OXYVD7WCOUS
OXY2TVD6COUS
User manual
- A brand of EuroCave Group -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OXYVD7WCOUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ArteVino OXYVD7WCOUS

Summary of Contents for ArteVino OXYVD7WCOUS

  • Page 1 OXYVD7WCOUS OXY2TVD6COUS User manual - A brand of EuroCave Group -...
  • Page 2 Welcome You have just purchased an ARTEVINO product – thank you for your custom. We take particular care in manufacturing our products in terms of their design, ergonomics and ease of use. We hope that you will be completely satisfied with this product.

  • Page 3: Table Of Contents

    Contents Protecting the environment ............................P 4 Description of your wine cabinet ..........................P 5 Some important facts about wine ..........................P 6 Power supply ...................................P 6 Installing your wine cabinet .............................P 6-7 Door reversibility ..............................P 8-9 Loading and layout advice............................ P 10-11 Commissioning and temperature setting......................

  • Page 4: Protecting The Environment

    When replacing your wine cabinet, enquire at your local municipal refuse department in order to find out the suitable recycling procedure. The refrigerant gases, substances and some parts contained in ARTEVINO wine cabinets are made up of recyclable materials which require a special disposal procedure to be followed.

  • Page 5: Description Of Your Wine Cabinet

    Description of your wine cabinet OXYVD7WCOUS Cabinet body Upper hinge Glass door Cabinet bracing bar (do not remove) Universal shelf (storage, sliding, presentation) Support strip for fixing shelf Lock Adjustable feet (x2) Lower hinge (x2) Condensation collection tray Grid Breather hole...

  • Page 6: Some Important Facts About Wine

    Some important facts about wine Your ARTEVINO wine cabinet has been designed to guarantee optimal storage and/or serving conditions for your wine. Wine is a complex product. It develops very slowly and requires specific conditions in order to reach its full potential.
  • Page 7 • Arrange the electric power lead so that it does not come into contact with any of the cabinet’s components. • Take the lead and plug it into the connector, located at the back of the cabinet, on the bottom left-hand side. •...

  • Page 8: Door Reversibility

    Door reversibility Upper hinge Door catch Caps Lower hinge Caps Door pin Torx screw Door pin cap Hex screw This allows you to change the direction in which the door opens. Follow the instructions below (example for changing a right-hand door into a left-hand door): Unscrew the three screws using a "T25"...
  • Page 9 Unscrew the two screws and the door catch. Unscrew the two screws on the opposite side and remove the two washers. Mount the door catch on the desired opening side, using screws. Replace the washers, then the screws, on the side opposite the door catch. Turn the door through 180°.

  • Page 10: Loading And Layout Advice

    Loading and layout advice Each shelf can be used as a storage shelf, sliding shelf or display shelf. The shelves in your cabinet have 12 recesses, allowing your bottles to be stored safely. Runners (x2) Shelf - 12 recesses Dowels (x2) Shelf specially developed for wine cabinets in the Oxygen range.
  • Page 11 Installing the specific grid for beverages (only available on the 2 temperatures model - OXY2TVD6COUS) Place a universal ArteVino shelf in the beverage center. Place the grid on the ArteVino shelf (see diagram 4). Install your bottles and cans upright on the grid. Diagram 4...

  • Page 12: Commissioning And Temperature Setting

    To set the temperature of your wine cabinet The temperature of your wine cabinet is set entirely from the control panel. 1 temperature model (OXYVD7WCOUS): Press and hold down the SET button for a few seconds until the temperature setting (ST1) flashes.

  • Page 13: Regular Maintenance Of Your Wine Cabinet

    Wait a few days. If the temperature does not stabilise, contact your retailer. Regular maintenance of your wine cabinet Your ARTEVINO cabinet is a tried and tested appliance. The following few operations will allow your cabinet to perform at its best for many years to come.

  • Page 14: Operating Faults

    If the condenser is hot, set your cabinet (ST1) to the maximum temperature setting value. If the compressor still does not stop, contact your retailer. ANY WORK CARRIED OUT BY TECHNICAL SERVICES NOT APPROVED BY ARTEVINO SHALL RENDER THE WARRANTY NULL AND VOID.

  • Page 15: Energy And Technical Features

    Electrical Consumption Voltage** Frequency** Recommended T° range power* (kWh/ 24hrs)* (Hz) (Watts) Min. T° Max. T° 1 temperature 86°F 0.800 32°F model OXYVD7WCOUS Annual energy Useful Acoustic consumption AEc*** volume emissions (Kwh/year) (litres) (dB(A)) Model Temperature Height Width Depth Weight...
