- Page 1 Neurio Sensor W1 User Guide Copyright © 2015, Neurio Technology Inc. All rights reserved. GlobalTestSupply www. .com Find Quality Products Online at: sales@GlobalTestSupply.com...
-
Page 2: Table Of Contents
Table of Contents 1.0 Neurio Sensor W1 ............................. 3 1.1 Features ................................. 3 1.2 Meet the Neurio Sensor ........................4 2.0 Installation and Configuration ......................... 7 2.1 Safety ................................7 2.2 Installation Instructions ........................8 2.4 Installation External to Breaker Panel ..................8 3.0 Specifications .............................. -
Page 3: Neurio Sensor W1
The Neurio Sensor is intended for use in residential or light commercial locations. It is a monitor only, and should not be used for billing purposes. It should not be used in mission-critical applications, or any instance where its failure could endanger human life. -
Page 4: Meet The Neurio Sensor
1.2 Meet the Neurio Sensor Below is a quick guide to your new Neurio Sensor. For more detailed information, see the Installation Guide and Welcome Guide included in the box, and support.neur.io for videos, FAQs and troubleshooting tips. Voltage and Current Ports On one end of the Neurio Sensor, you’ll find the voltage and current... - Page 5 Current Transformers and Voltage Cable The Neurio Sensor uses these to measure the energy consumption of your home. Installing these correctly is important for accurate measurements, so follow the directions carefully! The voltage cable has 4 wires on it.
- Page 6 The Buzzer The Neurio Sensor has a buzzer so it can tell you how it’s doing. even when it’s tucked away inside your breaker panel. It’ll use the buzzer to tell you when it’s started it’s own network, joined your home network, or thinks there was an installation problem.
-
Page 7: Installation And Configuration
Neurio Sensor. If power cannot be disconnected, high voltages may still be present, and caution must be taken to avoid injury. If the Neurio Sensor is not used as instructed, its protection mechanisms may be impaired. -
Page 8: Installation Instructions
Note that different installation instructions are provided for split-phase, three-phase and solar systems. If your Neurio Sensor came with an Expansion Kit for 3-phase or solar, follow the instructions provided in the kit. Otherwise, follow the Installation Guide included in the Neurio Sensor box. These instructions are also available at support.neur.io. -
Page 9: Specifications
3.0 Specifications 3.1 Models Neurio Sensor W1-S Neurio Sensor with Solar Expansion Kit W1-3P Neurio Sensor with 3-Phase Expansion Kit 3.1 Ratings Voltage 110-240VAC Voltage Fluctuations ±10% of nominal voltage Overvoltage Overvoltage Category II Frequency 50-60Hz Power GlobalTestSupply www. -
Page 10: Monitoring
3.2 Monitoring Out of the box, the Neurio Sensor can be used in the following scenarios: North American Split Phase Typically found in detached houses Line to Neutral Voltage 120V Line to Line Voltage 240V Frequency 60Hz Max Current 264A per phase... - Page 11 With an Expansion Kit, Neurio can also support: North American or European Three Phase Typically found in detached houses or commercial buildings Line to Neutral Voltage 120-240V Line to Line Voltage 208-415V Frequency 50 or 60Hz Max Current 264A per phase...
-
Page 12: Performance
Three-Phase with Single-Phase Solar Typically found in detached houses Line to Neutral Voltage 110-240V Line to Line Voltage 208-415V Frequency 50 or 60Hz Current 264A per phase 3.3 Performance Accuracy Power Energy Resolution Power Energy Measurement Frequency 3.4 Radio Standard WiFi (802.11b/g/n) Frequency 2.4GHz... -
Page 13: Environment
3.5 Environment Operating Temperature 5C to 45C Storage Temperature 0C to 60C Humidity Range 0-80% RH Max Altitude 2000m Pollution Degree 3.6 Compliance Safety Certification TUV, CE Safety Standard CAN/CSA C22.2 No. 61010-1:2012, UL 61010-1:2012, IEC 61010-1, EN 61010-1 Radio FCC, IC, ETSI FCC ID... - Page 14 This device must accept any interference received, including interference that may cause • undesired operation. Changes or modifications not expressly approved by Neurio Technology Inc. may void the user’s authority to operate the equipment. IC RSS 210 This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
-
Page 15: Manufacturing
L'antenne (s) utilisé pour cet équipement doit être installé pour fournir une distance d'au moins 20cm à partir de toutes les personnes. CE Compliance The Neurio Sensor W1 complies with the following CE directives: Low Voltage Equipment (LVD) Radio and Telecommunications Terminal Equipment (RTTE) Electromagnetic Compatibility (EMC) For the complete CE Self Declaration, see support.neur.io.
