the handle and slide the battery into the groove until the battery release button (#16) "clicks"...
-
Page 11: Charging The Battery
Cordless Pole Chainsaw / Hedge Trimmer Charging the Battery 1. Remove the battery from the tool. 2. Plug the charger electrical cord into the charger base. (IMPORTANT: Do not use any other charger, only use the supplied charger). 3. Plug the charger into a 240VAC electrical supply socket. The charger LED will light up green. (IMPORTANT: Do not charge by means of a generator or DC power source.) 4. - Page 12 Cordless Pole Chainsaw / Hedge Trimmer 2. Pull the chain out 3mm (1/8") from the guide bar with light force then release it (see figure below). If chain lightly snaps back into place, tension is correct. A slight gap of 1.5mm (1/16") or less between chain and bottom of guide bar is acceptable.
-
Page 13: Cutting
Cordless Pole Chainsaw / Hedge Trimmer Cutting • Use both hands to firmly hold the tool at the handle and the pole. Use designated grip areas and strap when operating the tool (see figure to the right). • Make sure that your footing is secure. Keep your feet apart and put your weight evenly on both feet. -
Page 14: Sharpening The Chain
Cordless Pole Chainsaw / Hedge Trimmer Sharpening the Chain Keep the chain sharp – a sharp saw will cut faster and more safely. A dull chain will cause undue sprocket, guide bar, chain, and motor wear. If you must force the chain into the wood and cutting creates only sawdust with few large chips, the chain is dull. -
Page 15: Replacing The Saw Chain
Cordless Pole Chainsaw / Hedge Trimmer Replacing the Saw Chain IMPORTANT: Do not clamp the chainsaw in a vice to replace the saw chain or guide bar. Replace the chain when cutters are too worn to sharpen or when the chain breaks. Only use replacement chain that is indicated in this manual. -
Page 16: Storage
Cordless Pole Chainsaw / Hedge Trimmer 8. Adjust chain tension. 9. Securely tighten the guide bar screw with a suitable spanner. CAUTION! Do not place the chain on the saw backwards. If chain is backwards, saw will vibrate badly and will not cut. -
Page 17: Hedge Trimmer
Cordless Pole Chainsaw / Hedge Trimmer Hedge Trimmer Parts Identification Part Part Trigger safety button Lock button Main switch handle Blade Battery pack Blade sheath Strap guard Charger Grip area Charger station Guard Charging indicator E&OE ©2017 Bäumr-AG... -
Page 18: Set-Up
Cordless Pole Chainsaw / Hedge Trimmer Set-Up IMPORTANT! Cutting edges on the trimmer are sharp. Use protective gloves when handling the trimmer. • Charge the battery fully before using it for the first time 1. Remove the battery from the tool – press the battery release button (16) down and pull out the battery. 2. -
Page 19: Charging The Battery
Cordless Pole Chainsaw / Hedge Trimmer 4. Secure the strap buckle with a screw (see figure below): Charging the Battery 1. Remove the battery from the tool. 2. Plug the charger electrical cord into the charger base. (IMPORTANT: Do not use any other charger, only use supplied charger). -
Page 20: Operation
Cordless Pole Chainsaw / Hedge Trimmer Operation It is important you read and understand the Always wear ear protection. Loud noises for instruction manual before first use and an extended period of time may damage keep the manual in a safe place for future your hearing. -
Page 21: Maintenance
Cordless Pole Chainsaw / Hedge Trimmer Maintenance Your tool has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regular cleaning. Your charger does require any maintenance apart from regular cleaning. •... - Page 22 Some experts believe the incorrect or prolonged use of almost any product could cause serious injury or death. For information that may reduce your risk of serious injury or death consult thepoints below and additionall y , the information available at www.datastreamserver.com/safety - Consult all documentation, packaging and - The product has been supplied by a general merchandise...
