  • Page 1 Interactive Flat Panel INSTRUCTION MANUAL Before connecting, operating or adjusting this product, please read the manual completely. Please keep this manual for future reference.

  • Page 2: Table Of Contents

    Contents Important Information Important Safety Precautions Important Notice Identification of Controls Remote Control Connections Basic Operations Device Settings Network Settings Menu List Using USB Multi Media Player Troubleshooting Specifications...

  • Page 3: Important Information

    CHILD SAFETY It makes a difference how and where you use your flat panel display As you enjoy your new product, keep these safety tips in mind The issue The home theater entertainment experience is a growing trend, and larger IFPs are popular purchases.

  • Page 4: Important Safety Precautions

    Important Safety Precautions WARNING CAUTION Electric shock hazard RISK OF ELECTRIC SHOCK To reduce the risk of fire or electric shock, do not remove DO NOT OPEN any cover or expose the device to rain or moisture. No user-serviceable parts are inside. Refer servicing to qualified service technicians.
  • Page 5 Important Safety Precautions (Continued) CAUTION Legal notices Damage requiring service FCC Statement Unplug this IFP from the power outlet and refer servicing 1. This device complies with Part 15 of the FCC Rules. to qualified service personnel under the following Operation is subject to the following two conditions: conditions: (1) This device may not cause harmful interference.

  • Page 6: Important Notice

    Important Notice About Location/ Do not use in hot and cold rooms (locations) Environment When the unit is used in rooms (locations) with low temperature, the picture may leave trails or appear slightly delayed. This is not a malfunction, and the unit will recover when the temperature returns to normal.

  • Page 7: Identification Of Controls

    Identification of Controls (For example: ST-700 ) :Switch the IFP power on or standby. : Press the button to display input source menu or exit the menu screen. : Press the button to return to previous menu. : Press the button to display desktop (Home page) on the screen.

  • Page 8: Remote Control

    Remote Control INPUT Switch the IFP power on or Standby Display or exit input source menu 0-9 number buttons Set up the sleep timer Select the screen size SLEEP ZOOM INFO EXIT Display or exit the current Return to previous menu program information or exit the on-screen menu To confirm or enter a sub-menu or...
  • Page 9 Remote Control Installing remote control Batteries To install remote control batteries: Open the battery cover. Insert two AAA batteries into the battery compartment. Make sure that the + and – symbols on the batteries match the + and – symbols in the battery compartment.

  • Page 10: Connections

    Connections Cautions Before Connecting When connecting an external device to the IFP, make sure that the IFP and the device are turned off.  Check the plugs at the ends of cables to make sure that they are the correct type before you try plugging them into jacks on ...
  • Page 11 Connections VGA cable Monitor VGA cable VGA 1 Audio cable VGA cable PC, etc. Audio cable VGA devices VGA 2 USB cable USB devices HDMI 1 HDMI cable (MHL) Camcorder HDMI cable HDMI 2 (ARC) Set top box Game console HDMI devices Satellite signal receiver DP cable...

  • Page 12: Basic Operations

    Basic Operations Turning the IFP on or off Plug the power cord into an AC Power outlet. Press Power Switch on the IFP. Now the IFP is in standby mode. Wait a moment until the power indicator lights up, then press POWER to turn on the IFP.
  • Page 13 Basic Operations Home Menu Overview Shortcuts you created on Home page In all applications, press and drag the icon to on Home page for shortcut created, press and drag the shortcut to X REMOVE for shortcut deleted. Call applications list Go to your USB multi-media player.

  • Page 14: Device Settings

    Device Settings Show all apps Daydream setting Display system Storage Network Setting Display information of the unit To set default input method To set Android keyboard(AOSP) To set on-screen language To set Date and time Note: To manually set date and time, you should toggle “Automatic Date &...

  • Page 15: Network Settings

    Network Settings Ethernet setting Internal routing setting IP settings Reset Internal Router by hardware. Password is required for this operation and is the same password to access Lock menu. Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login.
  • Page 16 Network Settings(Continued) Wired Network Setting Internal router Method 1: Easy Setup Wizard Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select Easy Setup Wizard Select Gateway Next There are five methods to connect with network, choose your preferred one.
  • Page 17 Network Settings(Continued) Wired Network Setting Internal router Method 2: Advanced Mode Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select Select SETUP, Advanced then SETUP Mode WIZARD Next Select Gateway Next...
  • Page 18 Network Settings(Continued) Wired Network Setting Internal router Method 3: Operating mode Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select SETUP, then Select OPERATING MODE Advanced Mode Select Gateway, then press Apply Changes.
  • Page 19 Network Settings(Continued) Wireless Network Setting Internal router (For example, WAN lnterface:5G Method 1: Easy Setup Wizard Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select from 5G, 2.4G. Select Easy Setup Wizard Select Wireless ISP Next...
  • Page 20 Network Settings(Continued) Wireless Network Setting Internal router Select SETUP, then SETUPWIZARD (For example, WAN lnterface:5G Method 2: Advanced Mode Select Advanced Mode Input the default UserName: admin, skip the default password setting as there is no default Next password, then press Login button login. Select Wireless ISP Next Next...
  • Page 21 Network Settings(Continued) Wireless Network Setting Internal router (For example, WAN lnterface:5G Method 3: Operating mode Input the default UserName: admin, skip the default password setting as there is no default password, then press Login button login. Select SETUP, then Select OPERATING MODE Advanced Mode Select Wireless ISP,...

  • Page 22: Menu List

    Menu List Adjusting Picture mode Picture Mode Select your favourite picture mode for each input [Standard] / [Soft] / [User] / [Game] / [Writing] / Dynamic]. Adjust the contrast. Contrast Brightness Adjust the brightness. Adjust the image hue. (Only for NTSC system) Sharpness Adjust the sharpness.
  • Page 23 Menu List Adjusting Setting menu Source Auto Switch Select On to automatically recognition source. Color Range Select color range. (Only for HDMI channel) HDMI EDID Ver. Select HDMI EDID Ver. (Only for 4K model) MHL Auto Switch Select On to automatically switch to the MHL input when it connected.

  • Page 24: Using Usb Multi Media Player

    Using USB Multi Media Player Using USB multi media player You can connect a USB storage device to your IFP to view compatible photo, movie or play compatible music so that the sound can be output from the IFP’s speaker. To use USB multi media player, please go to USB source by pressing USB button.
  • Page 25 Using USB Multi Media Player Playing Photo With the photo viewer, you can view compatible photos (in JPG, BMP or PNG format). Also you can zoom, rotate photo, etc. Previous photo Play/pause Show information Next photo Rotate clockwise Zoom in Rotate anti-clockwise Zoom out Note: You can also use...
  • Page 26 Using USB Multi Media Player Playing Video With the USB movie player, you can play compatible video (in AVI, MPG, MPEG, DAT, MP4, TS, RM/RMVB, or MKV/MOV format). Previous video Select sound mode Fast reverse Select aspect ratio Play/pause Select picture mode Fast forward Adjust the volume Next video...

  • Page 27: Troubleshooting

    Troubleshooting If, after reading these operating instructions, you have additional questions related to the use of your IFP, please call the services center in your local area. Before calling service, please check the symptoms and follow suggested solutions. Remote Control Problem Possible Solutions The batteries could be weak.

  • Page 28: Specifications

    Specifications Specifications Model No. ST-650U ST-700 ST-750U ST-840U ST-860U AC 100-240 V, 50 / 60 Hz Power Source 2.8A 3.1A 5.2A 6.2A 6.5A Current Max. 65 inches(diagonal) 70 inches(diagonal) 75 inches(diagonal) 84 inches(diagonal) 86 inches(diagonal) Visible screen size 3840×2160 1920×1080 3840×2160...
  • Page 29 PRINTED ON RECYCLED PAPER...
