Oracle ES1-24 Product Notes

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Oracle
Switch ES1-24 Product Notes
®
Part No: E39113-08
November 2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES1-24 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Oracle ES1-24

Summary of Contents for Oracle ES1-24

  • Page 1 Oracle Switch ES1-24 Product Notes ® Part No: E39113-08 November 2016...
  • Page 3 Oracle. Oracle Corporation and its affiliates will not be responsible for any loss, costs, or damages incurred due to your access to or use of third-party content, products, or services, except as set forth in an applicable agreement between you and Oracle.
  • Page 4 Oracle Corporation et ses affiliés déclinent toute responsabilité ou garantie expresse quant aux contenus, produits ou services émanant de tiers, sauf mention contraire stipulée dans un contrat entre vous et Oracle. En aucun cas, Oracle Corporation et ses affiliés ne sauraient être tenus pour responsables des pertes subies, des coûts occasionnés ou des dommages causés par l’accès à...

  • Page 5: Table Of Contents

    Reflective Relay .................. 11 Port Mirroring .................. 11 Uplink Port Trailing ................ 12 VRRPv3 .................... 12 Oracle ILOM 3.0 Updates ............... 12 Upgrading the Switch Firmware ............... 12 ▼ Back Up the Current Configuration Before Upgrading ...... 12 ▼ Download the Switch Firmware Package .......... 14 ▼ Install the Switch Firmware ...............  15 Configuring the Switches ................
  • Page 6 SSL V3.0 POODLE DISABLE SSL V3 (19842504) ........ 29 Switch Might Get Stuck at uboot on SSD Related Error (16922931) .... 30 Loss of Access to Management Node Oracle ILOM When Starting or Resetting the System (16893765) ................ 30 CPU Hang on Power Up (16822073) ............ 30 slb_lla: Long Time to Report Correct Status When the Link Is Down or Up (16424341) ...................

  • Page 7: Using This Documentation

    Using This Documentation Overview – Provides late-breaking information about Oracle Switch ES1-24 ■ Audience – Technicians, system administrators, and authorized service providers ■ Required knowledge – Advanced experience troubleshooting and replacing hardware ■ Product Documentation Library Documentation and resources for this product and related products are available at http://www.
  • Page 8 Oracle Switch ES1-24 Product Notes • November 2016...

  • Page 9: Late-Breaking Information

    Read the documentation in this order. Step Document Title or Type Information Provided Oracle Switch ES1-24 Product Notes Late-breaking information, supported configurations, and system limitations. README files Located in the download package, lists of corrected issues and special instructions for applying patches.

  • Page 10: New Features

    Edge Virtual Bridging Edge Virtual Bridging enables the coordination of configuration and management of a virtualized networking environment between an end station running Oracle Solaris and the external SEFOS bridge. Refer to the Sun Ethernet Fabric Operating System EVB Administration Guide for more information.

  • Page 11: Ieee Dcbx

    Refer to the Sun Ethernet Fabric Operating System IEEE DCBX Administration Guide for more information. In-Band Management In-band configuration mode on the switch enables access to the switch's Oracle ILOM interface from one of the 24 10 GbE in-band ports. “Configuring In-Band Management” on page...

  • Page 12: Uplink Port Trailing

    “Install the Switch Firmware” on page 15 ■ Back Up the Current Configuration Before Upgrading Save the current configuration to a remote site before upgrading the software. Refer to the Oracle Switch ES1-24 Configuration Guide for additional information. Oracle Switch ES1-24 Product Notes • November 2016...
  • Page 13 Back Up the Current Configuration Before Upgrading You can also use the backup and restore feature from Oracle ILOM to save the current Oracle ILOM and SEFOS configurations to a remote server. You can then restore the switch configuration after upgrading the firmware. See “Include the SEFOS Configuration in...

  • Page 14: Download The Switch Firmware Package

    Under the Patch Search section, select Product or Family (Advanced Search). Type switch in the Product field and select Oracle Switch ES1-24. Select the down arrow in the Release field and select the Oracle Switch ES1-24 folder. Oracle Switch ES1-24 Product Notes • November 2016...

  • Page 15: Install The Switch Firmware

    Ensure that you have a network configuration in place on the switch. For more information, refer to the Oracle Switch ES1-24 Installation Guide. Use TFTP, FTP, or the Oracle ILOM web interface to copy the firmware image to your server.
  • Page 16 Firmware update is complete. The system must be reset for the new image to be loaded   -> reset /SP Are you sure you want to reset /SP (y/n)? y Performing reset on /SP Oracle Switch ES1-24 Product Notes • November 2016...

  • Page 17: Configuring The Switches

      ORACLESP-AK00242424 SEFOS# show system information   Hardware Version : 2.5.8_00209384 Firmware Version : ES1-24-1.3.1.15 Switch Name : Oracle ES1-24 System Contact System Location Logging Option : Console Logging Login Authentication Mode : Local Config Save Status : Not Initiated...

  • Page 18: Configure 1 Gbps Mode On Sfp+ Interfaces

    If required, the maximum advertised speed can be changed from the SEFOS CLI. Obtain the SEFOS prompt. Configure the maximum advertised speed to 1 Gbps. Oracle Switch ES1-24 Product Notes • November 2016...

  • Page 19: Fine Tune The Vlan Setup

    Fine Tune the VLAN Setup For example, to configure ports 11 and 12. SEFOS# SEFOS(config)# interface range extreme-ethernet 0/11-12 SEFOS(config-if)# shutdown SEFOS(config-if)# speed 1000 SEFOS(config-if)# no shutdown SEFOS(config-if)# end SEFOS# write startup-config The ports only advertise 1 Gbps and 100 Mbps speeds. Note - Configure the maximum advertised speed to 100 Mbps.
  • Page 20 Vlan Port configuration table ------------------------------- Port Ex0/3 Port Vlan ID Port Acceptable Frame Type : Admit Only Vlan Tagged Port Ingress Filtering : Enabled Port Mode : Hybrid Port Gvrp Status : Enabled Oracle Switch ES1-24 Product Notes • November 2016...
  • Page 21 Fine Tune the VLAN Setup Port Gmrp Status : Enabled Port Gvrp Failed Registrations Gvrp last pdu origin : 00:00:00:00:00:00 Port Restricted Vlan Registration : Disabled Port Restricted Group Registration : Disabled Mac Based Support : Disabled Subnet Based Support : Disabled Port-and-Protocol Based Support : Enabled...
  • Page 22 Port Gvrp Failed Registrations Gvrp last pdu origin : 00:00:00:00:00:00 Port Restricted Vlan Registration : Disabled Port Restricted Group Registration : Disabled Mac Based Support : Disabled Subnet Based Support : Disabled Oracle Switch ES1-24 Product Notes • November 2016...

  • Page 23: Configuring In-Band Management

    : Disabled Configuring In-Band Management Typically, you can access the Oracle ILOM interface within the switch through the NET MGT port. By configuring in-band management, the Oracle ILOM interface becomes accessible through one of the 24 10 GbE ports. The NET MGT port remains active, and simultaneous access to Oracle ILOM is possible.
  • Page 24 Oracle(R) Integrated Lights Out Manager (Fabric Component Edition)   Version 3.0.16.0 r78530   Copyright (c) 2013, Oracle and/or its affiliates. All rights reserved.   Warning: The system appears to be in manufacturing test mode. Contact Service immediately.   Warning: password is set to factory default.

  • Page 25: Managing Sefos Configurations

    ■ Include the SEFOS Configuration in Backups By default, only the Oracle ILOM configuration is backed up when the backup feature is used. Complete the following tasks to include the SEFOS configuration in this backup. Before backing up your SEFOS configuration using the Oracle ILOM backup feature, complete the following steps.
  • Page 26 ID explicitly. Configure the network settings on the Oracle ILOM network management interface to communicate with the backup server. -> cd /SP/network Set the passphrase to the same value that was used for backup.

  • Page 27: Configuring Tacacs

    Disabled † In the TACACS+ server, the combination of ppp and ip can be configured to send additional fields in packet data. For Oracle ILOM clients, this configuration is used to send Oracle ILOM-specific fields like sefos-fs-privilege and ilom-role. Late-Breaking Information...
  • Page 28 Note - Management (u) role is enabled. Also ensure that you have collected all relevant information about your TACACS+ environment, then configure the appropriate settings from Oracle ILOM to enable authentication using TACACS+. Log in to the Oracle ILOM CLI.

  • Page 29: Known Issues

    ■ “Switch Might Get Stuck at uboot on SSD Related Error (16922931)” on page 30 ■ “Loss of Access to Management Node Oracle ILOM When Starting or Resetting the System ■ (16893765)” on page 30 “CPU Hang on Power Up (16822073)” on page 30 ■...

  • Page 30: Switch Might Get Stuck At Uboot On Ssd Related Error (16922931)

    When using the sideband feature on the Oracle ILOM X4170-M2/ZFSSA-controller to connect to the management network through the Oracle Switch ES1-24, the port might not link up after the host is shut down. This issue results in loss of access to the node.

  • Page 31: Slb_Lla: Long Time To Report Correct Status When The Link Is Down Or Up (16424341)

    Known Issues slb_lla: Long Time to Report Correct Status When the Link Is Down or Up (16424341) When links configured as part of an SLB group are shut down or brought back up on both SLB active and SLB standby switches, the SLB status on an SLB standby switch does not get updated until the ARP timeout happens.
  • Page 32 Oracle Switch ES1-24 Product Notes • November 2016...
