Bluebird SF550 User Manual

Lte phone
Hide thumbs Also See for SF550:
Table of Contents

Advertisement

Quick Links

See also: User Manual
Enlarged version
User Manual
BLUEBIRD INC.
LTE Phone
Trade Mark: Bluebird
Model: SF550
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF550 and is the answer not in the manual?

Questions and answers

Related Manuals for Bluebird SF550

Summary of Contents for Bluebird SF550

  • Page 1 User Manual BLUEBIRD INC. LTE Phone Trade Mark: Bluebird Model: SF550...

  • Page 2: Table Of Contents

    CONTENTS 1. Key Operation: ...................... 5 2. Main Features: Single SIM—4G ................6 3. Basic Operations: ....................9 4. Getting Started: ....................13 5. Contacts ....................... 19 6. Phone: ......................... 22 7. Messages: ......................26 8. Email: ........................30 9. Browser: ......................33 10.
  • Page 3 13、Clock & Alarm ....................46 14、Search ......................47 15、Sound Recorder ....................47 16、File Manager ....................48 17、APK/App Installer .................... 49 18、Camera ......................49 19、Music Player ....................50...
  • Page 4 20、GPS ........................51 21、Maps ........................ 53 Product Specifications: ................... 58...

  • Page 5: Key Operation

    1. Key Operation:...

  • Page 6: Main Features: Single Sim-4G

    2. Main Features: Single SIM—4G Calling & SMS enabled 13.97 cm HD (1080x1920)Capacitive Touch Screen Android Operating System, v 5.1.1 Lollipop 1.21 GHz 4-Core Processor for Ultra-fast speed Wi-Fi 802.11 a/b/g/n Supports APK application and installation. Audio Player Video Player Video Recorder 13MP rear main Camera and 5MP Front-facing Front Digital Camera...
  • Page 7 responsible for the damage in such circumstances. Battery life will vary with the conditions and environment in which Device is in use. Please charge the battery in time if any following conditions: A. The system warns that the power is low. B.
  • Page 8 discrepancies between the memory capacity marked on the logo and the memory capacity connected to PC, which depend on the firmware version and FLASH category used by the Device. The product performance and functionality may be different with different version of software.

  • Page 9: Basic Operations

    3. Basic Operations: ● Power On/ OFF Power On: In the power-off status, press the power button for few seconds, the unit will enter the main interface after the boot. (Slightly longer boot time, please be patient.) Power Off: In the power-on status, press the power button for few seconds, a pop-up interface will be displayed.
  • Page 10 ●Airplane mode: You can turn On/Off your device to Airplane mode. ●Auto rota on: Allow or prevent the interface from rota ng when you rotate the device. ●Bluetooth: Turn On/Off bluetooth ●Brightness: Increase or decrease brightness. ●Se ngs: You can find all the se ngs of SF550 here.
  • Page 11 Key Operations Function Turn Off/On the device (press and hold); Reset the device (press and hold Power Key/ down volume key and power key at the same time for 8-10 seconds); Lock Lock and Unlock the screen. Back Return to the previous screen. Home Return to the Home screen.

  • Page 13: Getting Started

    Note：The machine software is constantly upgraded; the status indicator may be different with your device, subject to the actual equipment. 4. Getting Started: 4.1 Insert the SIM Card Insert the SIM card when you need a cellular service. Do not insert a memory card into the SIM card slot.
  • Page 14 ●If the ba ery is completely discharged, you cannot turn on the device, even with the travel adapter connected. Allow a depleted battery to charge for a while before you try to turn on the device. 4.3 Use the touch screen Your device’s touch screen lets you easily select items or perform functions.
  • Page 15 Touch once to select or launch a menu, or option, or an application. Tap and hold Tap an item and hold it for more than 2 seconds. Drag Tap an item and move it to a new location.
  • Page 16 Double-tap Tap an item twice quickly. Flick Briskly scroll up, down, left, or right to move through lists or screens.
  • Page 17 Pinch Place two of your fingers far apart, and then pinch them together. ● Your device turns off the touch screen when you do not use it for a specified period. To turn on the screen, press the Power key.
  • Page 18 Shortcuts To customize different home screen, you can add apps shortcut; reposition the shortcut. long press and drag the icon to be added to the main screen. Widgets You can add a clock, music player and calendar widgets on the main screen. Long press the screen to open the application menu and then click widgets Then long press any widget drag it to the screen.

  • Page 19: Contacts

    Wallpapers 1. Click Settings>Display>Wallpaper Click “Gallery” Can select the system your own pictures as wallpapers. Click “Live Wallpapers” Can select the system live wallpapers as wallpapers. Click “Photos” Can select the photo as wallpapers. Click “Wallpapers” Can select the system pictures as wallpapers. 5.
  • Page 20 New contact Steps： Contacts> new contact 1. Enter your contact’s information. 2. Click “ ” to save the contact. Edit contacts/ Delete contacts Edit contacts: 1. Click open the contact list. 2. Choose the contact you want to edit，click “ ”.
  • Page 21 contact. Delete contacts: 1. Click open the contact list. ，in the pop-up menu, choose “Delete” 2. Click 3. Check the contacts you want to delete, click “ ” to delete the checked contacts. Backup contacts You can export your contact data to the Storage. Steps：...

  • Page 22: Phone

    2. Click > Import/export. 3. Click “Export to storage” Import contacts Import from Storage Steps: 1. Click open the contact list. 2. Click > Import/export. 3. Click “Import from storage”. 6. Phone: Learn to use calling functions, such as making and answering calls, using options available during a call, or...
  • Page 23 customizing and using call-related features. Make a call 1. In the application list, select →Keypad, and then enter an area code and a phone number. 2. Select to make a voice call. 3. Select to end the call. Answer a call 1.
  • Page 24 Reject a call During an incoming call, select and then drag your finger left side to reject the call. To send a message to the caller when you reject a call, drag the reject message bar at the bottom of the screen upwards.
  • Page 25 Your device will show missed calls. To return the call, tap the indicator icons area and drag it downwards to open the notifications panel, and then select the missed call notification. Set call diverting Call diverting is a network feature that sends incoming calls to a specified number. You can set this feature separately for several conditions.

  • Page 26: Messages

    2. Press the Option key and select Se ngs →Call se ngs →Call barring→ a call type. 3. Select a call barring option. 4. Enter a call barring password and select OK. Your setting will be sent to the network. Please contact network operator to activate this function. Set call waiting Call waiting is a network feature that alerts you to an incoming call while you are on another call.
  • Page 27 you have sent or received. Send a text message 1. In the application list, select →Click to create a new message. 2. Add recipients: ●Enter phone numbers manually and separate them with a semicolon or a comma. ●Select phone numbers from your call, message, or contact lists by selec ng 3.
  • Page 28 1. In the application list, select →Click to create a new message. 2. Add recipients: ●Enter phone numbers or email addresses manually and separate them with a semicolon or a comma. ●Select phone numbers or email addresses from your call, message, or contact lists by selec ng When you enter an email address, the device will Convert the message to a multimedia message.
  • Page 29 6. To send the message, select View a text or multimedia message 1. In the application list, select Messaging. Your messages are grouped by contact as a message thread. 2. Select a contact. 3. Select a multimedia message to view more details. Listen to a voicemail message If you have set your device to divert missed calls to the voicemail server, callers may leave voicemail messages when you miss calls.

  • Page 30: Email

    provider for this number. To use SMS and Calling Feature Make sure a Valid SIM card is inserted in the SIM slot. 8. Email: Click on the icon “Email” to enter user account interface and then log in to send and receive emails. (To use Gmail &...
  • Page 31 4. Created name and signature, for your account. You can also set multiple email addresses： ，select "Settings" option to enter the account 1．After Set the initial e-mail address，Click settings page. 2. Click the "Add Account" to add other email accounts. Write and send messages Steps：Click E-mail.
  • Page 32 4. Write the message content. 5. Click to send the E-mail. View and save e-mail Receiving e-mail messages stored in the network service provider's mail server before download to the device. ·Select the e-mail to read in the Inbox. ·Click the attachment icon can view e-mail attachments. ·Click Save to download attachments, attachments are usually stored in your SD card.

  • Page 33: Browser

    9. Browser: Under the main menu, click “Browser" to enter into the internet interface. Click “website column” to pop up the keyboard for new website address; Click “content column “to pop up to pop up the keyboard for new search content. Steps：Click Browser.

  • Page 34: Calendar

    10. Calendar: In the main menu screen click "Calendar" icon, you can have access to the calendar display, then view or set it. Setps：Click Calendar. New event Click to set new event, enter the event option, click on Done to save the event. 11.
  • Page 35 Wi-Fi: turn on/off WI-FI. Click “Refresh” to scan all the WIFI networks available within the range Click ”Add network” to pop up Diaglog box. User can add the aimed network to the WIFI network list after setting the network SSID and the security. Click on any network, pass the safety test (input the wireless password), and then click “Connect”...
  • Page 36 Search and connect WLAN 1. Click Settings>WIRELESS & NETWORKS 2. Open the WLAN, your device will automatically list’s the networks. ·If you select an open network, you can directly connect to the network. ·If you select an encrypted network, you must enter a password to connect to the network. ·Click on the "Add Network"...
  • Page 37 B. Bluetooth On / off the Bluetooth Steps：Click Settings>Bluetooth Click switch to turn on or off the Bluetooth. Connect the equipment to the new equipment 1. To confirm the device you want to pair with Bluetooth connectivity is turned on and visible. 2.
  • Page 38 E. Storage User can view the internal memory, SD card capacity, free space and relevant operations. F. Battery Click to check the battery status of your SF550. G.Apps Check all the apps in the unit which is downloading or in operation.
  • Page 39 H. Date & time Steps：Click Settings>Date & time. Note：If you check the “Automatic data & time” and “Automatic time zone”，the device will be based on the network automatically adjust the display time and date and time zone. If you want to set up your own time, do not check these two options. If you want set up time by yourself：...
  • Page 40 I. Language & input Steps：Click Settings>Language & input>Language. Select the language you want to use. J. Display 1) Brightness Steps：Click Settings>Display>Brightness. When the “Choose Brightness Settings”，click “Brightness”, adjust the brightness in the pop-up box.
  • Page 41 2) Sleep Steps：Click Settings>Display>Sleep Set the screen auto-lock delay time. 3) When device is rotated Steps：Click Settings>Display> When device is rotated Set the screen auto rotate.
  • Page 42 K. Backup & reset You can use this feature to erases all data on phone： Note：This operation will clear the following data in your device. a) Your account. b) System and application’s data and settings. c) Application. Does not clear the following data： a) System software and bundled applications.
  • Page 43 Steps：Click Settings>Security> Set up SIM card lock> Lock SIM Use the keyboard to enter the PIN code. If you want to change the PIN, please click“Change SIM PIN”. Note：You do not need to enter the PIN at any time to make an emergency call. ·Unlock the SIM card If you enter the wrong PIN code more than the allowed times (3 times), your SIM card will become the “PUK locked.”...
  • Page 44 ·Swipe Swipe is the system default unlock method.It will into the lock screen after the device is turned on. ·Create a screen unlock pattern. Create a personal screen unlock pattern can improve the security of the devices. Steps：1. Click Settings>Security>Screen lock>Pattern. 2.

  • Page 45: Usb Connection

    2. To change the screen unlock pattern, please enter the interface of the screen unlock pattern, confirmed once the original stored pattern, and then touch the "pattern" option to draw a new pattern. 3. If you fail to draw the correct unlock pattern for five times, the screen will prompt you must wait 30 seconds later to try again.

  • Page 46: Clock & Alarm

    3. Click the "Media device (MTP)": Lets you transfer media files on windows or using Android File Transfer on Mac (see www.android.com/filetransfer) 4. Click the "Camera (PTP)" : Lets you transfer photos using camera software and transfer any files on computers that don’t support MTP 5.

  • Page 47: Search

    Steps：Click Clock>alarm set. Add alarm, set the alarm information, then click OK. 14、Search Under the main menu click the into the following interface Under the searching interface, Input character then Click 15、Sound Recorder Under the state of main menu, select “Record” option, enter into the Record interface. Click button to start record;...

  • Page 48: File Manager

    recording file. Steps：Click Sound recorder. Record button. Stop recording. After the recording is completed you can press the button to play the audio you just recorded. 16、File Manager In the "File Explorer", the list shows all the files in the phone storage. Click to enter one layer by one layer, which lists the files under the current folder.

  • Page 49: Apk/App Installer

    17、APK/App Installer This device supports APK installation & uninstallation. Click any APK in the File Manager to access installation Interface. Click “Installation” to start installing this APK. Uninstallation: enter “applications interface “in the “setting“menu to uninstall the APK 18、Camera In the main menu interface, click the "camera "...

  • Page 50: Music Player

    Click it to change to photo-shoot Press shutter to start capture panorama Click it to change main camera to Front-facing camera Click it to view image if you have a photo or more Click it to set camera parameters 19、Music Player In the main menu interface, click the "Play Music"...
  • Page 51 Shuffle icon: Click to open or close the Shuffle Click the icon to set the "repeat the current song, repeat all songs, repeat off", etc. Click the icon to play on last song. Click to pause and play the current song. Click to play the next song 20、GPS Your device is equipped with a global positioning system (GPS) receiver.
  • Page 52 ●In poor weather ●Around high voltage or electromagne c fields ●In a vehicle with sun protection film Do not touch or cover the area around the antenna with your hands or other objects while using the GPS functions. This feature may be unavailable depending on your region or service provider. Activate location services You must activate location services to receive location information or search the map.
  • Page 53 Note：·You must open4G/ 3G/GPRS or WIFI to use the map. ·Maps application does not cover all countries and cities. ·Open the location service. You must open the location service first in order to open the map and search for your location or search a place to go.
  • Page 54 Steps：Click Maps. ·Search My position on the map. In the map interface, click ,then your location on the map will display a flashing blue dot. ·Search the place you want to go. 1. In the map interface，click “Search Maps”. 2. Enter the name of the place you want to search, you can choose to enter an address, city, or the building name (for example: The Oriental Pearl).
  • Page 55 View Maps While viewing the map, you can use the following zoom and navigation skills. Zoom the map. Through the fingers outward or inward sliding the screen at the same time, can zoom in or out the map. Change the map mode. Click to change the map mode.
  • Page 56 ·Terrain：This mode is the default view, not only can display the name of the map will be added to the streets, rivers, lakes, mountains, parks and the border. FAQ (Frequently Asked Questions): Smart Device could not be power on Check if the battery is empty. Check it again after connects the power adapter.
  • Page 57 Please check whether it has set the correct language option, the language chosen can set in the (settings) =＞ (language &input) =＞(Language) The files cannot be downloaded Confirm the connection between the computer and the player is proper Confirm whether the memory is full of storage space. Confirm whether there is any damage in the USB cable.
  • Page 58 Product Specifications: Model Number SF550 13.97cm Capacitive Touch Screen with 1080x1920 pixel Screen Size Resolution Screen Operation Capacitive Touch Screen SIM GSM 4G-3G Calling/SMS WIFI...
  • Page 59 Water Resistance phone subjected to close all connectors Water Resistant of phone properly; to avoid customer issues Android OS, v5.1.1 Lollipop 13 MP Rear main camera and 5MP Front-facing camera, Camera Digital Front...
  • Page 60 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 61 • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment.
  • Page 62 Warning 1) This product conforms with standard EN50332. Use careful with the earphone maybe possible excessive sound pressure from earphones and headphones can cause hearing loss. 2) The product shall only be connected to a USB interface of version USB2.0 Please use common USB Cable or original charger, Otherwise, It may result to danger.
  • Page 63 3) Extreme Operating Temperature : -20~+45℃ 4) For 5G WIFI application, The device is designed to operate only in slave mode and can not operate in master mode. The device is defined as a client device for 5G WIFI application. The device is designed to use indoor only (for 5G WIFI application). CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
  • Page 64 Specific Absorption Rate (SAR) information: This phone meets the government's requirements for exposure to radio waves. The guidelines are based on standards that were developed by independent scientific organizations through periodic and thorough evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of all persons regardless of age or health.
  • Page 65 phone. The use of belt clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided. Body-worn Operation This device was tested for typical body-worn operations.
  • Page 66 Declaration Of Conformity Hereby, BLUEBIRD INC. declares that this LTE Phone is in compliance with the essential requirements and other relevant provisions of directive 1995/5/EC.
