- Page 1 Ver 0.4a USER'S MANUAL RADS11 / RADF13 RADIO REMOTE CONTROL SYSTEMS 0341 RADS11 and RADF13 Users Manual ver0.4a.doc KCI Hoists Corp. reserves the right to modify this information without prior notification. Page 1 of 23...
-
Page 2: Table Of Contents
I N D E X CONFORMITY DECLARATION................3 DESCRIPTION ......................4 SAFETY PRECAUTIONS..................5 What you must do ....................5 What you must not do..................5 INSTALLATION ...................... 6 The BC60K battery charger................6 Receiver ......................7 Starting-up ....................... 11 Spurious ...................... -
Page 3: Conformity Declaration
1 CONFORMITY DECLARATION KCI Hoists corp. Ruununmyllyntie 13 FIN-13210 Hämeenlinna. Finland NIF A-20-036.018 Phone: +358 (0)20 427 11 FAX: +358 (0)20 427 3399 And in its name, Mr. Ari Kiviniitty, Managing Director, declares, conscious of complete responsibility, that the product Remote Control KCI Hoists Corp. -
Page 4: Description
2 DESCRIPTION The RADS11 and RADF13 push-button transmitter type, radio remote control systems, are designed for the remote control of hoists and cranes, and are particularly suitable for applications when the operator needs to be able to choose the best location from which to carry out an operation. -
Page 5: Safety Precautions
3 SAFETY PRECAUTIONS These instructions must be read carefully in order to install and use the set properly and to keep it in perfect working condition and to reduce the risks of misuse. Do not use this set on machines for the lifting of persons or in potentially explosive atmospheres. -
Page 6: Installation
Never allow unqualified personnel to operate the equipment. After use, never leave the equipment ON. Always use the contact key or the STOP button to avoid accidentally activating manoeuvres. Do not use the set when visibility is limited. Avoid knocking or dropping the set. Do not use the set if failure is detected. -
Page 7: Receiver
4.2 Receiver Make sure that the crane is stopped for the entire duration of the assembly process, keep the work area free and wear protective clothing. Park the crane and position stop-ends (if these are not available use appropriate signs) at a suitable distance so that it is not hit by other cranes on the same runway. Check the power-supply voltage and turn off the mains switch. -
Page 8: Figure 3 Receiver To Power Electric Circuit Connection
Figure 3 Receiver to Power Electric Circuit connection Connect the power supply and the receiver outputs on the corresponding relay board plug-in terminals. Do this following the outputs diagram which is supplied with the set. This diagram indicates the correspondence between the transmitter commands and the receiver outputs. -
Page 9: Figure 4 Receiver's Rad-Rs Outputs
Figure 4 Receiver’s RAD-RS outputs Remember to connect the ground cable. Only use fireproof cables for connections. Select the appropriate voltage on the receiver, (115 or 48 Vac). RADS11 and RADF13 Users Manual ver0.4a.doc KCI Hoists Corp. reserves the right to modify this information without prior notification. Page 9 of 23... -
Page 10: Figure 5 Receiver's Rad-Rf Outputs
Figure 5 Receiver’s RAD-RF outputs Remember to connect the ground cable. Only use fireproof cables for connections. Select the appropriate voltage on the receiver, (115 or 48 Vac). RADS11 and RADF13 Users Manual ver0.4a.doc KCI Hoists Corp. reserves the right to modify this information without prior notification. Page 10 of 23... -
Page 11: Starting-Up
4.3 Starting-up Proceed with caution; the equipment may not be connected correctly which may lead to unforeseeable movements on starting-up. Once the receiver has been connected, disconnect the power supply to the motors, (for example, by removing the fuses) and power on the receiver. The receiver will enter into the SCANNING mode while the own transmitter is off. - Page 12 On receiving a signal from the transmitter, the receiver will enter into de WORKING mode. The following LEDs will light up on the receiver: SIGNAL: Flashing ON, indicating that it is receiving an RF signal at the working frequency. (Now temporary ON fix). POWER: ON, indicating that the power supply is correct.
-
Page 13: Spurious
4.4 Spurious The receiver is designed to become blocked if there is intense spurious disturbance arising from galvanic, inductive, or capacitive coupling, thus preventing unwanted manoeuvres. As a precautionary measure, it is recommended that spurious-preventing devices (diodes, capacitors, RC circuits) be fitted at the source of the disturbance. These devices should be connected directly to the contactor coil terminals, etc. -
Page 14: Use
5 USE To ensure correct use of the equipment, follow the instructions below: Make sure the transmitter you are going to use is the right one, identifying the machine on the identification label. Attach the strap to the transmitter unit. Its use is recommended to prevent the equipment from falling. -
Page 15: How To Access To The Crane Condition Monitoring Unit In Radf13 System. Service Mode
6 HOW TO ACCESS TO THE CRANE CONDITION MONITORING UNIT IN RADF13 SYSTEM. SERVICE MODE. 6.1 General Description of Service Mode For RADF13 systems, there are a special “Service Mode” of operation for maintenance and set up the Crane Monitoring Unit PREMIUM via radio. This unit is connected to the receiver RAD-RF by a serial data communication CL20mA. -
Page 16: Keys For Moving Within The Menus
While the system is in service mode the “envelope” icon in the display will be switched ON. (Figure 8). Figure 8 LCD Display in Service Mode 6.3 Keys for moving within the Menus. The keys for moving within the menu are the following (Figure 9): ♦... -
Page 17: Exiting Service Mode
6.6 Exiting Service mode. There are two ways of exiting this mode. • Pressing the STOP button. (the transmitter will be switched OFF and the receiver will switch to standby mode). If the system is switched ON again and the system was switched OFF in a menu within the service mode, when receiving the new frames in normal operation, first of all the following message may appear: “EXITING SERVICE MODE”. -
Page 18: Maintenance
7 MAINTENANCE 7.1 Guarantee The systems RADS11 / RADF13 remote control sets are guaranteed for a period of up to one year after the date of delivery. This guarantee covers repairs and the replacement of defective pieces at our Technical Service Department. Both the transmitter and receiver will be necessary if any repairs or replacements need to be carried out. -
Page 19: Preventive Maintenance
7.3 Preventive maintenance A few simple checks can bring to light certain defects which can later be the cause of subsequent break-downs and which can be readily rectified. We recommend the following checks to be made from time to time: Transmitter: Check the transmitter’s closing screws to make sure they are securely tightened. - Page 20 7.4.2 RECEIVER In WORKING mode, the 5 green LEDs should light as described in Starting-up procedure. If this is so, press the transmitter manoeuvre buttons and observe the response of the output relays. If the response is normal, the problem is not related to the remote control equipment and the installation must be checked.
-
Page 21: Spare Parts
7.5 Spare parts 7.5.1 Transmitters Europe TS – EU; Code TF – EU; Code US/Canada TS – US; Code TS – US; Code 7.5.2 Battery and charger Battery charger BC60K Battery BT60K Code Code RADS11 and RADF13 Users Manual ver0.4a.doc KCI Hoists Corp. - Page 22 Power supply 230 Vac 115 Vac 230 Vac UK Code : Code : Code : 7.5.3 Command elements Pushbuttons P60K Rubber cover CP60K Stop button Code: Code : Code : Key lock K60 Selector switch S60 Code: Code: RADS11 and RADF13 Users Manual ver0.4a.doc KCI Hoists Corp.
-
Page 23: Drilling Pattern Sheet
8 Drilling pattern sheet. NO SCALE RADS11 and RADF13 Users Manual ver0.4a.doc KCI Hoists Corp. reserves the right to modify this information without prior notification. Page 23 of 23...
