- Page 1 TEMPPOINTER1 MANUAL...
- Page 2 Congratulations! On choosing this FUTECH instrument. FUTECH provides measuring instruments of precision and quality. Contributions from professional end users enable us to offer innovative, easy-to-use equipment. TEMPPOINTER 1 IMPORTANT! Read the instructions for use carefully before using the instrument. Keep them in a safe place for consultation when necessary.
- Page 3 TEMPPOINTER1 MANUAL Parts of the housing Laser beam Infrared sensor Measuring head Battery cover Handle LCD Display Display lighting ° C / ° F key Mode button 10. Laser On-Off 11. Measurement result ° ε 12. Temperature ° C SCAN =0.95...
- Page 4 How does an infrared thermometer work? Each object transmits infrared rays. The power of these rays depends on the type of material (expressed as “radiation coefficient” or “emissivity” of a material) and of course the temperature of the object. An infrared detector absorbs these rays and the electrons in the device turn them into temperature (°...
- Page 5 TEMPPOINTER1 MANUAL How big is the measuring area? The further you are of the object whose temperature you want to measure, the gre- ater the measurement area. The larger the measuring surface, the less the accuracy. We therefore recommend using the camera as close as possible to the objects to be 600 1200 measured.
-
Page 6: Temperature Unit
Measuring Insert 1x 9V battery into the device. Consider the polarity. This is indicated in the device. Hold the meter at the handle and point it to the surface to be measured. Pull and hold the trigger to start testing. When the battery is good, the display lights up. - Page 7 TEMPPOINTER1 MANUAL Min / Max After measurement, you can also read the lowest and highest measured temperature. Use the MODE button to switch between - last measurement - min - max Battery If the battery voltage is not high enough, the battery symbol will appear on the dis- play.
-
Page 8: Limits Of Use
∙ Use of products with obviously recog- in hazardous areas, or in close proximity ∙ To inform FUTECH immediately if the nizable damages or defects. to electrical installations or similar sit- product and the application becomes ∙... - Page 9 TEMPPOINTER1 MANUAL HAZARDS OF USE by lightning. international rules and regulations are WARNINGS ∙ Do not use the product in a thunder- observed. Before transportation or ∙ The person responsible for the product storm. shipping contact your local passenger must ensure that it is used in accord- ∙...
-
Page 10: Laser Classification
environmental contamination. ∙ special warning signs in the laser By disposing of the product irrespon- working area sibly you may enable unauthorized if used and operated as defined in this user persons to use it in contravention of manual due to the low eye hazard level. the regulations, exposing themselves Products classified as laser class 2 or and third parties to the risk of severe... -
Page 11: Technical Specifications
TEMPPOINTER1 MANUAL TECHNICAL SPECIFICATIONS accuracy ± 2°c temperature range ± -50°c ~ 450° (-58°c ~ 842°c) display sensitivity 0,10°c (0,10°f) emissivity 0,95 (fix) optical resolution 12:1 laser class class 2 - 630-675nm - <1mw response time <1 sec special response time 6 ~14 µm... - Page 12 JOIN US Facebook @futechtools LinkedIn futech-tools World Wide Web futech-tools.com YouTube futech-tools...
