Summary of Contents for Neilsen CT0870
- Page 1 15 PIECE AIR TOOL KIT RATCHET IMPACT GUN &SOCKETS CT0870 ORIGINAL INSTRUCTIONS Cannon Tools Limited Address: 20 Station Road, Rowley Regis, West Midlands, B65 0JU.U.K. SAVE THESE INSTRUCTIONS AND PRECAUTIONS. READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
-
Page 2: Ec Declaration Of Conformity
In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity. Product description: 1/2” DRIVE AIR IMPACT WRENCH Model: CT0870-1 Product description: 3/8” DRIVE AIR RATCHET WRENCH Model: CT0870-2 Applicable EC Directives:... -
Page 3: Safety Instructions
1. SAFETY INSTRUCTIONS SYMBOLS In this manual and/or on the machine the following symbols are used: Denotes risk of personal injury, loss of life or damage to the tool in case of non-observance of the instructions in this manual. Wear hearing protection. Wear safety goggles. - Page 4 •DO NOT carry the wrench by the air hose, or yank the hose from the air supply. •DO NOT operate wrench if you are tired, under the influence of alcohol, drugs or intoxicating medication. •DO NOT carry wrench with your hand on the power trigger in order to avoid unintentional starting.
-
Page 5: Getting Started
3. GETTING STARTED 3.1 Set-up Fitting the air inlet with the nitto fitting Put plumbers tape around the thread of the nitto fitting. Screw the nitto fitting into the air inlet. Connect to a compressor with an air hose. Fit the required socket to the anvil 3.2 Air supply Ensure wrench trigger is in the “off”... - Page 6 day or after every two hours of use. This must be done directly along the male coupler or oil inlet provided for the purpose on the side of the tool’s housing. Automatic lubrication is also possible using a mini oiler that you have to install between the tool and the compressor.
-
Page 7: Maintenance
5.1. Connect the wrench to the air hose as in Section 3. 5.2. Fit the socket onto the square drive and then place the socket over the subject nut. Squeeze the trigger to operate the wrench. 5.3. To change the ratchet direction turn the switch on the tool head. F = Forward, R = Reverse. DO NOT use any additional force upon the wrench in order to remove or tighten a nut. -
Page 8: Assembly Diagram And Parts List
8. ASSEMBLY DIAGRAM AND PARTS LIST 1/2” DRIVE AIR IMPACT WRENCH 7 ... - Page 9 3/8” DRIVE AIR RATCHET WRENCH CANNON TOOLS LTD Add: 20 station road, Rowley Regis, west midlands,B65 0JU.U.K. Made in China 8 ...
