Page 1: Installation Guide
Oracle InfiniBand Switch IS2-46 ® Installation Guide Part No: E65868-01 September 2016...
Page 3 Oracle. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services, except as set forth in an applicable agreement between you and Oracle.
Page 4 Oracle Corporation et ses affiliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou services émanant de tiers, sauf mention contraire stipulée dans un contrat entre vous et Oracle. En aucun cas, Oracle Corporation et ses affiliés ne sauraient être tenus pour responsables des pertes subies, des coûts occasionnés ou des dommages causés par l’accès à...
Page 5: Table Of Contents
Contents Using This Documentation ................. 9 Product Documentation Library ................. 9 Feedback ....................... 9 Understanding the Switch ................. 11 Installation Task Overview ................ 11 Switch Overview ................... 13 Front Panel Components ................. 14 Rear Panel Components .................. 15 Confirming Specifications ................. 17 Physical Specifications ................... 17 Electrical Specifications .................. 18 Environmental Specifications ................ 18 Airflow Precautions .................. 19 Rack Compatibility ..................
Page 6 ▼ Verify That the Switch Is Operational ............ 89 ▼ Verify Connectivity .................. 91 ▼ Log In to the Oracle Fabric Manager Interface .......... 94 ▼ Log In to the Oracle Fabric OS Interface ............ 96 ▼ Run the Oracle Fabric OS Configuration Wizard .......... 97...
Page 7 Contents Oracle Fabric OS Configuration Wizard Parameters .......... 98 Glossary ...................... 99 Index ........................ 107...
Page 8 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 9: Using This Documentation
Using This Documentation Overview – Describes how to prepare for and install the Oracle InfiniBand Switch IS2-46. ■ Audience – Installers, technicians, system administrators, and authorized service providers. ■ Required knowledge – Advanced experience installing network hardware. ■ Product Documentation Library Documentation and resources for this product and related products are available at http://www.
Page 10 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 11: Understanding The Switch
Understanding the Switch These topics describe the switch and the installation process. “Installation Task Overview” on page 11 ■ “Switch Overview” on page 13 ■ “Front Panel Components” on page 14 ■ “Rear Panel Components” on page 15 ■ Related Information “Confirming Specifications”...
Page 12 ■ “Verify Connectivity” on page 91 Administer the switch. ■ “Log In to the Oracle Fabric Manager Interface” on page 94 ■ “Log In to the Oracle Fabric OS Interface” on page 96 ■ “Run the Oracle Fabric OS Configuration Wizard” on page 97...
Page 13: Switch Overview
Switch Overview Related Information “Switch Overview” on page 13 ■ “Front Panel Components” on page 14 ■ “Rear Panel Components” on page 15 ■ Switch Overview The switch is a complete access switching and I/O platform that consolidates and virtualizes the switching infrastructure for server and storage systems deployed in high-performance enterprise clouds.
Page 14: Front Panel Components
SER MGT port SER MGT module (SMM), with battery inside Related Information “Installation Task Overview” on page 11 ■ “Switch Overview” on page 13 ■ “Rear Panel Components” on page 15 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 15: Rear Panel Components
Rear Panel Components Rear Panel Components The rear panel is the data cable connection end of the switch. This end of the switch is installed to the hot aisle. Description PrizmMT connectors: ■ Ports 1 to 24 – IB 4x (magenta housing) ■...
Page 16 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 17: Confirming Specifications
Confirming Specifications These topics describe the specifications of the switch and related precautions for installation. “Physical Specifications” on page 17 ■ “Electrical Specifications” on page 18 ■ “Environmental Specifications” on page 18 ■ “Airflow Precautions” on page 19 ■ “Rack Compatibility” on page 20 ■...
Page 18: Electrical Specifications
5% to 85% noncondensing, 80˚F maximum wet bulb bulb Elevation (Oracle requirement) Maximum 3000 meters at 40˚C Maximum 9840 feet at 104˚F Related Information “Physical Specifications” on page 17 ■ “Electrical Specifications” on page 18 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 19: Airflow Precautions
Airflow Precautions “Airflow Precautions” on page 19 ■ “Rack Compatibility” on page 20 ■ “Rack Precautions” on page 20 ■ Airflow Precautions Proper airflow is essential for keeping the switch's internal temperatures within a safe Caution - operating range. Air flows from the front (fan end) of the switch to the rear (connector end) of the switch. Air flows through the power supplies from the sides of the switch to out the front.
Page 20: Rack Compatibility
This switch and rackmounting hardware is designed for installation into a Sun Rack II or compatible rack or cabinet. The switch has a shorter form factor than Oracle rackmounted computing products. There is a gap between the rack front door and the switch front panel. To aid in proper airflow management and minimize air recirculation within the rack, install the air duct assembly at the front of the switch.
Page 21 Rack Precautions Reduced Air Flow. Install the equipment in a rack so that the amount of air flow is Caution - adequate for the safe operation of the equipment. Mechanical Loading. Mount the equipment in the rack so that the weight is Caution - distributed evenly.
Page 22 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 23: Preparing For Installation
Preparing for Installation These topics provide information to prepare for the switch installation process. “Shipping Kit” on page 24 ■ “Record the MAC IDs” on page 25 ■ “Assign IP Addresses to the SP and SCP Through DHCP” on page 26 ■...
Page 24: Shipping Kit
Front mounting brackets, short C-channel brackets (shown mounted) Fasteners Power cords Documentation Cable management extenders Long rails Cable management cover Cable management bracket (CMB) Attachment brackets Attachment plates Air duct Cover Snap brackets Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 25: Record The Mac Ids
Record the MAC IDs Related Information “Record the MAC IDs” on page 25 ■ “Assign IP Addresses to the SP and SCP Through DHCP” on page 26 ■ “Handling Precautions” on page 26 ■ “ESD Precautions” on page 27 ■ “Installation Tools”...
Page 26: Assign Ip Addresses To The Sp And Scp Through Dhcp
“Handling Precautions” on page 26 ■ “ESD Precautions” on page 27 ■ “Installation Tools” on page 27 ■ Handling Precautions Deploy the antitilt legs on the equipment rack before beginning an installation. Caution - Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 27: Esd Precautions
ESD Precautions Two people are required to lift and mount this switch into a rack when performing the Caution - tasks in this document. When performing a two-person task, always communicate your intentions clearly Caution - before, during, and after each step to minimize confusion. Related Information “Shipping Kit”...
Page 28 “Record the MAC IDs” on page 25 ■ “Assign IP Addresses to the SP and SCP Through DHCP” on page 26 ■ “Handling Precautions” on page 26 ■ “ESD Precautions” on page 27 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 29: Installing The Switch
Installing the Switch Perform these tasks in the order presented to install the switch. “Stabilize the Rack” on page 29 ■ “Install the Switch Brackets” on page 30 ■ “Assemble the Cable Management Extenders” on page 32 ■ “Prepare the Air Duct Assembly” on page 33 ■...
Page 30: Install The Switch Brackets
“Installation Task Overview” on page Using a No. 1 Philips screwdriver, attach the long front brackets (with cutouts) to the front of the switch with four M3x6 flathead screws on each side. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 31 Install the Switch Brackets The flange of the long front mounting brackets points away from the switch. Attach the C-channel brackets to the switch with four M3x6 flathead screws on each side. The edge of each C-channel bracket is flush to the rear of the chassis. Assemble the cable management extenders.
Page 32: Assemble The Cable Management Extenders
Use two M4x10 flathead screws to sandwich the attachment bracket and plate to the extender, in the position farthest from the flange. Using a No. 1 Phillips screwdriver, tighten the two screws. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 33: Prepare The Air Duct Assembly
Prepare the Air Duct Assembly Repeat Step 2 through Step 5 for the other cable management extender. Prepare the air duct assembly. “Prepare the Air Duct Assembly” on page Related Information “Stabilize the Rack” on page 29 ■ “Install the Switch Brackets” on page 30 ■...
Page 34 “Route the Power Cords” on page 38 ■ “Route the SER MGT Cable” on page 39 ■ “Install the Switch” on page 40 ■ “Install the CMB” on page 45 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 35: Install The Cage Nuts
Install the Cage Nuts Install the Cage Nuts Identify the prerequisite and subsequent installation tasks that you must perform in conjunction with this task. “Installation Task Overview” on page Determine where you are installing the switch. Mark this location on each rack post with masking tape. Counting the number of rack units from the bottom of the rack to the mounting location assists you when marking the other rack posts.
Page 36 “Install the Switch Brackets” on page 30 ■ “Assemble the Cable Management Extenders” on page 32 ■ “Prepare the Air Duct Assembly” on page 33 ■ “Install the Rackmount Hardware” on page 37 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 37: Install The Rackmount Hardware
Install the Rackmount Hardware “Route the Power Cords” on page 38 ■ “Route the SER MGT Cable” on page 39 ■ “Install the Switch” on page 40 ■ “Install the CMB” on page 45 ■ Install the Rackmount Hardware Identify the prerequisite and subsequent installation tasks that you must perform in conjunction with this task.
Page 38: Route The Power Cords
Use hook and loop fastener straps to bundle and secure the cords. Consider your next task. If you will have a full-time SER MGT connection, route the SER MGT cable. ■ “Route the SER MGT Cable” on page Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 39: Route The Ser Mgt Cable
Route the SER MGT Cable If the SER MGT connection is only temporary for installation, install the ■ switch now. “Install the Switch” on page Related Information “Stabilize the Rack” on page 29 ■ “Install the Switch Brackets” on page 30 ■...
Page 40: Install The Switch
Identify the prerequisite and subsequent installation tasks that you must perform in conjunction with this task. “Installation Task Overview” on page Carefully lift the switch and slide it into the rack, from the front rearward. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 41 Install the Switch Ensure that the ends of the long rails slide into the C-channel brackets at the rear of the switch chassis. Using a No. 2 Philips screwdriver, hold the front of the switch chassis to the front rack posts with two M6x12 screws at each side. Installing the Switch...
Page 42 Install the Switch Do not fully tighten the screws at this time. Note - Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 43 Install the Switch Slide the snap bracket under the loose screws with the tabs pointing into the rack. Installing the Switch...
Page 44 “Install the Rackmount Hardware” on page 37 ■ “Route the Power Cords” on page 38 ■ “Route the SER MGT Cable” on page 39 ■ “Install the CMB” on page 45 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 45: Install The Cmb
Install the CMB Install the CMB Identify the prerequisite and subsequent installation tasks that you must perform in conjunction with this task. “Installation Task Overview” on page If installed, loosen the two captive thumbscrews that secure the cover to the CMB and lift the cover off.
Page 46 “Install the Cage Nuts” on page 35 ■ “Install the Rackmount Hardware” on page 37 ■ “Route the Power Cords” on page 38 ■ “Route the SER MGT Cable” on page 39 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 47 Install the CMB “Install the Switch” on page 40 ■ Installing the Switch...
Page 48 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 49: Connecting Cables
Connecting Cables These topics provide cabling information and describe how to cable the switch. Description Links Understand cable requirements. “Cable Requirements” on page 49 Identify cable differences. “Standard MT and PrizmMT Cables” on page 50 Heed cable precautions. “Cable Precautions” on page 52 If necessary, assemble the optical data cables.
Page 50: Standard Mt And Prizmmt Cables
This is the preferred means of connecting to the SP, because it gives you the flexibility to use any host on the network to interact with the SP and the Oracle ILOM web interface. To improve security, a VLAN ID can be configured for the SP.
Page 51 Standard MT and PrizmMT Cables Technology Ferrule Housing Alignment Method Fiber Color Spacing 4x PrizmMT optical cable PrizmMT (clear with lenses) Magenta Post and Hole Wide 12x PrizmMT optical cable PrizmMT (clear with lenses) Black Post and Hole Wide 4x standard MT optical cable Standard MT (black) Aqua Pin or Hole...
Page 52: Cable Precautions
85 mm (3.4 inches). Ensure that corners. Unroll the cable as you lay it cable turns are as wide as possible. down and move it through turns. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 53 Cable Precautions Do not twist the cable to open a kink. If it Do not pack the cable to fit a tight space. is not severe, open the kink by unlooping Use an alternative cable route. the cable. Do not hang the cable for a length Do not straighten the cable to correct a more than 2 meters (7 feet).
Page 54: Assemble The Sfp+ Cables
Remove the caps from an LC connector of the fiber optic cable. Holding the shafts of the LC connector, insert the LC connector into the receptacles of the SFP+ optical transceiver. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 55 Assemble the SFP+ Cables The LC connector and SFP+ receptacles are keyed for proper fitting. Note - Push the connector into the transceiver until it clicks. Repeat from Step 3 for the other end of the cable. Repeat from Step 2 for all SFP+ cables to be assembled.
Page 56: Route The Cables
“Cable Precautions” on page 52 ■ “Assemble the SFP+ Cables” on page 54 ■ “Connect the RJ-45 Ethernet Cables” on page 57 ■ “Connect the PrizmMT Cables” on page 58 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 57: Connect The Rj-45 Ethernet Cables
Connect the RJ-45 Ethernet Cables “Connect the SFP+ Cables” on page 60 ■ “Secure Cables to the CMB” on page 62 ■ Connect the RJ-45 Ethernet Cables Identify the prerequisite and subsequent installation tasks that you must perform in conjunction with this task. “Installation Task Overview”...
Page 58: Connect The Prizmmt Cables
Insert the cleaner tip into the receptacle. Pump the cleaner into the receptacle, advancing the cleaning cloth inside. Remove the cleaner from the receptacle and verify cleanliness. Repeat from Step 3b if the fibers are still dirty. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 59 Connect the PrizmMT Cables Replace the adapter onto the end of the PrizmMT cleaner. Remove the protective cap from the cable connector and visually inspect the connector. The connector should be clean and free of dirt or debris. If the connector is dirty, clean it. Open the lid of the adapter on the end of the PrizmMT cleaner.
Page 60: Connect The Sfp+ Cables
The shell should not be bent and should be parallel to the inner boards. If the connector is bent or damaged, use a different cable. Ensure that the retraction strap is folded back against the cable. Orient the cable connector to the SFP+ receptacle squarely and horizontally. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 61 Connect the SFP+ Cables Ensure that the L groove is up for the top row of receptacles, or that the L groove is down for the bottom row of receptacles. Slowly move the connector in. As you slide the connector in, the shell should be in the center of the SFP+ receptacle. If the connector stops or binds after about 1/4 in.
Page 62: Secure Cables To The Cmb
“Secure Cables to the CMB” on page 62 ■ Secure Cables to the CMB Identify the prerequisite and subsequent installation tasks that you must perform in conjunction with this task. “Installation Task Overview” on page Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 63 Secure Cables to the CMB While connecting the RJ-45, SFP+, and PrizmMT cables to the switch, lay the cables into an available slot on the CMB. Connecting Cables...
Page 64 ■ “Standard MT and PrizmMT Cables” on page 50 ■ “Cable Precautions” on page 52 ■ “Assemble the SFP+ Cables” on page 54 ■ “Route the Cables” on page 56 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 65 Secure Cables to the CMB “Connect the RJ-45 Ethernet Cables” on page 57 ■ “Connect the PrizmMT Cables” on page 58 ■ “Connect the SFP+ Cables” on page 60 ■ Connecting Cables...
Page 66 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 67: Powering On The Switch
Powering On the Switch These topics describe how to power on the switch for the first time. Description Links Retrieve the power cords and SER “Retrieve the Power Cords and SER MGT Cable” on page 67 MGT cable. Connect the serial management ■...
Page 68 Open the larger loop approximately 45 degrees to form a hook. Holding the smaller loop, insert the larger loop into the opening of the long front mounting bracket, to hook the power cord hanging inside. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 69 Retrieve the Power Cords and SER MGT Cable Pull the power cord through the opening, until you can grasp it with your fingers. Pull the cord through so that the end of the cord is free. Repeat Step 5 through Step 7 for the other power cord.
Page 70 “Connect a Serial Management Device to the SER MGT Port” on page 74 ■ “Connect the Power Cords” on page 74 ■ “Install the Air Duct Assembly” on page 76 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 71: Connect The Ser Mgt Cable
Pass the end of the SER MGT cable through the opening on the side of the air duct assembly. If the SER MGT cable is on the left, pass the cable from the outside, through ■ the opening on the left side (no Oracle logo) in to the center. Powering On the Switch...
Page 72 If the SER MGT cable is on the right, pass the cable from the outside, ■ through the opening on the right side (Oracle logo) in to the center. Continue to pull the cable through the air duct assembly to take up the slack.
Page 73 Connect the SER MGT Cable The tab is up for the receptacle. Insert the connector into the receptacle until it clicks, securing it in place. Connect the other end of the SER MGT cable to a serial device. “Connect a Serial Management Device to the SER MGT Port” on page Related Information “Retrieve the Power Cords and SER MGT Cable”...
Page 74: Connect A Serial Management Device To The Ser Mgt Port
“Log In to the SP (Network Management)” on page 84 ■ Connect the Power Cords Identify the prerequisite and subsequent installation tasks that you must perform in conjunction with this task. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 75 Connect the Power Cords “Installation Task Overview” on page Ensure that the circuit breakers for the facility power receptacle or power distribution device are switched off. Plug the power cords into the receptacles at the front of the switch chassis. Plug each power cord into the facility power receptacle or power distribution device.
Page 76: Install The Air Duct Assembly
Tuck the power cord slack into the opening of the long front mounting bracket. Tuck the SER MGT cable slack into the cavity of the air duct assembly. Lift the air duct assembly to where it installs on the switch. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 77 Install the Air Duct Assembly Though the air duct assembly is symmetrical, the logo, if present, goes to the right. Push the air duct assembly in to the front of the switch, until it snaps into place. Consider your next steps. If you have DHCP-assigned IP addresses, power on the switch.
Page 78: Power On The Switch
The fans spin up to maximum speed. ■ Over the next few minutes, the fans gradually decrease in speed. Note - Full power is applied to all circuits and systems inside the switch. ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 79: Log In To The Sp (Ser Mgt)
Log In to the SP (SER MGT) Both the SP and SCP are powered on and booting up. ■ You might see the boot sequence on the serial device. Note - The SP LED slow blinks. ■ When the SP LED stops blinking and stays lit, and the OK LED lights, it is possible to log in to the SP.
Page 80: Assign A Static Ip Address To The Sp
Password: changeme -> The -> prompt is displayed. You can change the password at a later time. Refer to the Oracle EDR InfiniBand Switch Note - and Virtualized I/O Systems Administration Guide, changing the administrator password. Consider your next task.
Page 81 Assign a Static IP Address to the SP Access the Oracle ILOM CLI. “Log In to the SP (SER MGT)” on page Configure the network management parameters. -> set /SP/network property=value property=value ... where: property is the parameter of the network to configure.
Page 82: Assign A Static Ip Address To The Scp
Press the Enter key. Oracle Linux Server release 6.6 Kernel 4.0.4-15.el6uek.x86_64 on an x86_64 hostname login: Log in as the root user. hostname login: root Password:password Last login: Fri May 25 09:51:36 on ttyS0 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 83 SCP_IP_address is the IP address to be assigned to the SCP. Alternatively, you can configure IP address assignment by DHCP or Oracle ILOM. If you provide a static IP address, you will also need to provide the netmask and the IP address of the management network gateway.
Page 84: Log In To The Sp (Network Management)
-> where IP_address is the IP address of the SP. Initially, the password is changeme. You can change the password at a later time. Refer to the Oracle EDR InfiniBand Note - Switch and Virtualized I/O Systems Administration Guide, changing the root user password for instructions.
Page 85 Log In to the SP (Network Management) “Verify LED Status” on page If your SER MGT connection is only temporary, disconnect the SER MGT ■ cable and install the air duct assembly. “Install the Air Duct Assembly” on page Related Information “Retrieve the Power Cords and SER MGT Cable”...
Page 86 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 87: Verifying Functionality
“Verify That the Switch Is Operational” on page 89 ■ “Verify Connectivity” on page 91 ■ “Log In to the Oracle Fabric Manager Interface” on page 94 ■ “Log In to the Oracle Fabric OS Interface” on page 96 ■...
Page 88: Led Status
“Verify That the Switch Is Operational” on page 89 ■ “Verify Connectivity” on page 91 ■ “Log In to the Oracle Fabric Manager Interface” on page 94 ■ “Log In to the Oracle Fabric OS Interface” on page 96 ■...
Page 89: Verify That The Switch Is Operational
“Verify That the Switch Is Operational” on page 89 ■ “Verify Connectivity” on page 91 ■ “Log In to the Oracle Fabric Manager Interface” on page 94 ■ “Log In to the Oracle Fabric OS Interface” on page 96 ■...
Page 90 Refer to Switch Service, detecting and managing faults. Verify the switch's connectivity to the IB fabric and Ethernet network. “Verify Connectivity” on page Related Information “Verify LED Status” on page 87 ■ “LED Status” on page 88 ■ Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 91: Verify Connectivity
Verify Connectivity “Verify Connectivity” on page 91 ■ “Log In to the Oracle Fabric Manager Interface” on page 94 ■ “Log In to the Oracle Fabric OS Interface” on page 96 ■ “Run the Oracle Fabric OS Configuration Wizard” on page 97 ■...
Page 92 Start the host console. -> start /HOST/console Are you sure you want to start /HOST/console (y/n)? y Serial console started. To stop, type ESC ( Press Enter. [user@hostname ~]# where: Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 93 From here forward in this document, the admin@hostname[OFOS] prompt is replaced Note - with simply [OFOS]. If this is the first time Oracle Fabric OS is accessed, the Oracle Fabric OS configuration wizard might start. If this happens, see “Run the Oracle Fabric OS Configuration Wizard”...
Page 94: Log In To The Oracle Fabric Manager Interface
[OFOS] exit [root@nsn156-168 ~]# Serial console stopped. -> Administer the switch from Oracle Fabric Manager or Oracle Fabric OS. “Log In to the Oracle Fabric Manager Interface” on page 94 “Log In to the Oracle Fabric OS Interface” on page Related Information “Verify LED Status”...
Page 95 Address to the SCP” on page The Oracle Fabric Manager login page is displayed. Type the username and password of the Oracle Fabric Manager administrator. The default username is root, and the password is changeme. Select a language from the drop-down menu and click Log In.
Page 96: Log In To The Oracle Fabric Os Interface
Log In to the Oracle Fabric OS Interface Log In to the Oracle Fabric OS Interface When you log in to the Oracle Fabric OS interface for the very first time, the Oracle Fabric OS configuration wizard starts. From a management network attached host, start an SSH session.
Page 97: Run The Oracle Fabric Os Configuration Wizard
Consider your first step. If the Oracle Fabric OS configuration wizard has started automatically, go to ■ Step If you want to manually run the Oracle Fabric OS configuration wizard, at the ■ Oracle Fabric OS prompt, type: [OFOS} system clear config This is a destructive operation.
Page 98: Oracle Infiniband Switch Is2-46 Installation Guide • September
“Verify That the Switch Is Operational” on page 89 ■ “Verify Connectivity” on page 91 ■ “Log In to the Oracle Fabric Manager Interface” on page 94 ■ “Log In to the Oracle Fabric OS Interface” on page 96 ■...
Page 99: Glossary
Ethernet technology that supports cable distances of over 300 meters. 10GBASE-T – Standard 10GbE Ethernet technology. 10GbE/40GbE I/O module for the Oracle Fabric Interconnect F2-12 that supports 10GbE and 40GbE module interfaces. 16G Fibre I/O module for the Oracle Fabric Interconnect F2-12 that supports Fibre Channel interfaces.
Page 100 A data transference technology used primarily for storage systems. Abbreviation of fan module. See also fan module. Abbreviation of GigaByte. 1 GB is approximately 1000 MB. Abbreviation of Gigabit Ethernet. A unit of throughput for Ethernet technology. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 101 Is used in conjunction with the IB SLM modules. See also fabric card and IB SLM module. IB SLM I/O module for the Oracle InfiniBand Switch IS2-254 that provides a leaf topology construct. Is module used in conjunction with the IB SFM modules. See also line card and IB SFM module.
Page 102 A component of an IB switch chassis, that provides a leaf topology construct. See also IB SLM module. long-range IB I/O module for the Oracle Fabric Interconnect F2-12 that supports QDR IB throughput over module distances up to 40 kilometers.
Page 103 A web-based GUI to administer the switch and fabric. Manager Oracle Fabric Oracle Fabric Operating System. The operating system within the SCP, that manages the fabric. See also SCP. Oracle ILOM Oracle Integrated Lights-Out Manager. An interface using the IPMI protocol and the I C bus to monitor and control the hardware components of a chassis.
Page 104 See also MIB and OID. Service processor. A device that monitors and controls a chassis, regardless of the chassis host state, through an Oracle ILOM interface. See also Oracle ILOM and SCP. Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 105 WWPN spine switch A switch utilizing a spine topology. A transceiver used for short range Fibre Channel communication. transceiver Secure Shell. A secure network communication protocol, utilizing DSA and RSA algorithms. See also DSA and RSA. standard MT An optical fiber connector and cable used for IB 4x technology. Appears similar to, but is not cable compatible with PrizmMT cables and connectors.
Page 106 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 107: Index
Index front panel, 14 rear panel, 15 air duct configuration wizard, Oracle Fabric OS assembling, 33 parameters, 98 installing, 76 running, 97 preparing, 33 connecting airflow precautions, 19 cables, 49 assembling power cords, 74 air duct, 33 PrizmMT cables, 58...
Page 108 SP, 25 running the Oracle Fabric OS configuration wizard, 97 Oracle Fabric Manager, 94 Oracle Fabric OS, 96 configuration wizard parameters, 98 running configuration wizard, 97 assigning DHCP IP address, 26 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
Page 109 Index assigning static IP address, 82 login verifying Oracle Fabric Manager interface, 94 functionality, 87 Oracle Fabric OS interface, 96 LED status, 87 SER MGT cable switch connecting, 71 connectivity, 91 retrieving, 67 operation, 89 routing, 39 serial management device, 74...
Page 110 Oracle InfiniBand Switch IS2-46 Installation Guide • September 2016...
