- Page 1 Mul-ti Mode Ultrasonic Thickness Gauge MT660 User’s Manual MITECH CO., LTD. www.ponpe.com www.mitech-ndt.com...
-
Page 2: Table Of Contents
CONTENTS 1 Overview..............................4 1.1 Product Features..........................4 1.2 Measuring Principle...........................4 1.3 Specifications............................. 4 1.4 Transducer Technical Parameters....................5 1.5 Configuration............................6 1.6 Operating Conditions........................6 2 Structure Feature............................6 2.1 Main Screen............................7 2.2 Keypad Definitions..........................7 3 Test Preparation............................8 3.1 Transducer Selection........................ - Page 3 6.2 Wall Measurement.......................... 21 7 Servicing..............................21 8 Transport and Storage........................... 21 Appendix A Sound Velocities........................22 Appendix B Applications Notes......................23 User Notes..............................25...
-
Page 4: Overview
1 Overview The model MT660 is a multi-mode ultrasonic thickness gauge. Based on the same operating principles as SONAR, the instrument is capable of measuring the thickness of various materials with accuracy as high as 0.1/0.01 millimeters. The multi-mode feature of the gauge allows the user to toggle between pulse-echo mode (flaw and pit detection), and echo-echo mode (eliminate paint or coating thickness). -
Page 5: Transducer Technical Parameters
Units: Metric and Imperial unit selectable. Battery information indicates the rest capacity of the battery. Auto sleep and auto power off function to conserve battery life. USB2.0 communication port Bluetooth support. Size: 120mm×67mm×31mm ... -
Page 6: Configuration
1.5 Configuration Table 1.2 Instrument Configurations Item Qty. Note Standar Main body d Config. Probe P5EE(5MHz) Couplant Instrument Case Operating manual Alkaline battery AA size Optional Probe N02 (2.5MHz) Config. Probe N05/90°(5MHz) See Table1.1 Probe N05 (5MHz) Probe N07(7MHz) -
Page 7: Main Screen
2.1 Main Screen Mode: "E-E" indicating the instrument work in the Echo-Echo mode; "P–E” indicating it work in the Pulse-Echo mode; Probe: Probe selection Velocity: Sound velocity Battery: Indicating the rest capacity of the battery. Thickness: Last test result Unit: mm or inch Diff value: Differential result when working in diff mode. -
Page 8: Test Preparation
Bluetooth role LED status Bluetooth status Host mode Fast glittering (150 ms Searching and on, 150 ms turn off) connecting Fast glittering 5 times connecting and then turn off after 2 seconds Always on Connected Slave mode Slow glittering (800 ms... -
Page 9: Condition And Preparation Of Surfaces
The transducer is the “business end” of the instrument. It transmits and receives ultrasonic sound waves that the instrument uses to calculate the thickness of the material being measured. The transducer connects to the instrument via the attached cable, and two coaxial connectors. -
Page 10: Connecting The Probe
To insert the batteries: Loosen the two screws of the battery cover. Lift the cover off upward. Insert the batteries into the battery compartment. Close the battery compartment and fasten the screws. Turn on the instrument to make sure the battery is installed correctly and firmly. -
Page 11: Operations
The main unit and the display is switched off and consumes almost no energy. Pressing any key will stop the unit entering power off state while it prompts out “Idle Timeout!” and return back to run state. -
Page 12: Sound Velocity Calibration
5 When the progress bar shows complete, remove the transducer from the probe disc. If necessary, repeat this procedure for times. 6 At this point, the instrument has successfully calculated its internal error factor, and will compensate for this value in any subsequent measurements. When performing a “probe zero”, the instrument will always use the sound velocity value of the built-in probe-disc, even if some other velocity value has been entered for making actual measurements. -
Page 13: Making Measurements
3. Press the to enter the “Input Nominal Thickness” dialog. See right figure. Press F1/F2 to input the thickness value, until it matches the thickness sample piece. -
Page 14: View Mode Setting
In order for the transducer to do its job, there must be no air gaps between the wear-face and the surface of the material being measured. This is accomplished with the use of a “coupling” fluid, commonly called “couplant”. This fluid serves to “couple”, or transfer, the ultrasonic sound waves from the transducer, into the material, and back again. -
Page 15: Nominal Thickness Setting
Scan Mode. Besides the last test thickness value, it also shows the minimum thickness value and the maximum thickness during the test. Press will reset the minimum maximum value. Diff Mode. Shows both the last test thickness value ponpe.com... -
Page 16: Changing Resolution
5.9 Changing Resolution gauge selectable display resolution, which is 0.1mm and 0.01mm. When the resolution is set to 0.01mm, the tested piece surface should be smooth to get accurate test result. When measuring rough surface or coarse grained materials, it is suggested to use low resolution. -
Page 17: Key Sound Setting
Activate Memory Manager dialog. Press to focus on the desired data group. Press F2 to prompt commands list. Then select the command “Set” and press confirm. After finished the above steps, the new selected data group will be set as current data group to store the new coming testing results. -
Page 18: Display Standby Setting
Note: For saving power, lower down the LCD brightness in good light environment. 5.14 Display Standby Setting Standby state lower down the LCD brightness and puts the CPU in a power conserving mode. The change from run state to standby state is controlled by the setting of the Display standby delay. -
Page 19: Language Setting
Use F1 and F2 keys to move the cursor. Use arrow keys to increase/decrease the values; Press /F3 key to confirm the setting. Press key to cancel the setting change and close the dialog box. Once set, the internal clock of the instrument will maintain the current date and time. -
Page 20: Usb Communication
2 Set the Bluetooth role of instrument to Master mode. 3 The instrument will ask the operator if need to re-search nearby Bluetooth printer shown as right figure. Select “YES” for the first time to print. Otherwise, select “NO”. -
Page 21: Measuring Technologies
6. Measuring Technologies 6.1 Measuring Method Single point measuring method: Put the probe to any point in the workpiece, the instrument will show the probe located place thickness. Two point measuring method: Using the probe to measure two times in the same point of the tested piece, in two measuring, the probe parting plane keep 90º, the smaller value should be the... -
Page 22: Appendix A Sound Velocities
Appendix A Sound Velocities Material Sound Velocity in/µs Aluminum 0.250 6340-6400 Steel, common 0.233 5920 Steel, stainless 0.226 5740 Brass 0.173 4399 Copper 0.186 4720 Iron 0.233 5930 Cast Iron 0.173-0.229 4400－5820 Lead 0.094 2400 Nylon 0.105 2680 Silver 0.142... -
Page 23: Appendix B Applications Notes
Appendix B Applications Notes Measuring pipe and tube When measuring a piece of pipe to determine the thickness of the pipe wall, orientation of the transducers is important. If the diameter of the pipe is larger than approximately 4 inches, measurements should be made with the transducer oriented so that the gap in the wearface is perpendicular (at right angle) to the long axis of the pipe. - Page 24 Measuring through paints and coatings are also unique, in that the velocity of the paint/ coating will be significantly different form the actual material being measured. A perfect example of this would be a mild steel pipe with approximately 0.6mm of coating on the surface. Where the velocity of the pipe is 5920m/s, and the velocity of the paint is 2300m/s.
-
Page 25: User Notes
Warranty ： The product is guaranteed for one year since purchased. Log www.mitech-ndt.com or follow our company official public platform to register for maintenance. Please fill the blanks as required, if the product is not registered for maintenance, it will follow the date of manufacturer.
