Single temperature, dual temperature and multi temperature wine cellars
Eintemperatur-, Zweitemperatur- und Mehrtemperaturschränke
Armarios de 1 temperatura, 2 temperaturas y multitemperatura
Wijnkasten met 1 temperatuur, 2 temperaturen en multitemperatuurCantina
Access :
F130
FV140
F190
FV210
F250
FV270
F248
FV189
Caves 1 température, 2 températures et multi températures
Cantinette 1 temperatura, 2 temperature e multitemperatura
MODE D'EMPLOI
OPERATING INSTRUCTIONS
BEDIENUNGSANLEITUNG
MODO DE EMPLEO
GEBRUIKSAANWIJZING
ISTRUZIONI PER L'USO
Advertisement
Table of Contents
Related Manuals for ArteVino F130
Summary of Contents for ArteVino F130
- Page 1 Single temperature, dual temperature and multi temperature wine cellars Eintemperatur-, Zweitemperatur- und Mehrtemperaturschränke Armarios de 1 temperatura, 2 temperaturas y multitemperatura Wijnkasten met 1 temperatuur, 2 temperaturen en multitemperatuurCantina Cantinette 1 temperatura, 2 temperature e multitemperatura Access : F130 FV140 F190 FV210 F250 FV270...
- Page 2 ARTEVINO n’offre aucune garantie sur cet appareil lorsqu’il est utilisé pour un usage particulier autre que celui pour lequel il a été prévu. ARTEVINO ne pourra être tenue pour responsable des erreurs contenues dans le présent manuel ni de tout dommage lié ou consécutif à la fourniture, la per- formance ou l’utilisation de cet appareil.
-
Page 3: Table Of Contents
Contents Description of your wine cabinet.........P 4-5 The various ARTEVINO cabinet models........P 6 Power supply ................P 6 Installing your wine cabinet ............P 7 Handle assembly ........P 8 Layout and load recommendations ........P 8-9... -
Page 5: Description Of Your Wine Cabinet
Description of your wine cabinet Cabinet body Hinge Door Universal shelf (storage and/or presentation configuration) Hot and cold thermostats and thermometer Lock Thermodynamic pump opening Rigidity Bar (on large models) Universal shelf (sliding configuration) Cooling compartment (F248 model only) Adjustable foot (4) Maker’s label Wire shelf (except model F248) English - P 5... -
Page 6: The Various Artevino Cabinet Models
The various ARTEVINO cabinet models In order to better adapt to differing requirements and usages, there are 3 types of ARTEVINO wine cabinets. The 1-temperature Maturing cabinets: Designed to store and mature all wines, these cabinets reproduce the exact conditions of a natural cellar (one constant temperature), irrespective of the outside temperature (between 0 and 35°C). -
Page 7: Installing Your Wine Cabinet
Installing your wine cabinet When unpacking your cabinet, make sure that there are no traces of impact or deformation and that there are no surface defects. Carefully remove all of the protections and adhesive strips from the packaging around your wine cabinet. Install the handle by referring to the instructions given on the following page. -
Page 8: Handle Assembly
Installing the handle Installing the handle of your wine cabinet is carried out in the following manner: - Introduce the two spacers (B) into the holes on the inside panel of the door. - Using a screwdriver, secure the handle (A) with the two screws (C). - Page 9 Shelf in presentation version configuration: To place bottles on a presentation shelf, carry out the following: - Install the shelf in the selected location. - Place a wooden locking pin in each of the two holes located on the right and left of the upper face approximately 15cm in front of the shelf: these pins butt up against the heat shaped wall and avoid all accidental shelf movement (See diagram).
-
Page 10: Temperature Settings
Settings are adjusted from the hot and cold thermostats located in the middle of the interior right hand wall of your cabinet. Standard Settings Model Required T°C COLD f130 12°C fV140 12°C f190 12°C fV210 12°C f250 12°C... -
Page 11: Temperature Adjustments
Temperature adjustment If the loading configuration or the location of your cabinet justifies it, you can adjust the settings. Adjusting temperature upwards Starting off from the standard settings, move the index values of the two thermostats upwards, keeping the same distance apart between the two (3 graduations). - Page 12 Wine service temperatures (provided as an indicator only) Alsace 10°C Australia 16°C Beaujolais 13°C Sweet white Bordeaux 6°C Dry white Bordeaux 8°C Red Bordeaux 17°C White Burgundy 11°C Red Burgundy 18°C California 16°C Champagne 6°C Chili 15°C Spain 17°C Italiy 16°C Jura 10°C...
-
Page 13: Important Wine Information
Important wine information Your ARTEVINO cabinet has been designed to guarantee the optimum condi- tions for storing and/or serving your wine Wine is a highly complex product, requiring long and gentle development and needs specific conditions in which to reach its full potential. -
Page 14: Everyday Wine Cabinet Maintenance
Everyday care of your wine cabinet Your ARTEVINO cabinet is a simple tried and tested item of equipment. The following few operations enable you to obtain optimum operation and an extended life cycle. 1 - Regularly remove dust (twice a year) from the condenser (black metal grill fastened to the back of your wine cabinet). -
Page 15: Operating Anomalies
Only a qualified electrician should make any repairs or inspections to your electrical supply. ANy INTERVENTION PERfORMED By A TECHNICAL SERVICE NOT APPROVED By ARTEVINO OR ITS RETAILER WILL LEAD TO THE gUARANTEE BEINg CONSIDERED AS NULL AND VOID. English - P 15... -
Page 16: Technical Characteristics
Technical Characteristics Model Temperatures Height Width Depth Weight*** Precision (kg) (°C) (mm) (mm) (mm) F130 1110 +/- 2,5 FV140 1110 +/- 2,5 F190 1470 +/- 2,5 FV210 1470 +/- 2,5 F250 1810 +/- 2,5 FV270 1810 +/- 2,5 F248 1810... -
Page 17: Data Relating To Energy Consumption
N.B.: Caring for the environment: when replacing your wine cabinet, consult the local municipal refu- se department in order to observe the appropriate recycling procedure. For refrigerant gases, substances and some parts in the wine cabinets, Artevino uses recyclable mate- rials which require a special packaging disposal procedure to be used.
