ADI TiLite ZRA Install Manual

Disc brake
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
TiLite ZRA disc brake install guide
Page 1 of 5

Advertisement

loading
Need help?

Need help?

Do you have a question about the TiLite ZRA and is the answer not in the manual?

Questions and answers

Related Manuals for ADI TiLite ZRA

Summary of Contents for ADI TiLite ZRA

  • Page 1 TiLite ZRA disc brake install guide Page 1 of 5...
  • Page 2 parts included in kit. Threaded inserts - 2 ea. Hayes Caliper w/ U bracket - 2 ea. Caliper plate - 2 ea. Caliper plate width spacers 6” Hayes rotors w/ disc hub - 2 ea. Disc guards - 2 ea. Threaded insert C clip - 2 ea.
  • Page 3 Caliper bracket mounts to ZRA Camber tube vertical adjustment bracket. Page 3 of 5...
  • Page 4 Screw threaded insert into camber tube. Install 6” Hayes rotor on threaded insert, and anchor with C clip Install caliper plate to ZRA with appropriate bottom spacing to achieve wheel camber Install Hayes caliper w/ U-bracket to caliper plate with appropriate spacer length to achieve desired wheel spacing...
  • Page 5 Caliper Plate Spacer Disc Guard Note: Caliper plate spacer longer on the bottom to achieve appropriate degree camber Page 5 of 5...
