- Page 1 TwistPlex UTP Product Line UTP 4X1500 4 Camera Passive Hub Installation Manual...
- Page 2 Step 1 Remove the two countersunk screws from the rear of the metal case using a cross head screwdriver. Step 2 Hold onto the main case assembly with one hand supporting the top cover. Step 3 Press slightly on the back cover using the left hand thumb and slide the back cover using the right hand.
- Page 3 Slide the top cover onto the back cover with the slot on Step 7 the top cover hook on the catch of the back cover. Step 8 Screw back the two countersunk screw to secure the top cover on to the back cover. Installation complete. Step 9 Strip the UTP cable with 5 mm copper exposed.
- Page 4 Woodgreen Road, Waltham Abbey Essex, EN9 3SA, UK Tel: 440-870-770-9323 Fax: 440-870-770-9363 Email: ave-uk@multiview.net Website: www.multiview.net ASIA AVE (Thailand) Co., Ltd. 217/4 Crystal Garden Soi 4 (Nanatai), Sukhumvit Rd. Klongtoey, Klongtoey Bangkok, 10110 Thailand Tel: 662-656-8231 Fax: 662-656-9554 Email: ave@avethailand.com Website : www.avethailand.com...
