Dimensions and Installation Information (in inches)
The Installation Space
The finished cutout width must be 30" .
25" min. depth
3/4"
29-3/4"
Height adjustable
from 79-3/8" to 80-3/8" *
For answers to your Monogram,
GE
appliance questions, visit our website at
®
geappliances.com or call GE Answer Center
service, 800.626.2000.
30" Fully Integrated Glass Door Wine Reserve with
30" Finished Width
Height options
80" or * 84"
23-3/4"
1/8"
4"
1-1/4"
®
GE Profile
or
®
The cutout depth must be 25" for flush installations.
• The front face of the wine reserve fits flush with 25" depth
adjacent cabinets.
Electrical
A 115V, 60Hz., 15 or 20 amp power supply is required. An
individual properly grounded branch circuit or circuit breaker
is recommended. Install a properly grounded 3-prong
electrical receptacle recessed into the back wall. Electrical
must be located on rear wall as shown.
Note: GFI (ground fault interrupter) is not recommended.
Water Line
• A cold water supply is required for automatic icemaker
operation. The water pressure must be between 40 and 120
p.s.i.
• Route 1/4" OD copper or GE SmartConnect
tubing between the house cold water line and the water
connection location.
• Water line can enter an opening through the floor or back wall.
• Install a shut-off valve between the icemaker water valve
and cold water cupply in the home.
4"
Specification Created 2/11
plastic
Listed by
Underwriters
Laboratories
110119

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZIW30GNZII and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GE ZIW30GNZII

  • Page 1 • A cold water supply is required for automatic icemaker operation. The water pressure must be between 40 and 120 p.s.i. Height options • Route 1/4" OD copper or GE SmartConnect plastic 80” or * 84“ ™ tubing between the house cold water line and the water connection location.
  • Page 2: Product Dimensions

    ® handle kit for custom panels. Optional Accessory Kits ZUG30: For side-by-side installation European Handle Kit: can be purchased through GE Parts store - WR12X10988 Door Swing Clearances The installation must allow for clearances to adjacent walls or cabinets. These refrigerators are equipped with a 2-position door stop.
  • Page 3 3-3/8” *Pro style window is slightly smaller. For answers to your Monogram, GE Profile ® ™ appliance questions, visit our website at ® geappliances.com or call GE Answer Center ® service, 800.626.2000. Listed by Underwriters Laboratories Specification Created 2/11 110119...
  • Page 4 ® ™ appliance questions, visit our website at ® Design Tip: If using custom panels, a custom toe kick should geappliances.com or call GE Answer Center ® be considered. The bottom of case is black. service, 800.626.2000. Listed by Underwriters...
  • Page 5: Advance Planning

    1” 1-1/4” 1-1/2” 3/4” 1” 1-1/4” 1-1/2” For answers to your Monogram, GE Profile ® ™ appliance questions, visit our website at ® geappliances.com or call GE Answer Center ® service, 800.626.2000. Listed by Underwriters Laboratories Specification Created 2/11 110119...
  • Page 6 115 ˚ door swing. 1-1/8” 2-1/2” 1-1/4” For answers to your Monogram, GE Profile ® ™ appliance questions, visit our website at ® geappliances.com or call GE Answer Center ® service, 800.626.2000. Listed by Underwriters Laboratories Specification Created 2/11 110119...
  • Page 7: Door Swing

    1” 1-1/4” 1-1/2” 3/4” 1” 1-1/4” 1-1/2” For answers to your Monogram, GE Profile ® ™ appliance questions, visit our website at ® geappliances.com or call GE Answer Center ® service, 800.626.2000. Listed by Underwriters Laboratories Specification Created 2/11 110119...
  • Page 8 90˚ DOOR SWING (optional setting) 1-1/4” 2-9/16” For answers to your Monogram, GE Profile ® ™ appliance questions, visit our website at ® geappliances.com or call GE Answer Center ® service, 800.626.2000. Listed by Underwriters Laboratories Specification Created 2/11 110119...
  • Page 9: Features And Benefits

    • Convertible lower drawer - With independent temperature controls can be used to store fresh food, frozen foods, wine or beverages • GE unveils first HFC-free refrigerator in the U.S. - To use a R600a refrigerant, which has a lower global warming impact than ozone-depleting...
