SIP Fireball 72XRDT Manual

SIP Fireball 72XRDT Manual

Infra-red diesel heater

Advertisement

Please dispose of packaging for the product in a responsible
manner. It is suitable
for recycling.
Help to protect the
environment, take the packaging to the local amenity tip and
Fireball 72XRDT
place into the appropriate recycling bin.
Infra-Red Diesel Heater
Never dispose of electrical equipment or batteries in with your
domestic waste. If your supplier offers a disposal facility please
use it or alternatively use a recognised re-cycling agent. This will
allow the recycling of raw materials and help protect the envi-
ronment.
FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR,
OR SIP DIRECTLY ON:
TEL: 01509500400
09294
EMAIL: sales@sip-group.com or technical@sip-group.com
www.sip-group.com
Please read and fully understand the instructions in this manual
before operation. Keep this manual safe for future reference.
Ref: 210716
24
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fireball 72XRDT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SIP Fireball 72XRDT

  • Page 1 This will allow the recycling of raw materials and help protect the envi- ronment. FOR HELP OR ADVICE ON THIS PRODUCT PLEASE CONTACT YOUR DISTRIBUTOR, OR SIP DIRECTLY ON: TEL: 01509500400 09294 EMAIL: sales@sip-group.com or technical@sip-group.com www.sip-group.com...
  • Page 2 Low Voltage Directive 2014/30/EU EMC Directive 2011/65/EU RoHS Directive And the relevant harmonised standard(s), including: EN 55014-1:2006+A1+A2 EN 55014-2:2015 EN 61000-3-2:2014 EN 61000-3-3:2013 EN 60335-2-102:2004+A1 EN 60335-1:2010 Signed: …………………………………... Mr P. Ippaso - Managing Director - SIP (Industrial Products) Ltd Date: 23/06/2016.
  • Page 3: Table Of Contents

    NOTES CONTENTS Page No. Description Safety Symbols Used Throughout This Manual Safety Instructions Electrical Connection Guarantee Technical Specifications Getting to Know Your Heater Assembly Instructions Operating Principle Operating Conditions Operating Instructions Error Codes Maintenance Circuit Diagram Troubleshooting Exploded Drawing Parts List Declaration of Conformity...
  • Page 4: Safety Symbols Used Throughout This Manual

    Read all these instructions before operating the heater and save this user manual for future reference. SIP recommends that this heater should not be modified or used for any application other than that for which it was designed. If you are unsure of its relative applications do not hesitate to contact us and we will be more than happy to advise you.
  • Page 5 NOTES SAFETY INSTRUCTIONS….cont DISCONNECT THE HEATER FROM THE MAINS SUPPLY: When not in use. AVOID UNINTENTIONAL STARTING: Make sure the switch is in the OFF position before connecting the heater to the mains supply. DO NOT ABUSE THE MAINS LEAD: Never carry the heater by the mains lead or pull it to remove the plug from the mains socket.
  • Page 6 SAFETY INSTRUCTIONS….cont PARTS LIST Description SIP Part No. Description SIP Part No. ment is made of stainless steel and was coated with protection oil during produc- tion. The smoke / smell is caused by any small residue of this oil which was left on...
  • Page 7: Electrical Connection

    Connecting to the power supply: This SIP heater is fitted with a standard 230v ~ 13 amp type plug. Before using the heater, inspect the mains lead and plug to ensure that neither are damaged. If any damage is visible have the heater inspected / repaired by a suitably qualified per- son.
  • Page 8: Guarantee

    Ignition device is dirty / faulty. the heater. This SIP heater is covered by a 12 month parts and labour warranty covering failure Contact service centre. Fuel filter is dirty. due to manufacturers defects. This does not cover failure due to misuse or operating Nozzle is blocked.
  • Page 9: Technical Specifications

    CIRCUIT DIAGRAM TECHNICAL SPECIFICATIONS Part Number 09294 Input Voltage 220V - 240V ~ 50hz Fuel Diesel / Kerosene Heat Output 70,000 BTU/hr (20 Kw) Fuel Consumption 1.9L/Hr (Approx.) Fuel Tank Size 10.5 Litres Net Weight 19.5 Kg Top - 1500 mm Sides - 1500 mm Minimum Clearance Around Heater Rear - 1500 mm...
  • Page 10 ASSEMBLY INSTRUCTIONS MAINTENANCE FITTING THE PROTECTION PANEL Danger: Maintenance operations should only be carried out by suitably qualified persons. Component Frequency Procedure Clean every 150-200 hours of Empty and rinse with fresh fuel. Fuel Tank operation or when necessary. Fig. 1 Fig.
  • Page 11: Assembly Instructions

    ERROR CODES ASSEMBLY INSTRUCTIONS….cont FITTING THE STAND Error Code Cause Solution Operator Error. The power switch is in the On (I) Disconnect the heater from position when the heater is con- the mains supply, turn to pow- nected to the mains supply. er switch to the Off (0) position and reconnect to the mains supply.
  • Page 12: Operating Conditions

    OPERATING CONDITIONS OPERATING INSTRUCTIONS….cont WARNING! Air contaminants taken into the heater may affect the heat output, dam- stat control left to lower the temperature and clockwise to raise the temperature, at age to the unit may cause health problems. this time the temperature on the display indicates the set temperature and after a few seconds it will change to the ambient temperature.
